Module 92 - Bosch MD1, MG1 Bootloader

$377.95

Manufacturer

Description

Reviews (0)

Caption:

Direct connection to the ECU connector and Scanmatik 2/Scanmatik 2 Pro or Dialink adapter are required for operation.

ECUs manufactured after mid-2020 may not be supported.

Supported ECU

MD1/MG1 FLASH (SPC572L/SPC574K/SPC5777M/SPC58/TC275TP/TC277TP/TC298TP/TC299TP/TC387QP/TC399XP) [RD/WR/CK]
MD1/MG1 EEPROM (SPC572L/SPC574K/SPC5777M/SPC58/TC275TP/TC277TP/TC298TP/TC299TP/TC387QP/TC399XP) [RD/WR]
MG1UA008/MG1US008 FLASH (SPC574K/TC277TP) [RD/WR/CK]
MG1UA008/MG1US008 EEPROM (SPC574K/TC277TP) [RD/WR/CK]

For TC387QP/TC399XP ECUs, the module ensures proper handling of FLASH, including advanced SOTA mode detection (flash bank swapping), identification of unused areas in FLASH and EEPROM (displayed as erased), and replacing those areas with “PCMFLASH” text in the files instead of random data that other tools might capture. As a result, no damage occurs when writing to FLASH/EEPROM. However, note that files from other tools are not compatible.
MG1UA008 and MG1US008 ECUs, commonly found in Chinese-manufactured vehicles using SPC574K and TC277TP microcontrollers, are also supported. Cloning is potentially possible with these ECUs, and currently, there are no restrictions on the production date for these units.
Regarding the files: They match the full size of the processor’s flash/eeprom, meaning they are complete with no truncation, retaining all original content. The file format is consistent with Kess and Dimsport. During the writing process, SBOOT and service areas are skipped, and cloning is not supported in this module.

Connection option

Use the Bench/Boot cable for Scanmatik 2 Pro.
Use a high-quality PowerBox for PCMflash. Low-quality PowerBoxes are not recommended because dangerous voltage (up to +12V) can appear on the GPT pins, potentially damaging the ECU.
