Module 76 - Kia, Hyundai Gearbox

$132.28

Manufacturer

PCMflash

Description

Reviews (0)

Caption:

RD: Read
WR: Write
CK: Checksum correction
UNLOCK: Unlock ECU

Supported ECU

Kia/Hyundai: MG7.9.8/MEG17.9.12 Gearbox (ST10F275/TCU) [ RD/WR ]
TC14 Gearbox (MPC562/TCU) [ RD/WR/CK ]
TC60/TC80/ME(D) G17.9.8/13 Gearbox (SH72549/TCU) [ RD/WR/CK ]
MEG17.9.21 Gearbox (SH72549/TCU) [ WR/CK ]
SIM2K-24x/341 Gearbox (TC1766/TCU) [ RD/WR/CK ]
SIM2K-24x Gearbox (TC1738/TCU) [ RD/WR/CK ]
SIM2K-341 Gearbox (TC1738/TCU) [ RD/WR/CK ]
SIM2K-143 Gearbox (TC1738/TCU) [ RD/WR/CK ]
CPTSH2.08.1/CPTSH2.08.2 Gearbox (SH72544/TCU) [ RD/WR/CK ]

Gearboxes with ST10 are full read, the software can be written, and it can be changed.
Gearboxes with MPC562, SH72549 – only calibrations are read and written. They can only be changed if the software version matches!
Gearboxes in SIM2K – the software can be read and written, and it can be changed.

For all gearboxes, writing files in GDS format is supported. As usual, start by identifying and carefully checking the ECU type. The software in SIM2K on TC1738 can be of two types, and inside SIM2K-240, there can be software similar to SIM2K-341. Therefore, focus specifically on the ECU type, as the protocols in the program are named conventionally, according to the most commonly used versions.

Examples of identification (MEG7.9.8, TC14, TC80, SIM2K):

Hardware number: BT090806
ECU type: ST10F275/TCU
Software version: TTD2C16UA1
Calibration: C3063401
CVN number: D6B383EA

Hardware number: BC190106_BS190102_BB190101
ECU type: MPC562/TCU
Software version: TBK2C20NAC
Calibration: 564D0505
CVN number: BC21B82E

Hardware number: b60d0505
ECU type: SH72549/TCU
Part number: 95440-4F032
Software version: c35_v0000
Calibration: TBK0M20NH1
CVN number: DE3A17B4

Hardware number: KR821552_C06
ECU type: SIM2K-24X/341/TC1766
Software version: KR82155118
Calibration: TYF0Z24SA4
CVN number: 88A27D07

Read-write (for time estimation)

MEG7.9.8

17:24:49 Identifying module
17:24:49 Software version: TTD2C16UA1
17:24:50 Reading data
17:44:00 Completed successfully

17:44:50 Entering programming mode
17:44:51 Gaining access
17:44:52 Transferring data
17:46:20 Completed successfully

TC14

17:10:06 Identifying module
17:10:06 Software version: TBK2C20NAC
17:10:06 Reading data
17:17:48 Completed successfully

17:19:09 Entering programming mode
17:19:10 Gaining access
17:19:11 Transferring data
17:19:34 Completed successfully

TC80:

17:02:01 Identifying module
17:02:01 Software version: TBK0M20NH1_c35_v0000
17:02:01 Reading data
17:06:00 Completed successfully

17:07:21 Entering programming mode
17:07:22 Gaining access
17:07:23 Transferring data
17:08:07 Completed successfully

SIM2K:

12:34:45 Identifying module
12:34:46 Software version: TYF0Z24SA4
12:34:49 Reading data
12:36:25 Completed successfully

12:38:42 Entering programming mode
12:38:45 Gaining access
12:38:46 Transferring data
12:41:03 Completed successfully
