What is WinOLS?
WinOLS is an application, which is written especially to modify the memory contents of ECUs.
It facilitates the searching and finding of maps, which can then be named and viewed in different ways and changed. To change the data, different functions are available to edit the maps.
All data and maps are stored in project files. These project files hold all information obtained in the course of processing of a given controller. Other information, such as customer name, car number, and image files can be added.
Modifications of maps can be stored as ‘versions’ and can be commented. Up to 200 versions of one original file are possible.
All modified projects are shown in a list, which can be filtered and sorted. So it is easy to find an already modified project again.
Overview
- The raw data is displayed either in 2D graphics or hex/decimal dump. Automatic processor recognition to distinguish between program and data area.
- Functions to search for maps and to put them down on the map list makes efficient working a lot easier.
- A 3D preview window makes it easier to find maps
- Maps can be shown as 3D/2D chart or as a table.
- Automatic search of ECU and software numbers.
- You can select either English or German as the interface language and switch between these.
- Integrated checksum correction through plugins.
- Support of current hardware like BDM100, BSL100 and OLS300.
- Import and export of binary files, Intel and Motorola-Hexfiles. All types can be zipped, coded and have swapped lines or be sent directly by mail.
Slices
WinOLS 5.46 brings with “Slices” a new, alternative optical representation for maps. Here all lines are at the same height, which facilitates the comparison. With the toolbar view the display can be rotated+scaled.
Note: Slices are a “WinOLS Feature”, i.e. they have to be unlocked by paying an annual fee.
Highlight
- Text / 2d / 3d / Slices
- Automatic overview
- Automatic map search
- Extensive editing functions
- Many configuration options
- Many built-in import formats
- Export projects
- Use external hardware
- Let plugins calculate checksums
- Many import-plugins
- OLSx export / Mass export
- Scripts
- Clients
Details
Map search:
The automatic map search finds maps and shows them in a list and also directly in the data:
Preview-Window:
The preview window can be freely moved and sized and shows the selection as 3d-map:
Automatically overview:
Program code, empty areas, maps etc. are automatically detected. An overview window shows what can be found where in the file. Program code and empty areas are automatically displayed in pale.
Automatic checksums:
Each checksum module (available separately) automatically recognizes whether it can be used and corrects the checksums immediately after each change. Even in real time while the car is running. If you don have the right module yet, just press a button and all checksum modules for your project will be tested online. So you know for sure which one fits. Modules can be purchased online around the clock. You will receive the module within minutes.
Digital signatures as watermarks
By making tiny changes to the data, you can digitally sign your projects to recognize copies. Optionally openly visible to everyone or only to you. None of the text is visible in the data, but it can still be displayed.
Free choice of colour:
There are four color schemes preset and of course you can configure your own colors individually.
More features
- Original and version: For every project the original is stored permanently. Changes will be stored as version (the number of versions is not limited). Changes are displayed in colour and you can restore the original values any time.
- Multilevel undo: Up to 50 editing steps can be undone.
- Scripts for pros: If you work with similar cars, you can store the changes as scripts. This allows you to apply the changes for every new car within seconds.
- Automatic comments: You can enter comments for every project and every version. Further more they are automatically commented when you import or create new versions.
- Online project search: Our online-database can automatically fill in the fields like producer, chassis, etc. Several other fields, like Bosch number will even be filled in automatically when you’re offline.
- Complete overview: The project overview shows all your projects in a configurable and searchable list. Within the fraction of a second, even if you have hundreds of projects.
- Versions: For every project you can create as many versions as like. The version over shows which maps are changed in which version.
- Open for other projects: WinOLS can import and export binary data, Intel- and Motorola-Hexfiles. Entire maps and the map list can be exported to Microsoft Excel. Maps can be ex and imported from a project.
- Accept changes: Copy the best changes from old projects. Even if the maps were moved to a different position, they will still be automatically recognized.
- Extensive help: Texts in the status bar, tool tips for the icons, Instructions for every dialog. WinOLS keeps you informed which every step. Furthermore you can download the entire documentation as PDF here.
- Many other features. Too many to list all of them here…
Compatibility
- WinOLS 5 requires Windows 10 (x64), Windows 11 (x64) or Windows 11 (ARM).
- WinOLS 5 supports current EVC hardware like UCM100, BDM100, BSL100, OLS300 (except under ARM). Megaprommer MP2240P and OLS16 are no longer supported.
- WinOLS 5 can be installed and used in parallel to WinOLS 4 and uses the same license, i.e. you do not need another license for a WinOLS 5 installation on a computer on which WinOLS 4 is already installed. Since WinOLS5 can save additional data fields and properties in projects, the project files are no longer backwards-compatible, i.e. projects that were created or modified with WinOLS5 can no longer be opened in WinOLS4.
Support
ECUTools Vietnam is currently a distributor for WinOLS:
Read more: https://www.evc.de/en/service/links_authorized_dealers.asp
Whatsapp: +84.899.402.402
Facebook: ECUTools.vn
Youtube: ECUToolsvn
Tiktok: ECUTools
Website: ECUTools.vn
WinOLS License (3)
What is WinOLS?
WinOLS is an application, which is written especially to modify the memory contents of ECUs.
It facilitates the searching and finding of maps, which can then be named and viewed in different ways and changed. To change the data, different functions are available to edit the maps.
All data and maps are stored in project files. These project files hold all information obtained in the course of processing of a given controller. Other information, such as customer name, car number, and image files can be added.
Modifications of maps can be stored as 'versions' and can be commented. Up to 200 versions of one original file are possible.
All modified projects are shown in a list, which can be filtered and sorted. So it is easy to find an already modified project again.
Overview
- The raw data is displayed either in 2D graphics or hex/decimal dump. Automatic processor recognition to distinguish between program and data area.
- Functions to search for maps and to put them down on the map list makes efficient working a lot easier.
- A 3D preview window makes it easier to find maps
- Maps can be shown as 3D/2D chart or as a table.
- Automatic search of ECU and software numbers.
- You can select either English or German as the interface language and switch between these.
- Integrated checksum correction through plugins.
- Support of current hardware like BDM100, BSL100 and OLS300.
- Import and export of binary files, Intel and Motorola-Hexfiles. All types can be zipped, coded and have swapped lines or be sent directly by mail.
Slices
WinOLS 5.46 brings with "Slices" a new, alternative optical representation for maps. Here all lines are at the same height, which facilitates the comparison. With the toolbar view the display can be rotated+scaled.
Note: Slices are a "WinOLS Feature", i.e. they have to be unlocked by paying an annual fee.
Highlight
- Text / 2d / 3d / Slices
- Automatic overview
- Automatic map search
- Extensive editing functions
- Many configuration options
- Many built-in import formats
- Export projects
- Use external hardware
- Let plugins calculate checksums
- Many import-plugins
- OLSx export / Mass export
- Scripts
- Clients
Details
Map search:
The automatic map search finds maps and shows them in a list and also directly in the data:
Preview-Window:
The preview window can be freely moved and sized and shows the selection as 3d-map:
Automatically overview:
Program code, empty areas, maps etc. are automatically detected. An overview window shows what can be found where in the file. Program code and empty areas are automatically displayed in pale.
Automatic checksums:
Each checksum module (available separately) automatically recognizes whether it can be used and corrects the checksums immediately after each change. Even in real time while the car is running. If you don have the right module yet, just press a button and all checksum modules for your project will be tested online. So you know for sure which one fits. Modules can be purchased online around the clock. You will receive the module within minutes.
Digital signatures as watermarks
By making tiny changes to the data, you can digitally sign your projects to recognize copies. Optionally openly visible to everyone or only to you. None of the text is visible in the data, but it can still be displayed.
Free choice of colour:
There are four color schemes preset and of course you can configure your own colors individually.
More features
- Original and version: For every project the original is stored permanently. Changes will be stored as version (the number of versions is not limited). Changes are displayed in colour and you can restore the original values any time.
- Multilevel undo: Up to 50 editing steps can be undone.
- Scripts for pros: If you work with similar cars, you can store the changes as scripts. This allows you to apply the changes for every new car within seconds.
- Automatic comments: You can enter comments for every project and every version. Further more they are automatically commented when you import or create new versions.
- Online project search: Our online-database can automatically fill in the fields like producer, chassis, etc. Several other fields, like Bosch number will even be filled in automatically when you're offline.
- Complete overview: The project overview shows all your projects in a configurable and searchable list. Within the fraction of a second, even if you have hundreds of projects.
- Versions: For every project you can create as many versions as like. The version over shows which maps are changed in which version.
- Open for other projects: WinOLS can import and export binary data, Intel- and Motorola-Hexfiles. Entire maps and the map list can be exported to Microsoft Excel. Maps can be ex and imported from a project.
- Accept changes: Copy the best changes from old projects. Even if the maps were moved to a different position, they will still be automatically recognized.
- Extensive help: Texts in the status bar, tool tips for the icons, Instructions for every dialog. WinOLS keeps you informed which every step. Furthermore you can download the entire documentation as PDF here.
- Many other features. Too many to list all of them here...
Compatibility
- WinOLS 5 requires Windows 10 (x64), Windows 11 (x64) or Windows 11 (ARM).
- WinOLS 5 supports current EVC hardware like UCM100, BDM100, BSL100, OLS300 (except under ARM). Megaprommer MP2240P and OLS16 are no longer supported.
- WinOLS 5 can be installed and used in parallel to WinOLS 4 and uses the same license, i.e. you do not need another license for a WinOLS 5 installation on a computer on which WinOLS 4 is already installed. Since WinOLS5 can save additional data fields and properties in projects, the project files are no longer backwards-compatible, i.e. projects that were created or modified with WinOLS5 can no longer be opened in WinOLS4.
Support
ECUTools Vietnam is currently a distributor for WinOLS:
Read more: https://www.evc.de/en/service/links_authorized_dealers.asp
The OLS505-License allows users who already own a main WinOLS 5 license to install and use the software on an additional workstation or computer.
It provides the same full functionality as the main license, making it ideal for multi-PC setups or shared work environments.
| Item number | Description | Number of workstations |
| OLS505-Licence | Additional license for OLS505 | +1(*) |
Notice:
(*) If your Premium features have expired or are about to expire, it may be cheaper for you to extend them before purchasing a new license.
The OLS515-2 License activates Premium Features in WinOLS 5, providing access to the newest and most advanced tools developed by EVC electronic GmbH.
These premium functions are introduced gradually throughout the year, ensuring that WinOLS 5 users always stay at the cutting edge of ECU calibration technology.
With an active Premium License, you gain access to all new features released within a 12-month period. After your license expires, you can continue using WinOLS 5 indefinitely — including all standard tools and future bug fixes. However, newly released Premium-marked features will only become available again once the Premium License is renewed.
Pricing is calculated per workstation and per year, making it flexible for both individual users and professional tuning teams.
If your Premium Features have been expired for more than one year, EVC applies a renewal fee for each missing year (up to a maximum of three years).
This ensures that users who rejoin later can still benefit from all the advanced features added in the meantime.
In short, OLS515-2 gives professional tuners the ability to continuously evolve with the software — always having access to EVC’s latest innovations in data analysis, visualization, and calibration workflow optimization.
| Item number | Description | Number of workstations |
| OLS515-2 | Premium features | Price per place and year (*) |
Notice:
(*) If your Premium features have been expired for more than one year, we will charge you per year (maximum: 3) for the features added in the meantime.
Feature list:
| Premium features | Version |
| KF properties - Lock icon could not be switched off without premium features | 5.83 |
| LUA Editor (requires OLS530)
|
5.81 |
| New version of the ols file format in preparation for future features | 5.79 |
| Feature updates are now called premium features | 5.77 |
Synchronize hexdump with map (toolbar button: Sync Cursor) |
5.74 |
| Create maps from hexdump address tables
|
5.72 |
Recognize tables (at the end of the potential maps) |
5.72 |
| Quickly create QuickFixes from a selection | 5.71 |
ChangeAbsoluteMulti! Opens automatically instead of ChangeAbsolute for linked table maps |
5.70 |
| New: PrjOpen>SearchProjects |
5.62 |
PrjOpen: Right-click: "Search for (ValueFromCurrentProject)" |
5.60 |
| Create encrypted lua files: Miscellaneous> Apply previous LUA script | 5.60 |
SearchBytesequence: Replace in other maps/columns |
5.58 |
SearchBytes: Template list now as tree |
5.57 |
| SearchBytes: Template list for DropDown button
|
5.55 |
| SearchBytes: Contextmenu: Set to 0 in (connected) window
|
5.55 |
| Premium-Feature: New: Select Maps where the values exceed the defined range (Map list > context menu > Select) | 5.48 |
Key /- can now be limited to defined values to number2text |
5.48 |
| Twin windows (Ctrl+click on view bar, see also evc.de/video). |
5.47 |
| New View Mode: Layers | 5.46 |
| Pairing: Option to take the parent version (from the tree) as reference by default. | 5.44 |
| Connect: option to take as reference by default the parent version (from the tree). |
5.43 |
| MapCreateWizard: Can create multiple maps |
5.31 |
| Alt+click+drag in hexdump to beginning of map/axes to move. Additionally Ctrl to copy. |
5.31 |
| Project list can be ex-/imported directly to xlsx | 5.25 |
| EditMultipleMaps: Be able to perform multiple operations at the same time | 5.25 |
| Export as CSV: Flag as criterion | 5.25 |
| New dialog: Searches > Search Similar Maps | 5.24 |
| Premium-Feature: ProjectOpen > Options: Allow to disallow changes to the timestamp | 5.22 |
| Premium-Feature: New: AutoImport/AutoUpdate can automatically import/merge versions when managing many variants. More about this in the help file. | 5.21 |
| Some of these changes may require the purchase of a feature update |
5.21 |
| KF properties: Value range can now limit input (lock icon). |
5.21 |
Checksum Correction: (77)
Part-No: OLS220
Description: Checksum correction for Bosch TDI V2.0, V3.x, V4.x, CR1, CR2
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 03.10.2023 | 3.07 | New | TDI3.1: Now also files with length of 40000h, which contain only the map area |
| 05.05.2021 | 3.06 | New | Bosch TDI V4.1 - Identification expanded. |
| 05.03.2020 | 3.05 | Fixed | Bugfix BOSCH TDI V3.1 |
| 07.02.2020 | 3.04 | New | Revision of the BMW CR2 checksum. |
| 05.02.2020 | 3.03 | Fixed | Fixed checksum search bug. |
| 24.07.2019 | 3.02 | Fixed | Error at block end search fixed |
| 17.07.2019 | 3.01 | New | Improved information, if no checksum correction is necessary |
| 06.05.2019 | 3.00 | New | Reworked completely. Contains now OLS220, OLS224, OLS228, OLS229, OLS233, OLS234, OLS235, OLS239, OLS240, OLS254, OLS264, OLS268 |
| 08.01.2018 | 2.07 | New | Element support implemented: Project may have further elements than Eprom |
| 06.06.2016 | 2.06 | New | Internal improvements |
| 02.08.2013 | 2.05 | New | Now sync blocks can be disabled |
| 12.03.2008 | 2.04 | New | Checksum interface updated |
| 17.11.2006 | 2.03 | Fixed | Possible crash at defect projects |
| 22.02.2006 | 2.02 | Fixed | Problem at patch tag blocks fixed |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 29.08.2005 | 1.15 | Fixed | Problem with sync blocks fixed |
| 09.12.2003 | 1.14 | Fixed | Identification: Nissan Patrol has no CS |
Part-No: OLS222
Description: Checksum correction for Siemens MS40, MS41, MS42, MS43, Mini
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 15.05.2020 | 3.02 | New | MS42 checksum also about program area. |
| 11.10.2019 | 3.01 | New | Detection improved |
| 07.02.2019 | 3.00 | New | Reorganized: Now MS40 - 43 and Mini |
| 06.06.2016 | 2.03 | New | Internal improvements |
| 12.03.2008 | 2.02 | New | Checksum interface updated |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 03.06.2004 | 1.7 | New | Address for spi string modified |
Part-No: OLS226
Description: Checksum correction for Bosch ME1.0, ME2.0, ME2.1, AS41
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 23.04.2021 | 3.00 | New | Added OLS281 Bosch AS41 - Citroen Saxo 1.5D and OLS282 Bosch ME2.1 - Alfa 156 2.5V6. |
| 06.10.2020 | 2.04 | Fixed | Crash at some ME1.0 files fixed |
| 06.06.2016 | 2.03 | New | Internal improvements |
| 12.03.2008 | 2.02 | New | Checksum interface updated |
| 30.12.2005 | 2.01 | Fixed | Error messages were not displayed |
| 08.12.2005 | 2.00 | New | New registration |
| 10.09.2003 | 1.3 | New | Revised |
Part-No: OLS230
Description: Checksum correction for Bosch VDO, MSA, HFM
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 23.10.2017 | 2.03 | New | Now also MSE3.5/3.6 in MB, Ssangyong, Daewoo, Tagaz and MSM1.4 in MB A140, A160 |
| 06.06.2016 | 2.02 | New | Internal improvements |
| 16.03.2014 | 2.01 | Fixed | Recognition failed, if additional elements were in the project |
| 19.11.2013 | 2.00 | New | Test |
Part-No: OLS231
Description: Checksum correction for Bosch M2.x/M5.x BMW + Porsche, M5.2.1 BMW
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 03.03.2022 | 4.02 | New | New Bosch M2.x/M5.x |
| 12.11.2021 | 4.01 | New | New Bosch M2.x/M5.x |
| 23.04.2021 | 4.00 | New | Added OLS236 Bosch M5.2.1 BMW. |
| 03.07.2019 | 3.02 | Fixed | Error at M06 fixed |
| 21.06.2019 | 3.01 | Fixed | Error at 993 fixed |
| 08.05.2019 | 3.00 | New | Reworked and merged with OLS256 |
| 03.05.2019 | 2.10 | Fixed | M5.2: NOREAD removed because of placement problems |
| 26.04.2019 | 2.09 | New | Now also M5.2 as 8000h file |
| 12.10.2017 | 2.08 | New | Now also Byteshooter files |
| 06.06.2016 | 2.07 | New | Internal improvements |
| 07.07.2015 | 2.06 | New | Now also BMW E38 0261203484 |
| 30.11.2010 | 2.05 | New | Now also Genius files with length 1A000h |
| 31.08.2009 | 2.04 | Fixed | Error at Porsche M5.2 fixed |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 29.08.2007 | 2.02 | New | Now also 750i with M5.2 with 87M12 |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 10.09.2003 | 1.6 | New | Revised |
Part-No: OLS237
Description: Checksum correction for Siemens Mss50, MSS52/3, MSS54
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 17.03.2024 | 2.11 | Fixed | Checksum blocks were found only in the original but not in the version |
| 29.03.2018 | 2.10 | New | Handling of certain files improved |
| 12.12.2017 | 2.09 | New | MSS54: Now also both files in one project Elements: Eprom + Eprom2 |
| 06.06.2016 | 2.08 | New | Internal improvements |
| 20.03.2012 | 2.07 | Fixed | Identification improved |
| 11.01.2012 | 2.06 | Fixed | Recognition of a special case at MSS52 improved |
| 18.11.2011 | 2.05 | Fixed | Compiler error |
| 30.09.2011 | 2.04 | New | New file |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 28.11.2006 | 2.02 | New | New placement of the SPI identification |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 03.03.2004 | 1.8 | Fixed | Error at BMW M3 CSL removed |
Part-No: OLS238
Description: Checksum correction for Opel - Simtec56, Delco/2/3/4, Siemens, Bosch Me1.5.5/3.1.1, Delco DTI, GMPT, ME76.2/7.9.8, ME7.6.4, ME7.6.1/7.9.6
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 18.02.2025 | 3.06 | New | New Opel Siemens. |
| 19.09.2024 | 3.05 | New | New Opel Delco, Opel GMPT. |
| 18.08.2023 | 3.04 | New | Now also Delco with file size of 8000h |
| 23.03.2021 | 3.03 | New | PlugIn revised. |
| 08.09.2020 | 3.02 | New | SPI string removed |
| 04.10.2019 | 3.01 | Fixed | Problem on some computers. |
| 04.12.2018 | 3.00 | New | Now also Y30DT |
| 02.11.2018 | 2.99 | Fixed | Possible crash at defect file fixed |
| 24.10.2018 | 2.98 | New | New file Delco Y16XE |
| 18.09.2018 | 2.97 | New | Now also file length of 8000h at Simtec71 |
| 24.07.2018 | 2.96 | Fixed | Exclusion Chevrolet Trailblazer improved |
| 12.10.2017 | 2.95 | Fixed | Erroneous recognition of Delco-USA files |
| 08.02.2017 | 2.94 | New | Update of the GMPT checksum |
| 06.06.2016 | 2.93 | New | New file |
| 20.05.2016 | 2.92 | New | New file Opel Delco with MagPro |
| 26.01.2016 | 2.91 | New | New SIMTEC81 file |
| 06.11.2015 | 2.90 | New | New Simtec70 file |
| 05.09.2015 | 2.89 | New | New Z18XE file |
| 05.08.2015 | 2.88 | New | New Calibra file |
| 28.01.2015 | 2.87 | New | New GMPT file |
| 06.01.2015 | 2.86 | New | Short files 18000h were not found any more. |
| 11.12.2014 | 2.85 | New | New file/offset Delco3 |
| 16.09.2014 | 2.84 | New | New file SIMTEC71.5 |
| 01.08.2014 | 2.83 | New | Now also file size E0000h at ME7.6.4 |
| 18.06.2014 | 2.82 | New | Now also SIMTEC78.0 with length of 1EFF0h. |
| 07.06.2014 | 2.81 | Fixed | At ME7.6.2 and ME7.9.9 one CS at the end of the file was not corrected |
| 19.12.2013 | 2.80 | New | Now also Simtec71 with length of 46000h |
| 12.09.2013 | 2.79 | Fixed | Problem fixed at Opel Siemens |
| 23.08.2013 | 2.78 | New | New: OBD2 file X18XE |
| 12.02.2013 | 2.77 | New | SIMTEC81 |
| 15.01.2013 | 2.76 | Fixed | Problem with Compiler setting |
| 14.01.2013 | 2.75 | New | New file Simtec81 |
| 12.12.2012 | 2.74 | New | New Z18XE files |
| 09.10.2012 | 2.73 | Fixed | Z10XEP were not recognized |
| 23.08.2012 | 2.72 | New | Recognition modified for Delco3 |
| 02.08.2012 | 2.71 | New | Identification improved at ME7.6.x with linear address space port area not cut out |
| 31.07.2012 | 2.70 | New | New file SIMTEC71.6 |
| 20.07.2012 | 2.69 | Fixed | Location of patch tag block modified at ME7.6.4 |
| 28.12.2011 | 2.68 | New | New file ME7.9.9 |
| 07.06.2011 | 2.67 | Fixed | Problem at ME3.1.1 fixed |
Part-No: OLS242
Description: Checksum correction for Siemens SIM4LE, SIM4KLE
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 15.11.2022 | 2.14 | Fixed | SIM4KLE: Handling of sync blocks changed: Changes are immediately transferred to the respective block to avoid recursions. |
| 22.02.2022 | 2.13 | Fixed | Patchblock moved. |
| 26.05.2021 | 2.12 | Fixed | Placement of the PatchBlock changed. This now varies so that it is not in a SyncBlock. |
| 20.04.2021 | 2.11 | Fixed | Fixed a bug caused by a SyncBlock. |
| 13.04.2021 | 2.10 | New | Search SyncBlock for SIM4KLE added. |
| 02.11.2018 | 2.09 | Fixed | Possible crash at defect file fixed |
| 03.11.2017 | 2.08 | Fixed | Possible crash fixed |
| 26.01.2017 | 2.07 | New | Recognition improved |
| 06.06.2014 | 2.06 | New | Now also checksum correction over program area at SIM4LE |
| 22.10.2012 | 2.05 | New | Now also checksums in lower memory area |
| 26.06.2008 | 2.04 | New | New file |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 20.01.2006 | 2.02 | Fixed | Checksum search in modified file didn't work |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 30.12.2005 | 2.01 | Fixed | Error messages were not displayed |
| 08.12.2005 | 2.00 | New | New registration |
| 01.09.2005 | 1.14 | Fixed | Problem with sync blocks fixed |
| 29.08.2005 | 1.13 | Fixed | Problem with sync blocks fixed |
| 29.07.2005 | 1.12 | Fixed | Problem with sync blocks fixed |
| 03.11.2003 | 1.11 | New | Now also serial files from 1MB eproms |
Part-No: OLS243
Description: Checksum correction for Smart 005
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 12.03.2008 | 2.04 | New | Checksum interface updated |
| 06.11.2006 | 2.03 | Fixed | Patches didn't work |
| 30.05.2006 | 2.02 | Fixed | Under LUA the patches were not inserted |
| 30.12.2005 | 2.01 | Fixed | Error messages were not displayed |
| 08.12.2005 | 2.00 | New | New registration |
| 21.11.2005 | 1.10 | Fixed | Recognition improved |
| 14.11.2005 | 1.9 | Fixed | Recognition improved for 365131 |
| 10.09.2003 | 1.8 | New | Revised |
Part-No: OLS244
Description: Checksum correction for Siemens: Simos4s, SimosV2, Simos2/3/71/9x; Bosch: M3.x/M5.92 + EEPROM, ME7.9.7.1
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 25.10.2024 | 2.25 | Fixed | Eliminated difference in code between internal and public versions. |
| 02.11.2018 | 2.24 | Fixed | Possible crash at defect file fixed |
| 31.07.2017 | 2.23 | New | New file |
| 06.10.2015 | 2.22 | New | Bosch M3.x and M5.x now also EEprom checksum |
| 16.02.2015 | 2.21 | New | Special handling of 358735 |
| 15.10.2013 | 2.20 | New | Identification modified at M3.8 |
| 30.10.2012 | 2.19 | New | Recognition modified at ME7.9.71 |
| 20.12.2011 | 2.18 | New | Now also Simos71 Genius files |
| 10.12.2011 | 2.17 | Fixed | Error at short Simos9 file |
| 27.04.2011 | 2.16 | Fixed | Now also Simos9.x |
| 08.04.2011 | 2.15 | New | Now also Rowe 350 with ME7.9.7.1 |
| 04.04.2011 | 2.14 | New | Now also SIMOS2 short file with length of 8000h |
| 09.03.2011 | 2.13 | Fixed | CS over program area was not found at SIMOS71 |
| 07.01.2011 | 2.12 | Fixed | Problem at correction of already modified files |
| 16.08.2010 | 2.11 | New | New file of ME7.9.7.1 |
| 18.05.2010 | 2.10 | New | Now also ME7.9.7.1 with length E0000h |
| 29.04.2010 | 2.09 | New | New file M5.92 |
| 09.04.2010 | 2.08 | New | Now also Simos7.1 files with length of 10000h |
| 08.04.2010 | 2.07 | New | Now also Audi A3 with Bosch ME7.9.7.1 |
| 15.05.2009 | 2.06 | New | Now also Simos7PP 1MB files |
| 09.10.2008 | 2.05 | Fixed | Recognition modified at M3.8.2 |
| 12.03.2008 | 2.04 | New | Checksum interface updated |
| 29.09.2006 | 2.03 | New | Now also Bosch M5.41 |
| 08.08.2006 | 2.02 | Fixed | Simos: Checksum search at versions doesn't find a starting value |
| 30.12.2005 | 2.01 | Fixed | Error messages were not displayed |
| 08.12.2005 | 2.00 | New | New registration |
| 15.03.2005 | 1.14 | New | Now also Bosch M5.92 Audi A4 |
Part-No: OLS246
Description: Checksum correction for Bosch Volvo V70R
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 23.04.2020 | 2.03 | New | New file |
| 02.02.2015 | 2.02 | New | New file |
| 12.03.2008 | 2.01 | New | Checksum interface updated |
| 08.12.2005 | 2.00 | New | New registration |
| 10.09.2003 | 1.4 | New | Revised |
Part-No: OLS248
Description: Checksum correction for Volvo/Renault/Kia, SH705x
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 22.01.2025 | 3.08 | New | New: Siemens Ford. |
| 24.11.2023 | 3.07 | New | New Siemens Kia. |
| 08.02.2023 | 3.06 | Fixed | Fixed a bug that prompted incorrect swapping for other files. |
| 06.11.2021 | 3.05 | New | New file |
| 27.05.2021 | 3.04 | New | List expanded to include another Dacia / Renault. |
| 27.07.2020 | 3.03 | New | Added Kia Cerato. |
| 27.12.2019 | 3.02 | New | New file Tagaz C100 Vega |
| 02.05.2019 | 3.01 | Fixed | File was not recognized |
| 22.02.2019 | 3.00 | New | Revised completely |
| 02.11.2018 | 2.60 | Fixed | Possible crash at defect file fixed |
| 28.10.2016 | 2.59 | Fixed | Possible crash fixed |
| 26.10.2016 | 2.58 | New | Now also Cadillac SRX |
| 24.10.2016 | 2.57 | New | New SIRIUS34 file |
| 29.01.2015 | 2.56 | New | New Chery QQ file |
| 01.07.2014 | 2.55 | Fixed | Wrong recognition from last update fixed |
| 24.06.2014 | 2.54 | New | Now also Dacia Duster 1.6L EMS3130 with file length of 80000h or 90000h |
| 17.01.2013 | 2.53 | Fixed | Problem with compiler setting |
| 14.01.2013 | 2.52 | New | New file Samsung SM5 |
| 04.01.2013 | 2.51 | New | Now also Lifan Breez |
| 09.11.2012 | 2.50 | New | Now also short file at Daewoo Matiz |
| 04.10.2012 | 2.49 | New | New file: Renault Sandero read with KESS |
| 18.09.2012 | 2.48 | New | Recognition modified for Chevrolet Lacetti |
| 01.08.2012 | 2.47 | New | Now also Daewoo |
| 31.05.2012 | 2.46 | New | Now also Peugeot 206 with SIM2K34VR |
| 07.05.2012 | 2.45 | New | Now also Changan files |
| 07.12.2011 | 2.44 | New | Now also Huatai |
| 27.09.2011 | 2.43 | New | Now also filelength 7A000h at SIM32 |
| 25.07.2011 | 2.42 | New | New Rongwei file |
| 27.05.2011 | 2.41 | New | New file Hyundai 2.0L |
| 12.05.2011 | 2.40 | New | New file: Samand |
| 03.05.2011 | 2.39 | New | New Chevrolet Cruze file |
| 27.04.2011 | 2.38 | New | Wrong identification fixed |
| 24.02.2011 | 2.37 | Fixed | Error at OBD2 files fixed |
| 01.02.2011 | 2.36 | New | Chevrolet Cruze now also file length 1EFE0h |
| 16.11.2010 | 2.34 | Fixed | Recognition fixed MG |
| 05.08.2010 | 2.33 | New | Now also Chevrolet Aveo with Sirius D52 |
| 13.07.2010 | 2.32 | Fixed | Differentiation from Mini improved |
| 12.07.2010 | 2.31 | New | Now also Dacia with length of 5FF0 |
| 18.06.2010 | 2.30 | New | Correction Sirius34 for CMD |
| 20.05.2010 | 2.29 | New | New file Chevrolet Lacetti |
Part-No: OLS250
Description: Checksum correction for Bosch ME7/Mx VAG, BMW, Fiat, Volvo, Porsche, Asia
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 10.07.2025 | 3.11 | Fixed | Fixed a bug that caused a crash. |
| 02.06.2025 | 3.10 | New | New ME7 - China. |
| 23.04.2025 | 3.09 | New | New ME7 - China |
| 24.02.2025 | 3.08 | New | New ME7 China - Recognition changed so that new ECU gets correct elements. |
| 14.01.2025 | 3.07 | New | CS calculation for some more ME7 now also outside the Maparea. |
| 17.12.2024 | 3.06 | Fixed | Changed the order of the CS calculation, which occasionally led to errors. |
| 12.12.2024 | 3.05 | Fixed | Installed missing checksums for some ME7.1.1. |
| 21.10.2023 | 3.04 | New | New Ferrari file |
| 16.11.2021 | 3.03 | New | Now also file length of E0000h at ME7.4.5 |
| 06.10.2021 | 3.02 | New | Bosch ME7 Renault/Peugeot/Citroen - detect only map area files. |
| 20.11.2019 | 3.01 | Fixed | Error correction during detection ME7 Fiat 9.1. |
| 04.11.2019 | 3.00 | New | Reworked completely and all ME7 summarized. Contains now:OLS223, OLS225, OLS232G, OLS241, OLS245, OLS249, OLS250, OLS260 |
| 02.08.2019 | 2.59 | New | New M7.9 file |
| 13.08.2018 | 2.58 | New | ME7.4.x now also with file size of C0000h |
| 15.02.2018 | 2.57 | New | New M7.9.5 file |
| 05.12.2016 | 2.56 | New | For M7.9.52 now also file length of C0000h allowed |
| 27.09.2016 | 2.55 | Fixed | Wrong recognition at M7.9.5 |
| 29.06.2016 | 2.54 | New | Now also file size of E0000h at ME7.4.9 |
| 27.05.2016 | 2.53 | New | New Fiat file |
| 21.01.2015 | 2.52 | Fixed | Exclusion MED7.5.11 - Audi A2 |
| 08.10.2013 | 2.51 | New | New Haima file |
| 30.09.2013 | 2.50 | New | New file Toyota Aygo |
| 10.07.2013 | 2.49 | New | New Buick file |
| 17.01.2013 | 2.48 | Fixed | Problem with compiler setting |
| 13.12.2012 | 2.47 | New | Now also readout protection at Ferrari ME7 |
| 15.11.2012 | 2.46 | New | M7.8.0 now in OLS249 |
| 28.10.2011 | 2.45 | New | CS search updated at ME7-PSA |
| 25.10.2011 | 2.44 | Fixed | Additional checksum disabled |
| 10.10.2011 | 2.43 | Fixed | CRC checksum was not found in a certain file |
| 25.08.2011 | 2.42 | New | Additional CS found in ME7.9.52 |
| 11.08.2011 | 2.41 | Fixed | Compiler error |
| 10.08.2011 | 2.40 | New | Now also China Chery and Geely, which contain only 9B 00 at the beginning |
| 14.02.2011 | 2.39 | New | New Ferrari F599 file |
| 27.08.2010 | 2.37 | New | New files of M7.9.71 |
| 14.07.2010 | 2.36 | New | Now also ME7 KessV2 files |
| 12.05.2010 | 2.35 | New | Test Maserati 2010 |
| 21.04.2010 | 2.34 | Fixed | Problem at Clio V6 1MB files |
| 15.04.2010 | 2.33 | New | New file Toyota Auris |
| 18.03.2010 | 2.32 | New | Now also Alfa ME7.3.2 |
| 06.01.2010 | 2.31 | New | New file M7.9.71 |
Part-No: OLS251
Description: Checksum correction for Bosch BMS BMW 4-Zyl.
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 28.11.2017 | 2.05 | Fixed | Recursion at BMS fixed |
| 23.01.2012 | 2.04 | New | New BMS43 file |
| 02.09.2011 | 2.03 | New | Now also BMS NewGenius files |
| 12.03.2008 | 2.02 | New | Checksum interface updated |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 10.09.2003 | 1.6 | New | Revised |
Part-No: OLS252
Description: Checksum correction for Temic V51/51 MB S/G 400CDI, Temic V51-V88
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 12.03.2008 | 2.01 | New | Checksum interface updated |
| 08.12.2005 | 2.00 | New | New registration |
| 19.09.2003 | 1.7 | New | Revised |
Part-No: OLS253
Description: Checksum correction for Siemens HDI, ECM
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 28.10.2021 | 2.06 | New | Added Siemens ECM Truck. |
| 02.11.2018 | 2.05 | Fixed | Possible crash at defect file fixed |
| 12.03.2008 | 2.04 | New | Checksum interface updated |
| 13.02.2006 | 2.03 | New | New file |
| 20.01.2006 | 2.02 | Fixed | Error at placement of the SPI string |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 30.12.2005 | 2.01 | Fixed | Error messages were not displayed |
| 08.12.2005 | 2.00 | New | New registration |
| 08.11.2005 | 1.11 | New | Now also Citroen C1 |
| 30.03.2004 | 1.10 | New | Now also Peugeot HPI |
Part-No: OLS255
Description: Checksum correction for Bosch MS 6.x Iveco, Scania; MAN Bus, JD
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 22.10.2019 | 2.19 | New | Recognition improved for John Deere 8400 file |
| 27.08.2019 | 2.18 | New | New MAN file |
| 05.07.2016 | 2.17 | New | New Mack file |
| 21.01.2013 | 2.16 | New | Now also file length 2040h at Scania |
| 12.07.2012 | 2.15 | New | Now also Scania MS5 with file length of 10000h |
| 14.12.2011 | 2.14 | New | Now also John Deere 2000h |
| 24.01.2011 | 2.13 | Fixed | Compiler error |
| 19.01.2011 | 2.12 | New | Now also Neoplan 2000h |
| 29.07.2010 | 2.11 | New | Now also EDC5 Scania 460 |
| 03.03.2010 | 2.10 | New | Now also old MAN files with length of 10000h |
| 12.02.2010 | 2.09 | New | New file from Mack |
| 27.01.2010 | 2.08 | New | New file from Mack |
| 21.09.2009 | 2.07 | Fixed | Recognition MAN/Scania improved |
| 26.08.2009 | 2.06 | New | Now also old Scania files with length 2000h |
| 24.08.2009 | 2.05 | New | Now also old MAN files with length 2000h |
| 21.01.2009 | 2.04 | New | Now also file length 8000h |
| 12.03.2008 | 2.02 | New | Checksum interface updated |
| 05.03.2007 | 2.01 | New | Now also Mitsubishi |
| 08.12.2005 | 2.00 | New | New registration |
| 29.08.2005 | 1.26 | Fixed | Problem with sync blocks fixed |
| 03.08.2005 | 1.25 | Fixed | Now with sync blocks |
| 01.07.2005 | 1.24 | New | Synchronisation modified => Now it doesn't matter, which data block is modified |
| 27.01.2004 | 1.23 | New | New file of Renault 440 |
Part-No: OLS258
Description: Checksum correction for Saab Trionic T5, T7, AFM5
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 03.09.2014 | 2.16 | New | New file |
| 06.08.2014 | 2.15 | New | New file |
| 19.11.2013 | 2.14 | New | Automatic detection of special files |
| 18.11.2013 | 2.13 | New | New file |
| 02.07.2013 | 2.12 | New | New file |
| 24.05.2013 | 2.11 | Fixed | Crash fixed |
| 27.07.2012 | 2.09 | New | New file |
| 11.07.2011 | 2.06 | New | New file |
| 26.03.2009 | 2.05 | New | New file |
| 06.02.2009 | 2.04 | New | New file |
| 14.08.2008 | 2.03 | New | New file |
| 12.03.2008 | 2.02 | New | Checksum interface updated |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 22.09.2005 | 1.19 | New | Adjusted to new filet: EC0PP1HC.CBF |
| 11.03.2005 | 1.18 | New | Adjusted to new file |
Part-No: OLS259
Description: Checksum correction for Marelli VW, Skoda, Alfa, Fiat, Maserati, IAW4/5
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 30.09.2022 | 2.75 | New | Marelli IAW4/5: New file. |
| 25.03.2022 | 2.74 | New | Marelli IAW4/5: New file. |
| 23.03.2022 | 2.73 | New | Marelli IAW4/5: New file. |
| 08.02.2021 | 2.72 | New | Now also length of 10000h at MM6LP |
| 12.01.2021 | 2.71 | New | Now also file length BFFC at MM48P |
| 19.06.2020 | 2.70 | New | New MM6LP file |
| 17.07.2019 | 2.69 | New | New IAW7EV file |
| 20.03.2019 | 2.68 | Fixed | Possible crash fixed |
| 12.03.2019 | 2.67 | New | Test MBC |
| 31.10.2018 | 2.66 | New | Now also IAW M3G |
| 07.09.2018 | 2.65 | New | New file |
| 30.04.2018 | 2.64 | Fixed | Error fixed at IAW4SF HW105 |
| 03.04.2017 | 2.63 | Fixed | Wrong recognition fixed at MM6LP |
| 13.03.2017 | 2.62 | New | New Lamborghini file |
| 07.01.2016 | 2.61 | New | Now also IAW 16C4 |
| 21.07.2015 | 2.60 | New | Now also MM6LP with length of 70000h |
| 07.07.2015 | 2.59 | New | New file MV Agusta Brutale |
| 19.03.2015 | 2.58 | New | New file Iveco Daily |
| 19.03.2015 | 2.57 | New | New file |
| 27.02.2015 | 2.56 | New | New file Lamborghini Gallardo |
| 01.10.2013 | 2.55 | Fixed | Wrong area at IAW7SM |
| 27.07.2013 | 2.54 | New | Now also Marelli TCU |
| 21.03.2013 | 2.53 | New | New 4GV files |
| 17.01.2013 | 2.52 | Fixed | Problem with compiler setting |
| 14.01.2013 | 2.51 | New | Alternative file length at IAW5SF |
| 13.12.2012 | 2.50 | New | New MM7GV file |
| 07.12.2012 | 2.49 | New | New IAW6 file |
| 24.10.2012 | 2.48 | New | Now also MM7GV |
| 14.06.2012 | 2.47 | New | Now also 5SF HW220 Tata. |
| 16.05.2012 | 2.46 | Fixed | Error fixed at MM1AP |
| 14.05.2012 | 2.45 | New | Now also IAW4GV |
| 25.04.2012 | 2.44 | Fixed | Error at 4HV |
| 16.04.2012 | 2.43 | New | New file 5SFHW410 and 5DM |
| 04.04.2012 | 2.42 | New | New 4HV file |
| 23.02.2012 | 2.41 | New | Now also IAW5SF HW207 |
| 10.02.2012 | 2.40 | Fixed | Erroneous recognition of IAW8 fixed |
| 05.01.2012 | 2.39 | New | Now also 4CF |
| 13.12.2011 | 2.38 | New | Now also IAW 4CM |
| 02.09.2011 | 2.37 | New | More file lengths at IAW5AM |
| 01.09.2011 | 2.36 | New | Now also IAW5AM and IAW5SM |
Part-No: OLS261
Description: Checksum correction for Bosch Smart CDI
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 12.03.2008 | 2.01 | New | Checksum interface updated |
| 08.12.2005 | 2.00 | New | New registration |
| 10.09.2003 | 1.6 | New | Revised |
Part-No: OLS262
Description: Checksum correction for Bosch ME7 VAG 200x, Patch, RSA
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 02.10.2023 | 3.02 | Fixed | ME7-2002: RSA checksum was not inserted if project was created by Intel hex import |
| 26.11.2020 | 3.01 | Fixed | Software S31 was not detected |
| 04.11.2019 | 3.00 | New | Reworked completely and all ME7 VAG version of the year 2002/2006/2008. Contains now:OLS262 and OLS802 |
| 17.12.2014 | 2.10 | Fixed | Own modifications in RSA were not recognized |
| 19.03.2014 | 2.09 | New | Recognition of another RSA key |
| 18.08.2008 | 2.08 | Fixed | RSA block recognition improved |
| 12.03.2008 | 2.07 | New | Checksum interface updated |
| 23.05.2007 | 2.06 | Fixed | RSA correction improved |
| 04.07.2006 | 2.05 | Fixed | Message that checksum is not correct when switching between versions |
| 07.02.2006 | 2.04 | Fixed | Recognition improved |
| 24.01.2006 | 2.03 | Fixed | Checksum search in already modified file caused error message |
| 09.01.2006 | 2.02 | Fixed | Error messages were not displayed |
| 30.12.2005 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 29.11.2005 | 1.20 | New | New RSA calculation: Now all Audi RS6 are possible |
| 23.02.2005 | 1.19 | New | Now also ME7.5.10 |
Part-No: OLS263
Description: Checksum correction for KEFICO, M798, CPEDG2
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 11.10.2024 | 2.15 | New | New Kefico CPGPSH3/CPEGD3. |
| 25.07.2024 | 2.14 | New | Test Kefico CPGPSH3/CPEGD3 |
| 15.10.2021 | 2.13 | New | New Kefico M7.8.9 identification. |
| 20.09.2021 | 2.12 | New | New Kefico CPEDG2 file size. |
| 20.10.2018 | 2.11 | New | New file Kia Ceed |
| 05.04.2018 | 2.10 | New | New CPEDG2 file |
| 26.07.2016 | 2.09 | Fixed | Element handling forgotten |
| 12.07.2016 | 2.08 | New | Now also CPEDG2 |
| 20.08.2015 | 2.07 | New | Now also file size of E0000h at M7.9.8 |
| 12.03.2008 | 2.06 | New | Checksum interface updated |
| 12.02.2007 | 2.05 | Fixed | Slows down the WinOLS startup |
| 31.01.2007 | 2.04 | New | Recognition improved |
| 07.11.2006 | 2.02 | Fixed | Curious behaviour at changes |
| 07.11.2006 | 2.02 | New | Modified to CAdrCnv |
| 23.03.2006 | 2.01 | New | Now also Kefico M798 |
| 08.12.2005 | 2.00 | New | New registration |
| 10.09.2003 | 1.2 | New | Revised |
Part-No: OLS266
Description: Checksum correction for Bosch ME9-1/2 BMW
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 10.10.2022 | 2.10 | New | Bosch ME9-1 BMW: identifiy small files - only over map area |
| 18.03.2008 | 2.09 | Fixed | Forgot checksum block |
| 12.03.2008 | 2.08 | New | Checksum interface updated |
| 07.11.2006 | 2.07 | Fixed | Curious behaviour at changes |
| 29.08.2006 | 2.06 | Fixed | Error at initialisation |
| 28.08.2006 | 2.05 | New | Modified to CAdrCnv |
| 23.05.2006 | 2.04 | New | BDM readout protection improved |
| 18.05.2006 | 2.03 | Fixed | Block search function improved |
| 22.02.2006 | 2.02 | Fixed | Problem at patch tag blocks fixed |
| 30.12.2005 | 2.01 | New | New placement of the BDM readout protection |
| 08.12.2005 | 2.00 | New | New registration |
| 22.02.2005 | 1.7 | New | Adjusted to new file |
Part-No: OLS267
Description: Checksum correction for Delphi DCI, USA, HDI; Delco Isuzu, Daewo; MPC
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 05.12.2022 | 2.24 | New | New Delphi Isuzu. |
| 21.03.2022 | 2.23 | New | Missing checksums added to Delco USA. |
| 12.08.2021 | 2.22 | New | New file Isuzu Delco |
| 25.05.2020 | 2.21 | New | Added Delco Chevrolet. |
| 30.04.2020 | 2.20 | New | Added Delco Hammer 3. |
| 24.07.2018 | 2.19 | New | Recognition Chevrolet Trailblazer improved |
| 31.03.2017 | 2.18 | New | Now also Isuzu Delco |
| 14.06.2012 | 2.17 | New | New Isuzu file |
| 10.03.2011 | 2.16 | Fixed | Readout protection placement modified at Renault Clio 1.5DCI |
| 23.06.2010 | 2.15 | New | Now also Clio CMD files |
| 12.08.2009 | 2.14 | New | New Daewoo file |
| 12.03.2008 | 2.13 | New | Checksum interface updated |
| 30.05.2007 | 2.12 | New | Isuzu: Now also BDM files |
| 13.04.2007 | 2.11 | New | Isuzu: New file |
| 13.01.2007 | 2.10 | New | Recognition improved |
| 20.12.2006 | 2.09 | New | Now also DCM1.2 readout with Byteshooter |
| 06.09.2006 | 2.08 | New | Now also Renault Clio 1.5DCI readout with KESS |
| 10.08.2006 | 2.07 | New | Now also Cheverolet / Isuzu 3.0TDI |
| 03.07.2006 | 2.05 | New | Now also Renault Modus with file length of 1FFD0h |
| 03.07.2006 | 2.06 | New | Now also Suzuki 1.3 DDiS with file length of 80000h and 90000h |
| 21.03.2006 | 2.04 | New | Now also Delphi with software YDXX |
| 02.03.2006 | 2.03 | New | Now also Daewoo |
| 30.12.2005 | 2.02 | New | New placement of the SPI/BDM readout protection |
| 12.12.2005 | 2.01 | New | Now also Isuzu Trooper 3.0 |
| 12.12.2005 | 2.01 | Fixed | Recognition improved: Citroen C3 HDI readout with BDM |
| 08.12.2005 | 2.00 | New | New registration |
| 20.07.2005 | 1.14 | New | Now also Hummer with software YLXZ |
| 27.05.2005 | 1.13 | New | Now also Chevrolet and Hummer |
| 26.10.2004 | 1.12 | New | Adjusted to new file |
Part-No: OLS269
Description: Checksum correction for Ford WDS, Siemens TDCI. Diesel, EECV
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 29.10.2022 | 2.28 | Fixed | MFC problem fixed |
| 27.06.2022 | 2.27 | New | Visteon EEC-V: Hex-import identification. |
| 02.11.2018 | 2.26 | Fixed | Possible crash at defect file fixed |
| 03.09.2018 | 2.25 | New | Now also SIM29 as hex file |
| 16.07.2016 | 2.24 | New | New SIM28 file |
| 11.02.2015 | 2.23 | New | New file Ford Fiesta Siemens EMS with 0-FFFF 0 |
| 27.07.2012 | 2.22 | New | New Siemens file |
| 01.12.2010 | 2.21 | New | Now also Genius file with length of 70000h at Siemens ECUs |
| 19.06.2010 | 2.20 | Fixed | Problem at checksum search in version at Siemens ECUs fixed |
| 18.06.2010 | 2.19 | Fixed | Recognition modified for Siemens ECUs |
| 15.06.2010 | 2.18 | New | New file Ford Fiesta |
| 12.08.2009 | 2.17 | New | New file Ford Fiesta |
| 07.05.2009 | 2.16 | New | New file Ford Fiesta with vSpire |
| 18.03.2009 | 2.15 | New | New file |
| 30.09.2008 | 2.14 | New | Now also Mondeo with file length of 100000h |
| 08.05.2008 | 2.13 | New | Now also serial files with length 1F800 |
| 12.03.2008 | 2.12 | New | Checksum interface updated |
| 24.10.2007 | 2.11 | New | Now also Siemens files with missing area 0-3FFF |
| 07.08.2007 | 2.10 | Fixed | Redundant sync block removed |
| 10.04.2007 | 2.09 | New | Now also SIM28 serial |
| 05.04.2007 | 2.08 | Fixed | Problem fixed at classic checksum calculation |
| 07.03.2007 | 2.07 | Fixed | Recursion occured at classic checksum calculation |
| 31.08.2006 | 2.06 | New | Checksum offset now taken from original file at EEC V with length 36000h and 38000h |
| 16.06.2006 | 2.05 | New | Now also Ford Ranger with SID901 |
| 28.03.2006 | 2.04 | Fixed | Error at the expansion fixed |
| 16.03.2006 | 2.03 | Fixed | Error at the expansion fixed |
| 12.01.2006 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 02.11.2005 | 1.9 | New | New file Ford Ka |
| 20.05.2005 | 1.8 | New | New file Fiesta 100HP |
| 11.09.2003 | 1.7 | New | Revised |
Part-No: OLS270
Description: Checksum correction for Bosch DME / DDE
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 30.01.2018 | 2.18 | New | BMW DME recognition improved |
| 30.06.2017 | 2.17 | Fixed | MP5.2 wasnt recognized in some files |
| 01.10.2016 | 2.16 | Fixed | Wrong recognition at BMW M3 075 fixed |
| 15.08.2016 | 2.15 | New | Now also MP5.2 |
| 30.12.2014 | 2.14 | New | VW-DDE and BMW-DDE support now two elements: Eprom and Eprom2 |
| 18.12.2014 | 2.13 | New | Support of projects with elements, that means Eprom and EEprom |
| 22.04.2014 | 2.12 | New | Now also file length of 20000h at M2.8 |
| 05.08.2013 | 2.11 | New | Test BMW M3/E36/8000h |
| 26.04.2013 | 2.10 | New | Now also Opel Kadett GSI |
| 17.03.2012 | 2.09 | New | Now also Alfa M2.10.4 |
| 05.01.2012 | 2.08 | New | Now also BMW 0261200402 |
| 01.09.2010 | 2.05 | New | Now also FIAT Punto 1.4T ignition and boost |
| 27.07.2010 | 2.04 | New | BMW M3 with Bosch ECU |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 23.02.2008 | 2.02 | New | Test MAN DDE with file length 10000h |
| 19.02.2008 | 2.01 | New | Now also Peugeot MP5.1 |
| 08.12.2005 | 2.00 | New | New registration |
| 28.07.2005 | 1.6 | New | Now also Fiat M2.104 |
| 10.09.2003 | 1.5 | New | Revised |
Part-No: OLS271
Description: Checksum correction for Siemens SMG/EGS, EML, Rotax, EGS53, EGS51; Opel Automatic
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 30.03.2021 | 2.21 | New | Additional file size at Siemens SMG/EGS of 6FFF0 from CFF Import |
| 01.12.2020 | 2.20 | New | Additional file size of C0000h at EGS53 |
| 02.11.2018 | 2.19 | Fixed | Possible crash at defect file fixed |
| 05.04.2017 | 2.18 | New | New file of EGS53: Jeep Wrangler |
| 08.03.2016 | 2.17 | New | Test2: EGS51 |
| 04.11.2015 | 2.16 | New | Test: EGS51 Mercedes |
| 29.08.2012 | 2.15 | New | New EGS52 file |
| 08.03.2012 | 2.14 | Fixed | Error in the calculation of Siemens-Rotax |
| 31.01.2012 | 2.13 | New | Additional CS in Rotax |
| 14.10.2011 | 2.12 | Fixed | Compiler error |
| 29.08.2011 | 2.11 | New | Additional CS found at EGS52/53 |
| 27.07.2009 | 2.10 | New | Now also Porsche 996 Tiptronic |
| 12.03.2008 | 2.09 | New | Checksum interface updated |
| 22.01.2008 | 2.08 | New | Now also 1mb files |
| 18.01.2008 | 2.07 | Fixed | Additional CS block found at MB EGS52 |
| 15.01.2008 | 2.06 | New | Now also BMW M5-V10 SMG gear shift controller |
| 12.12.2007 | 2.05 | New | New: Mercedes automatic gearshift |
| 23.09.2007 | 2.04 | Fixed | Wrongly calculated block removed |
| 08.07.2007 | 2.03 | New | Test: Opel automatic |
| 25.05.2007 | 2.02 | New | New: Siemens MSE3.7: Rotax Bombadier |
| 05.04.2007 | 2.01 | New | New BMW E38 750i EML |
| 08.12.2005 | 2.00 | New | New registration |
| 10.09.2003 | 1.1 | New | Revised |
Part-No: OLS272
Description: Checksum correction for Bosch Kia
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 12.03.2008 | 2.01 | New | Checksum interface updated |
| 08.12.2005 | 2.00 | New | New registration |
| 03.08.2005 | 1.3 | Fixed | Problem with sync blocks fixed |
| 08.03.2005 | 1.2 | New | Adjusted to new file |
Part-No: OLS273
Description: Checksum correction for Bosch Smart 006 (Only for serial programming)
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 30.05.2006 | 2.02 | Fixed | Under LUA the patches were not inserted |
| 09.01.2006 | 2.01 | Fixed | Under certain circumstances patches were not inserted |
| 08.12.2005 | 2.00 | New | New registration |
| 16.11.2005 | 1.12 | New | New file 365131 |
| 16.10.2005 | 1.11 | New | Now recognizes data blocks automatically |
| 21.03.2005 | 1.9 | New | New file 371568 |
Part-No: OLS274
Description: Checksum correction for Phoenix VP44, CR, MPC/ST10, UIC3; John Deere EST50
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 23.04.2025 | 2.40 | New | New Phoenix MPC/ST10. |
| 10.12.2022 | 2.39 | Fixed | Compiler error |
| 06.12.2022 | 2.38 | New | New file |
| 14.06.2022 | 2.37 | Fixed | Bugs fixed. |
| 10.06.2022 | 2.36 | New | Phoenix MPC/ST10: patchblock moved. |
| 23.03.2020 | 2.35 | New | Now also file length of 400000h at L33 |
| 25.10.2019 | 2.34 | New | Now also file length of 100000h at Phoenix L33 |
| 05.04.2017 | 2.33 | New | Now also L21 with size of 200000h |
| 01.02.2017 | 2.32 | New | New L16 file |
| 06.09.2015 | 2.31 | New | Now also L33 |
| 14.04.2014 | 2.30 | New | New L14 file |
| 18.07.2013 | 2.29 | New | Recognition improved for L21 |
| 09.03.2012 | 2.28 | Fixed | Identification Phoenix MPC/ST10 modified |
| 08.02.2012 | 2.27 | New | Now also EST50 |
| 31.05.2010 | 2.26 | New | New file VP44 |
| 19.05.2010 | 2.25 | New | New L15 file |
| 18.03.2010 | 2.24 | New | Now also OBD2 files from ST10 ECUs |
| 05.03.2010 | 2.23 | New | New file Deere ST10 |
| 01.12.2009 | 2.22 | New | Now also L14 CMD/Dimsport files |
| 22.09.2008 | 2.21 | Fixed | Recognition modified |
| 05.08.2008 | 2.20 | Fixed | Short P273 files were not recognized |
| 29.07.2008 | 2.19 | New | Recognition of serial files modified |
| 15.07.2008 | 2.18 | New | Now also J341 |
| 19.06.2008 | 2.17 | New | Now also P292 |
| 15.05.2008 | 2.16 | New | Now also P210 |
| 11.04.2008 | 2.15 | New | New file L14 |
| 27.03.2008 | 2.14 | New | New file |
| 20.03.2008 | 2.13 | New | New file |
| 12.03.2008 | 2.12 | New | Checksum interface updated |
| 11.03.2008 | 2.11 | New | Recognition modified + now also L14 Byteshooter files |
| 28.02.2008 | 2.10 | New | Now also serial VP44 files |
| 31.01.2008 | 2.09 | New | Recognition of serial L11 files modified |
| 15.01.2008 | 2.08 | New | Now also Phoenix CR Byteshooter files. |
| 11.12.2007 | 2.07 | New | Now also L12 as serial file |
| 11.10.2007 | 2.05 | New | Now also L14 with ST10 controller |
| 14.03.2007 | 2.04 | New | New file |
| 13.01.2007 | 2.03 | New | Now also Phoenix with MPC5xx |
| 21.12.2006 | 2.02 | New | New file |
| 09.06.2006 | 2.01 | New | New file |
| 08.12.2005 | 2.00 | New | New registration |
Part-No: OLS275
Description: Checksum correction for Lucas Volvo, FHK2, Ford, Hyundai. Fiat
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 06.12.2013 | 2.14 | New | Recognition modified |
| 11.10.2011 | 2.13 | New | Now also file size 8040h at FHK2 |
| 16.03.2010 | 2.12 | New | Now also KESSv2 FHK2 files |
| 20.11.2009 | 2.11 | New | New file Ford Transit |
| 21.09.2009 | 2.10 | New | Recognition of the correct file length improved |
| 12.08.2009 | 2.09 | Fixed | Errornous recognition fixed |
| 08.05.2009 | 2.08 | New | Now also 20000h long Ford 2.5D files |
| 08.08.2008 | 2.07 | New | Now also Hyundai truck |
| 02.06.2008 | 2.05 | Fixed | Readout protection corrected |
| 12.03.2008 | 2.04 | New | Checksum interface updated |
| 18.01.2008 | 2.03 | New | Now also Byteshooter files at FHK2 |
| 24.11.2006 | 2.02 | New | Ford 2.5TD |
| 10.05.2006 | 2.01 | New | New file |
| 08.12.2005 | 2.00 | New | New registration |
| 22.01.2004 | 1.7 | New | Adjusted to new file |
Part-No: OLS276
Description: Checksum correction for TEMIC Mercedes Actros, Atego, Axor
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 10.12.2021 | 2.34 | New | Revised. |
| 06.07.2015 | 2.33 | New | New file |
| 30.11.2013 | 2.32 | New | New file |
| 05.10.2012 | 2.31 | Fixed | Wrong identification fixed |
| 21.09.2012 | 2.30 | Fixed | Error in V5 fixed |
| 02.05.2012 | 2.28 | Fixed | Error in recognition fixed |
| 21.11.2011 | 2.27 | New | Test2 with new file |
| 14.07.2011 | 2.26 | New | Test with new file |
| 14.10.2010 | 2.25 | New | New V5 file: 11C |
| 24.09.2010 | 2.24 | New | New file V2 |
| 14.05.2010 | 2.23 | Fixed | Error fixed |
| 12.05.2010 | 2.22 | New | New file V1 |
| 27.01.2010 | 2.21 | New | New V4 file |
| 26.01.2010 | 2.20 | New | New file |
| 03.07.2009 | 2.19 | Fixed | Problem fixed |
| 27.05.2009 | 2.18 | New | New file |
| 19.02.2009 | 2.17 | New | Recognition modified |
| 02.09.2008 | 2.16 | New | New file |
| 29.04.2008 | 2.15 | New | Now also V2 in 80000h long files. |
| 12.03.2008 | 2.14 | New | Checksum interface updated |
| 16.02.2008 | 2.13 | New | Recognition V1 modified |
| 14.11.2007 | 2.12 | New | New file |
| 09.11.2007 | 2.11 | New | New file |
| 26.09.2007 | 2.10 | New | New file |
| 30.08.2007 | 2.08 | New | New file |
| 07.08.2007 | 2.07 | New | Now also brasilian files |
| 28.07.2007 | 2.06 | New | New file |
| 08.11.2006 | 2.05 | New | Now also Doppstadt files |
| 05.05.2006 | 2.04 | Fixed | Patch didn't work |
| 04.05.2006 | 2.03 | New | New file |
| 27.03.2006 | 2.02 | New | New file |
| 25.05.2005 | 1.10 | New | New file |
| 25.04.2005 | 1.9 | New | Now also Atego with data at 20000h |
Part-No: OLS278
Description: Checksum correction for Scania HPI, EMS S7/8, ACM
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 05.12.2022 | 2.16 | New | New Scania S8 Files. |
| 26.01.2022 | 2.15 | New | Additional file length of 200400h at ACM |
| 11.03.2021 | 2.14 | New | Additional Scania S8 identification. |
| 13.11.2020 | 2.13 | New | Improved the Scania S7 checksum |
| 22.10.2020 | 2.12 | New | Additional checksum for Scania S8. |
| 16.10.2020 | 2.11 | New | Improved detection for S8. |
| 17.04.2020 | 2.10 | Fixed | Bugfix |
| 16.04.2020 | 2.09 | New | Add Scania AMD. |
| 30.04.2018 | 2.08 | New | Now also file size of 80200h |
| 21.11.2017 | 2.07 | Fixed | Problem at S6 fixed |
| 15.03.2014 | 2.06 | New | Now also XPI files |
| 29.07.2009 | 2.05 | New | Now also V1 CMD files |
| 10.11.2008 | 2.04 | New | Now also V2 CMD files |
| 23.09.2008 | 2.03 | New | Now also new HPI ECUs |
| 12.03.2008 | 2.02 | New | Checksum interface updated |
| 03.01.2006 | 2.01 | New | New placement of the BDM readout protection |
| 08.12.2005 | 2.00 | New | New registration |
| 17.10.2005 | 1.1 | New | New: Scania HPI |
Part-No: OLS279
Description: Checksum correction for Bosch PSG16, RSA
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 23.06.2021 | 2.17 | Fixed | Error in end value detection fixed, New detection of map-only files with size of DFF00h |
| 11.06.2021 | 2.16 | New | Identification expanded. |
| 30.07.2018 | 2.15 | New | New Saab file |
| 12.10.2017 | 2.14 | New | Recognition of Saab files improved |
| 22.11.2016 | 2.13 | New | New file |
| 20.09.2016 | 2.12 | New | New Saab file |
| 18.05.2016 | 2.11 | New | New Saab file |
| 01.08.2014 | 2.10 | New | New file |
| 28.07.2014 | 2.09 | New | Now also Saab files and 2MB files |
| 22.10.2013 | 2.08 | New | Now also file length of 80000h |
| 20.12.2011 | 2.07 | Fixed | Update |
| 26.01.2009 | 2.06 | Fixed | Wrong element size caused wrong export file size |
| 12.03.2008 | 2.05 | New | Checksum interface updated |
| 23.05.2007 | 2.04 | Fixed | RSA correction improved |
| 23.05.2006 | 2.03 | New | BDM readout protection improved |
| 10.04.2006 | 2.01 | New | New |
| 08.12.2005 | 0 | New | New registration |
Part-No: OLS280
Description: Checksum correction for Siemens SID803, SID201/204, SID202, SIDxxx, SID9xx, EasyU
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 30.06.2025 | 2.61 | Fixed | Troubleshooting. |
| 28.05.2025 | 2.60 | New | New SID902. |
| 06.11.2024 | 2.59 | New | SID603 installed. |
| 16.09.2024 | 2.58 | New | New SID9xx. |
| 24.08.2023 | 2.57 | New | New size. |
| 17.01.2023 | 2.56 | New | New SID9xx identification. |
| 07.11.2022 | 2.55 | Fixed | Bug fix that causes errors on some files. |
| 27.10.2022 | 2.54 | New | SID908: Special handling of ZENC files |
| 17.08.2022 | 2.53 | New | Crash fixed |
| 20.06.2022 | 2.52 | New | New file size Siemens SID9xx. |
| 24.02.2022 | 2.51 | New | SID9xx - bug fixed in connection with Zenc import. |
| 28.04.2021 | 2.50 | New | File size of SID904/SID913/SID914 now 880000h - 980000h |
| 26.04.2021 | 2.49 | New | Now also SID904 with filesize of 8BFF80h |
| 24.11.2020 | 2.48 | New | Chinese ECU with file length of 180000h |
| 16.03.2020 | 2.47 | New | Additional file length at SID908 |
| 05.03.2020 | 2.46 | New | New file length for Siemens SID9xx. |
| 08.11.2019 | 2.45 | New | Handling of SID9xx files improved |
| 22.03.2019 | 2.44 | New | Now also SID914 with size of 480000h |
| 21.02.2019 | 2.43 | New | SID804/904 also as 280000h binary file |
| 24.01.2019 | 2.42 | Fixed | Ford Territory SID204 identified as SID202 by error |
| 11.07.2018 | 2.41 | New | SID902/904: File size now also 400000h |
| 27.03.2018 | 2.40 | New | Now also EasyU in Iran Khodro 207 |
| 13.07.2016 | 2.38 | New | Now also filesize of 1BD080h at SID301 |
| 28.12.2015 | 2.37 | New | Now also SID904 |
| 30.10.2015 | 2.36 | New | SID803: Possible processor size now 70000h - 710000h |
| 30.05.2014 | 2.35 | Fixed | Invalid elements will not be inserted into the element list |
| 04.02.2013 | 2.34 | Fixed | Element recognition did not work at some vbf files |
| 14.10.2011 | 2.33 | New | Now also only data area at SID902 |
| 24.11.2010 | 2.32 | New | Now also SID803A Genius file |
| 21.04.2010 | 2.31 | New | Now also SID201 mit 4MB eprom |
| 07.04.2010 | 2.30 | New | Now also 9MB Optican file |
| 18.03.2010 | 2.29 | New | Now also SID 803 Genius files |
| 23.02.2010 | 2.28 | New | Expecially for Markus |
| 13.07.2009 | 2.27 | New | New VBF file |
| 13.05.2009 | 2.26 | Fixed | Recognition modified |
| 12.02.2009 | 2.25 | New | Placement of the readout protection changed at SID202 |
| 26.01.2009 | 2.24 | New | Now also Landrover SID201 from VBF file |
| 04.12.2008 | 2.23 | New | Further file Volvo SID803 |
| 27.10.2008 | 2.22 | New | SID803 recognition adjusted to OLS1001 |
| 21.05.2008 | 2.21 | New | Place for readout protection modified at SID803 |
Part-No: OLS283
Description: Checksum correction for Sagem 2000 / 3000, S2000PM2; Valeo
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 10.05.2023 | 2.34 | New | Now also S2000PL4FC5 with length of 90000h |
| 18.10.2022 | 2.33 | New | New Valeo file |
| 02.10.2018 | 2.32 | New | Now also Valeo V46 |
| 23.08.2018 | 2.31 | New | Test: Valeo VD46 |
| 23.01.2018 | 2.30 | New | New Valeo file |
| 16.01.2018 | 2.29 | New | Valeo recognition improved |
| 15.01.2018 | 2.28 | New | Now also Valeo V40 |
| 08.07.2016 | 2.27 | New | J34 recognition improved |
| 26.01.2016 | 2.26 | New | Now also Valeo J34 Galetto files |
| 11.06.2015 | 2.25 | New | New file |
| 11.05.2015 | 2.24 | New | Now also files with length of 10000h at Sagem3000 |
| 09.07.2014 | 2.23 | New | Now also FGtech files with port area present |
| 31.01.2014 | 2.22 | New | New Valeo files |
| 05.11.2012 | 2.21 | Fixed | Recognition improved for S2000PM2 |
| 27.02.2012 | 2.20 | New | New Valeo file |
| 07.12.2011 | 2.19 | New | Now also file length 1FF80h at Sagem 3000 |
| 02.08.2011 | 2.18 | New | Now also Sagem3000 with file length 70000h MPPS |
| 11.07.2011 | 2.17 | New | Now also Sagem3000 with length of DFF00h |
| 15.06.2011 | 2.16 | New | Now also Sagem3000 with length of 1FF00h |
| 30.03.2011 | 2.15 | Fixed | Recognition modified |
| 02.09.2010 | 2.14 | New | Now also Fiat with Valeo |
| 06.08.2010 | 2.13 | New | Now also Sagem3000 with length of 100000h - Serial Suite Piasiniengineering |
| 23.06.2010 | 2.12 | New | Recognition modified for Valeo |
| 16.06.2010 | 2.11 | New | Recognition modified for Valeo |
| 17.05.2010 | 2.10 | New | New Valeo file |
| 22.04.2010 | 2.09 | New | New file of Valeo + Sagem |
| 27.10.2009 | 2.08 | New | Now also J34P Byteshooter files |
| 26.10.2009 | 2.07 | New | Now also VALEO J34P |
| 12.03.2008 | 2.06 | New | Checksum interface updated |
| 22.08.2007 | 2.05 | New | Now also S2000PM2 |
| 11.12.2006 | 2.04 | New | Recognition modified for files with length 40000h |
| 16.05.2006 | 2.03 | New | Recognition modified for S2000RPM |
| 07.02.2006 | 2.02 | New | Recognition modified for S3000 |
| 03.01.2006 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 21.01.2005 | 1.5 | New | New address for SPI string in Sagem 3000 |
Part-No: OLS284
Description: Checksum correction for Delphi Ford, Ford 2, Korea
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 27.10.2022 | 2.15 | Fixed | MPC problem fixed |
| 05.09.2017 | 2.14 | New | Now also Delphi Jaguar files with size of F0000h without elements can be processed |
| 04.02.2009 | 2.13 | Fixed | Problem at expansion fixed |
| 12.03.2008 | 2.12 | New | Checksum interface updated |
| 23.08.2007 | 2.11 | Fixed | Bug fixed in Delphi-Korea |
| 22.08.2007 | 2.10 | Fixed | Recognition improved at new Mondeo ECUs |
| 16.08.2007 | 2.09 | Fixed | Eprom was not recognized in Jaguar ECUs |
| 08.07.2007 | 2.08 | New | Now also new Mondeo files |
| 29.12.2006 | 2.07 | New | Delphi Korea: Now also serial files with length FFF0 |
| 15.11.2006 | 2.06 | New | New file Jaguar 2.0D |
| 14.11.2006 | 2.05 | Fixed | Crash at loading under Win2000 |
| 26.10.2006 | 2.04 | New | Now also Ford Transit |
| 11.05.2006 | 2.03 | Fixed | Online CS test improved |
| 12.01.2006 | 2.02 | New | New placement of the BDM readout protection |
| 12.12.2005 | 2.01 | Fixed | Fixed: Wrong recognition of Citroen C3 HDI |
| 08.12.2005 | 2.00 | New | New registration |
| 06.12.2005 | 1.14 | New | New file Ssany Yong |
| 30.08.2005 | 1.13 | Fixed | Problem with recognition of elements fixed |
| 25.08.2005 | 1.12 | Fixed | Problem with sync blocks fixed |
| 02.08.2005 | 1.11 | Fixed | Problem with sync blocks fixed |
| 13.05.2005 | 1.10 | New | Now also Ford Tourneo TDCI |
| 30.03.2005 | 1.9 | New | Now expansion of Ford WDS files |
Part-No: OLS285
Description: Checksum correction for Bosch EDC16V2, EEPROM, RSA, Comp-Patch
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 07.05.2024 | 2.80 | New | Singe binary file of 28.0000 - 2 elements, Intel-Hex with #1, #2 - Renaming of elements, Bootloader-CS |
| 16.02.2023 | 2.79 | New | Change of internal data. |
| 26.05.2021 | 2.78 | Fixed | Problem with compiler setting |
| 19.06.2019 | 2.77 | Fixed | Error in EEprom block search fixed |
| 26.03.2019 | 2.76 | New | EEprom block search improved |
| 21.09.2015 | 2.75 | New | New key for Toyota |
| 07.07.2015 | 2.74 | New | New key for MB Sprinter |
| 01.09.2014 | 2.73 | New | Exception of Iveco Daily |
| 22.10.2013 | 2.72 | Fixed | Exclusion of PSG16 files with length of 80000h |
| 17.01.2013 | 2.71 | Fixed | Problem with compiler setting |
| 20.12.2012 | 2.70 | Fixed | Mitsubishi Canter excluded |
| 21.09.2012 | 2.69 | Fixed | Iveco Daily was not identified |
| 30.08.2012 | 2.68 | New | UAZ Patriot excluded |
| 25.07.2012 | 2.67 | Fixed | Improved support of EDC16C31 only data area in 1MB file |
| 30.05.2012 | 2.66 | New | New key for Hyundai |
| 29.05.2012 | 2.65 | New | New key for Ford |
| 29.03.2012 | 2.64 | Fixed | Possible crash at defect file fixed |
| 02.02.2012 | 2.63 | Fixed | Erroneous message if no RSA |
| 11.01.2012 | 2.62 | Fixed | Recognition of already modified files improved: Error message |
| 16.11.2010 | 2.61 | Fixed | Identification improved for EDC16/EDC7: Mitsubishi Fuso |
| 26.10.2010 | 2.60 | New | New key for Smart |
| 19.10.2010 | 2.59 | New | New Ford key |
| 03.11.2009 | 2.58 | New | EEprom checksum improved |
| 07.10.2009 | 2.57 | New | New RSA key |
| 14.05.2009 | 2.56 | Fixed | DLL loading problem |
| 12.05.2009 | 2.55 | New | Now also Dodge serial files |
| 15.04.2009 | 2.54 | New | Recognition of empty areas also at contents 00 |
| 09.04.2009 | 2.53 | Fixed | If no processor contents present, dont insert an invalid processor element |
| 25.03.2009 | 2.52 | Fixed | Readout protection now in last logical block |
| 23.01.2009 | 2.51 | New | Possible request for compatibility test checksum now via checkbox |
| 27.11.2008 | 2.50 | New | New key inserted for Volvo |
| 08.05.2008 | 2.49 | New | Now also vSpire BMW files |
| 02.05.2008 | 2.48 | Fixed | Patch was displayed |
| 24.04.2008 | 2.47 | New | Problem solved at files, where the area 0-3FFFF is empty |
| 31.03.2008 | 2.46 | Fixed | Problem fixed, that sometimes one checksum is not corrected |
| 12.03.2008 | 2.45 | New | Checksum interface updated |
| 20.02.2008 | 2.44 | New | Now file length from 1E000h |
| 07.12.2007 | 2.43 | Fixed | Problem fixed |
| 28.11.2007 | 2.42 | New | Now also Nissan Patrol EDC16C41 |
| 15.10.2007 | 2.41 | Fixed | EDC16UC40 was recognized by mistake |
Part-No: OLS286
Description: Checksum correction for Bosch ME9 - Ford/Volvo, RSA
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 15.10.2013 | 2.31 | Fixed | Correct handling of short AG files |
| 17.01.2013 | 2.30 | Fixed | Problem with compiler setting |
| 14.12.2012 | 2.29 | Fixed | Error at VBF files fixed |
| 21.09.2012 | 2.28 | Fixed | Wrong identification of Ford Kuga fixed |
| 30.07.2012 | 2.27 | Fixed | Better error message at Genius OBD2 AG file |
| 17.01.2012 | 2.26 | New | Recognition of SW versions improved + CJ OBD2 solution |
| 17.05.2011 | 2.25 | Fixed | Problem fixed at AG software |
| 29.03.2011 | 2.24 | Fixed | Problem at AG software |
| 25.02.2011 | 2.23 | Fixed | Old files was not recognized any more |
| 22.02.2011 | 2.22 | Fixed | Handling of Focus RS files improved |
| 17.12.2008 | 2.21 | Fixed | Adjusted to OLS1001 |
| 10.12.2008 | 2.20 | New | Modified for use with OLS1001 |
| 07.05.2008 | 2.19 | New | Now at software 393284 again OBD2 programming possible |
| 12.03.2008 | 2.18 | New | Checksum interface updated |
| 12.12.2007 | 2.17 | New | Now also file 393284 |
| 10.08.2007 | 2.16 | New | Now also S-MAX vSpire files. |
| 23.05.2007 | 2.15 | Fixed | RSA correction improved |
| 12.02.2007 | 2.14 | Fixed | Slows down the WinOLS startup |
| 23.01.2007 | 2.13 | New | Placement of patch tag block changed |
| 29.12.2006 | 2.12 | New | Placement of patch tag block changed |
| 27.11.2006 | 2.11 | New | Now also files with RSA checksum |
| 07.11.2006 | 2.10 | Fixed | Curious behaviour at changes |
| 07.08.2006 | 2.09 | New | Now also file length 1D0000h ( Byteshooter ) |
| 07.08.2006 | 2.09 | New | Modified to CAdrCnv |
| 23.05.2006 | 2.08 | New | BDM readout protection improved |
| 18.05.2006 | 2.07 | Fixed | Block search function improved |
| 10.04.2006 | 2.06 | Fixed | Recognition improved |
| 03.04.2006 | 2.05 | Fixed | Recognition modified |
| 22.03.2006 | 2.04 | New | Now also serial files for Ford Focus ST |
| 16.03.2006 | 2.03 | New | Additional CS in Ford Focus ST |
| 22.02.2006 | 2.02 | Fixed | Problem at patch tag blocks fixed |
| 30.12.2005 | 2.01 | New | New placement of the BDM readout protection |
| 08.12.2005 | 2.00 | New | New registration |
| 11.11.2005 | 1.5 | New | New file 378731 |
| 02.06.2005 | 1.4 | New | New file 374870 |
| 23.07.2004 | 1.2 | New | New |
Part-No: OLS287
Description: Checksum correction for Motorola MEMS3 - MG, Rover, Land Rover, MEMS3-PLCC
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 07.06.2024 | 2.11 | New | New file layout MEMS3 |
| 28.11.2008 | 2.10 | New | Problem with old version |
| 01.09.2008 | 2.09 | New | Now also MEMS3 with PLCC eproms |
| 29.08.2008 | 2.08 | New | Recognition modified |
| 15.07.2008 | 2.07 | New | New file |
| 12.03.2008 | 2.06 | New | Checksum interface updated |
| 18.02.2008 | 2.05 | Fixed | Error at recognition of file length 4000h |
| 21.12.2007 | 2.04 | New | Now also Nanocom file |
| 30.08.2007 | 2.03 | New | New file |
| 03.01.2006 | 2.02 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 24.02.2005 | 1.7 | New | Neuer Datenstand |
Part-No: OLS288
Description: Checksum correction for Bosch MED9 - VAG, EEPROM, RSA, VAG-R
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 25.01.2023 | 2.53 | Fixed | Missing EEPROM identification of some files. |
| 21.01.2022 | 2.52 | New | New Bosch MED9 VAG file size. |
| 20.08.2021 | 2.51 | Fixed | Problem at WinOLS startup fixed |
| 26.03.2019 | 2.50 | New | EEprom block search improved |
| 13.04.2018 | 2.49 | New | New file |
| 07.03.2018 | 2.48 | New | Continue even if no RSA solution is found |
| 09.02.2016 | 2.47 | Fixed | Possible buffer overrun fixed |
| 14.10.2015 | 2.46 | New | Now also processor elements with 80200h |
| 07.07.2015 | 2.45 | New | Now also processor elements with a size of 81000h are recognized |
| 14.01.2015 | 2.44 | New | Test: EEprom checksum calculation implemented |
| 10.11.2014 | 2.43 | Fixed | Possible crash fixed |
| 28.05.2014 | 2.42 | New | Automatically select -all elements- at binary files which contain multiple elements |
| 09.10.2012 | 2.41 | Fixed | Recognition of already modified RSA results improved |
| 11.06.2012 | 2.40 | New | New file |
| 21.12.2011 | 2.39 | New | New Audi R8 file |
| 23.08.2011 | 2.38 | New | Additional checksum found in VW Passat |
| 11.07.2011 | 2.37 | New | New RSA key for MED9.1.2 |
| 23.03.2011 | 2.36 | Fixed | Problem at recognition of SPI-Wizard files fixed |
| 21.03.2011 | 2.35 | New | New file TTRS-2011 |
| 18.11.2010 | 2.34 | New | Test Audi TTRS-2011 |
| 17.02.2010 | 2.33 | New | Now also Genius files with length of 27C000h |
| 07.12.2009 | 2.32 | New | New file |
| 20.04.2009 | 2.31 | Fixed | Recognition of additive blocks improved |
| 09.04.2009 | 2.30 | Fixed | If no processor contents present, dont insert an invalid processor element |
| 04.02.2009 | 2.29 | New | New file |
| 13.10.2008 | 2.28 | New | Now also Katana files |
| 29.07.2008 | 2.27 | New | New file |
| 12.03.2008 | 2.26 | New | Checksum interface updated |
| 10.08.2007 | 2.25 | Fixed | Recognition improved for 374614 |
| 07.06.2007 | 2.24 | New | Now also Audi S8 V10 |
| 06.06.2007 | 2.23 | New | Revised completely |
| 23.05.2007 | 2.22 | Fixed | RSA correction improved |
| 08.05.2007 | 2.21 | Fixed | Problem at MED9.1 Passat 3.2L fixed |
| 02.04.2007 | 2.20 | Fixed | Problem at MED9.1 Q7 3.6L fixed |
| 04.01.2007 | 2.19 | Fixed | Problem at MED9.5.10 fixed |
| 07.11.2006 | 2.18 | Fixed | Curious behaviour at changes |
| 30.10.2006 | 2.17 | Fixed | Error at new MED9.5.10 files fixed |
| 10.10.2006 | 2.16 | New | Now also Passat 3.2L / 3.6L FSI |
| 29.08.2006 | 2.15 | Fixed | Error at initialisation |
| 28.08.2006 | 2.14 | New | Modified to CAdrCnv |
Part-No: OLS289
Description: Checksum correction for SISU EEM2; Siemens CLAAS/Mercury; Motorola CM570, CM850, CM87X; Deutz; VDO-FMGR, VDO_ECS; Liebherr; CAT ADEM3/4/5/6, CAT PCMFP; New Holland GD, Charger
CM850 is not yet complete
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 27.06.2025 | 2.92 | Fixed | Troubleshooting |
| 06.11.2024 | 2.91 | New | New ADEM file size. |
| 09.09.2024 | 2.90 | New | Nee ADEM3. |
| 23.08.2024 | 2.89 | New | More ADEM4/5/6 files. |
| 07.08.2024 | 2.88 | New | New CM850. |
| 06.08.2024 | 2.87 | New | New CM850. |
| 27.06.2024 | 2.86 | New | New file size Adem6. |
| 24.06.2024 | 2.85 | New | New CM850. |
| 18.05.2024 | 2.84 | Fixed | Reverted the change to the CS compensation position because it does not work in all affected files |
| 15.05.2024 | 2.83 | New | ADEM 4/5/6 now also length B8000 |
| 07.05.2024 | 2.82 | New | New file size for Adem. |
| 09.04.2024 | 2.81 | New | New CM8xxx. |
| 11.03.2024 | 2.80 | New | CM876 xcal import file. |
| 29.01.2024 | 2.79 | New | Caterpiller PCMFP .fls import file size 0x60000 installed. |
| 05.12.2023 | 2.78 | New | Automatically add elements. |
| 14.11.2023 | 2.77 | New | New CM850. |
| 29.09.2023 | 2.76 | New | New Motorola CM850. |
| 21.09.2023 | 2.75 | New | New Adem 4 size. |
| 19.09.2023 | 2.74 | New | New Adem4 size. |
| 07.07.2023 | 2.73 | New | New file size Adem6. |
| 30.06.2023 | 2.72 | New | New size Adem4/5. |
| 30.05.2023 | 2.71 | New | CM850 improved identification |
| 05.05.2023 | 2.70 | New | Revision for xcal imports. |
| 21.03.2023 | 2.69 | New | New Adem3 size. |
| 07.02.2023 | 2.68 | New | New Adem3 size. |
| 24.10.2022 | 2.67 | Fixed | Addresses adjusted. |
| 07.10.2022 | 2.66 | New | ADEM4/5 back to old balance address |
| 07.10.2022 | 2.65 | Fixed | Recursion fixed |
| 04.10.2022 | 2.64 | New | New file size C0000 for ADEM3 |
| 21.06.2022 | 2.63 | New | New file size for ADEM4/5. |
| 08.06.2022 | 2.62 | New | New file for Cumins 850. |
| 31.05.2022 | 2.61 | New | New CM850 File. |
| 21.04.2022 | 2.60 | New | New file size ADEM3. |
| 28.03.2022 | 2.59 | New | New file size for ADEM4/5/6 |
| 02.03.2022 | 2.58 | Fixed | Bug fix in programcode which causes wrong idetifications. |
| 01.03.2022 | 2.57 | New | New SW data for ADEM6. |
| 02.02.2022 | 2.56 | New | New file size for ADEM6 0x800000 |
| 23.12.2021 | 2.55 | New | New file. |
| 22.12.2021 | 2.54 | New | New File |
| 19.04.2021 | 2.53 | Fixed | At ADEM4/5 a possible processor element was not taken into account |
Part-No: OLS290
Description: Checksum correction for Bosch EDC7C1/3, FB, EDC7U, EDC7UC, EDC7 RSA, EEPROM, EDC7+, EDC7 DAF
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 22.10.2024 | 2.97 | Fixed | Bug fix that could cause in the EEPROM to crash. |
| 23.09.2024 | 2.96 | New | EEPROM for EDC7C1/3 and EDC7U improved. |
| 24.07.2024 | 2.95 | Fixed | Fixed a bug that caused the plugin to crash. |
| 25.06.2024 | 2.94 | Fixed | Fixed wrong address from configuration element. |
| 25.06.2024 | 2.93 | New | Configurations element is now found and installed. |
| 13.11.2023 | 2.92 | Fixed | Fixed incorrect detection. |
| 07.03.2023 | 2.91 | New | EEPROM for EDC7+ revised. |
| 06.02.2023 | 2.90 | New | EEPROM correction for EDC7+ |
| 03.12.2021 | 2.89 | New | Performance improvement. |
| 28.06.2021 | 2.88 | New | EEPROM for EDC7C1/3 too. |
| 20.11.2019 | 2.87 | Fixed | EDC7 Mack: Copy of map area was not detected |
| 07.11.2019 | 2.86 | New | Handling of EDC7U1 Dimsport DTF files with length of 170000h improved |
| 26.03.2019 | 2.84 | New | EEprom block search improved |
| 22.03.2019 | 2.83 | New | New: EEprom checksum at most of the EDC7 types |
| 06.03.2019 | 2.82 | New | Additional checksum in EDC7+ |
| 12.02.2019 | 2.81 | New | New MAN file |
| 10.11.2017 | 2.80 | Fixed | Problem fixed |
| 17.06.2016 | 2.79 | Fixed | Did not run under WinXP |
| 15.06.2016 | 2.78 | Fixed | Error at double block detection fixed |
| 14.09.2015 | 2.77 | Fixed | Possible correction problem fixed |
| 02.09.2015 | 2.76 | New | Now also EDC7C3 as CMD file |
| 12.08.2015 | 2.75 | New | New file |
| 15.05.2015 | 2.74 | Fixed | Possible Crash fixed |
| 07.05.2015 | 2.73 | New | Now also Ford Cargo |
| 19.09.2014 | 2.72 | New | OBD2 file was not recognized |
| 05.09.2014 | 2.71 | Fixed | Error fixed |
| 01.09.2014 | 2.70 | Fixed | Recognition Iveco Daily improved |
| 15.03.2014 | 2.69 | New | Now also file size of 71000h at EDC7C1/3 |
| 05.02.2014 | 2.68 | Fixed | Sometimes the readout protection was placed in maps |
| 01.10.2013 | 2.67 | New | Now also file length of 71000h at EDC7-DAF |
| 03.06.2013 | 2.65 | New | Test of the additional checksum in the EDC7UC31 |
| 03.06.2013 | 2.66 | Fixed | Error from compiler |
| 17.01.2013 | 2.64 | Fixed | Problem with compiler setting |
| 20.12.2012 | 2.63 | New | Recognition Mitsubishi Canter improved |
| 30.08.2012 | 2.62 | New | Now also UAZ Patriot |
| 25.05.2012 | 2.61 | New | Control block identification improved, new New Holland T7 still doesnt work. |
| 24.01.2012 | 2.59 | New | New EDC7UC32 file |
| 02.11.2011 | 2.58 | New | Recognition, if beginning of the file is empty |
| 26.07.2011 | 2.57 | New | Special handling of Fendt 90000h files |
| 19.07.2011 | 2.56 | Fixed | Offset calculation of partial files improved |
Part-No: OLS291
Description: Checksum correction for Bosch ME9 Mercedes
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 29.03.2021 | 2.14 | New | Now also file size of 3FFF4 from CFF import |
| 17.02.2010 | 2.13 | New | Now also short files with length of 3E000h |
| 29.07.2009 | 2.12 | New | Now also MED9.7 |
| 17.03.2008 | 2.11 | Fixed | One checksum block was not found |
| 12.03.2008 | 2.10 | New | Checksum interface updated |
| 07.11.2006 | 2.09 | Fixed | Curious behaviour at changes |
| 24.08.2006 | 2.08 | New | Modified to CAdrCnv |
| 23.05.2006 | 2.07 | New | BDM readout protection improved |
| 18.05.2006 | 2.06 | Fixed | Block search function improved |
| 10.04.2006 | 2.05 | Fixed | Recognition improved |
| 17.03.2006 | 2.04 | New | Search function improved for ME2.7.2 |
| 28.02.2006 | 2.03 | Fixed | Recognition improved |
| 22.02.2006 | 2.02 | Fixed | Problem at patch tag blocks fixed |
| 30.12.2005 | 2.01 | New | New placement of the BDM readout protection |
| 08.12.2005 | 2.00 | New | New registration |
| 10.10.2005 | 1.6 | Fixed | Recognition improved |
| 18.08.2005 | 1.5 | New | New file |
| 28.07.2005 | 1.4 | Fixed | Recognition improved |
| 01.02.2005 | 1.3 | New | Neuer Datenstand |
Part-No: OLS292
Description: Checksum correction for BMS-K Motorrad R1200GS + RSA
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 09.02.2016 | 2.21 | Fixed | Possible buffer overrun fixed, additional checksum found |
| 19.04.2012 | 2.20 | New | Error handling improved |
| 01.03.2011 | 2.19 | Fixed | Recognition improved |
| 16.12.2009 | 2.18 | New | New file |
| 19.03.2008 | 2.17 | Fixed | Error fixed |
| 12.03.2008 | 2.16 | New | Checksum interface updated |
| 29.08.2007 | 2.15 | Fixed | If the checksums over the program area were not calculated, also one RSA checksum was not calculated by mistake |
| 23.05.2007 | 2.14 | Fixed | RSA correction improved |
| 17.04.2007 | 2.13 | Fixed | Mistakenly text output in script mode |
| 05.04.2007 | 2.12 | Fixed | Problem at patch tag blocks fixed |
| 15.03.2007 | 2.11 | New | In some files checksums over the program area are not correct -> Request, if the program area checksums shall be corrected |
| 07.11.2006 | 2.08 | Fixed | Curious behaviour at changes |
| 24.08.2006 | 2.07 | New | Modified to CAdrCnv |
| 23.05.2006 | 2.06 | New | BDM readout protection improved |
| 10.04.2006 | 2.05 | Fixed | Recognition improved |
| 07.04.2006 | 2.04 | New | New file 369491 |
| 22.02.2006 | 2.03 | Fixed | Problem at patch tag blocks fixed |
| 30.12.2005 | 2.02 | New | New placement of the BDM readout protection |
| 23.12.2005 | 2.01 | New | New file 376788 |
| 08.12.2005 | 2.00 | New | New registration |
| 17.05.2005 | 1.1 | New | New file |
| 29.10.2004 | 1.0 | New | New |
Part-No: OLS293
Description: Checksum correction for Denso, Denso Toyota
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 18.11.2024 | 2.37 | New | New files for Isuzu. |
| 14.10.2024 | 2.36 | New | New file size for Denso. |
| 10.01.2024 | 2.35 | New | Revision of the Toyota Denso with a new checksum. |
| 08.11.2023 | 2.34 | Fixed | Bug fix for difference between different checksums. |
| 14.03.2023 | 2.33 | Fixed | Version mismatches. Includes the new file size 0xF8000 for Denso Toyota |
| 13.08.2021 | 2.32 | New | New file Isuzu with length of 3C.0000h |
| 31.05.2021 | 2.31 | New | New Isuzu identification. |
| 19.06.2020 | 2.30 | New | New Isuzu NPR file |
| 07.02.2020 | 2.29 | New | Exception also for smaller files |
| 05.02.2020 | 2.28 | New | Start identification for the last block improved |
| 04.02.2020 | 2.27 | New | Isuzu NPR, NQR sorted up |
| 30.01.2020 | 2.26 | New | New file |
| 24.01.2020 | 2.25 | New | Additional file size of 7E000 at certain files |
| 31.10.2019 | 2.24 | New | Changes on a checksum on flies with the size 180000h |
| 24.09.2019 | 2.23 | New | Additional checksum for Isuzu NPR 3C0000h. |
| 03.09.2019 | 2.22 | New | Now also Isuzu NPR with file length of 3C0000h |
| 29.08.2019 | 2.21 | New | New Isuzu Denso file |
| 10.10.2018 | 2.20 | New | Now also Isuzu Truck with file length 100000h |
| 21.08.2018 | 2.19 | New | New file |
| 23.07.2018 | 2.18 | New | Recognition of Toyota Denso files improved |
| 05.04.2018 | 2.17 | New | More checksum blocks found in Isuzu NPR |
| 04.04.2018 | 2.16 | New | Test Isuzu NPR |
| 03.04.2018 | 2.15 | New | New Lexus file |
| 16.01.2018 | 2.14 | New | Now also file length of C0000h at Toyota Denso |
| 26.01.2017 | 2.13 | New | Toyota Denso |
| 06.05.2014 | 2.12 | New | Now also Mazda MX-5 software BP8 |
| 06.05.2014 | 2.11 | New | Now also Nissan Primera, X-Trail |
| 26.03.2014 | 2.10 | New | New file BP4W |
| 15.08.2011 | 2.09 | New | New file Mazda MX5 |
| 14.03.2011 | 2.08 | Fixed | Problem fixed at Mazda 6 |
| 11.03.2011 | 2.07 | Fixed | Recognition modified at MX5 |
| 25.05.2010 | 2.06 | New | New MX5 file |
| 20.10.2009 | 2.05 | New | Now also Mazda MX5 |
| 25.03.2009 | 2.04 | New | Recognition modified for Renault Espace readout with Galetto tool |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 12.10.2006 | 2.02 | New | Now also Suzuki gasoline and Mazda 6 |
| 03.01.2006 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 11.12.2004 | 1.0 | New | New |
Part-No: OLS294
Description: Checksum correction for Marelli MJ/MM6-11
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 09.12.2024 | 2.70 | New EEPROM installed | |
| 25.11.2024 | 2.69 | Fixed | Changes in MM11GP and EEPROM. |
| 23.08.2024 | 2.68 | New | EEPROM revised. |
| 07.06.2024 | 2.67 | Fixed | Addresses of the last update corrected and CS name expanded to Marelli 11. |
| 07.06.2024 | 2.66 | New | New Marelli. |
| 03.06.2024 | 2.65 | New | Checksum search Marelli EEPROM improved. |
| 31.05.2024 | 2.64 | New | EEPROM checksum improoved |
| 28.05.2024 | 2.63 | New | EEPROM checksum identification installed. |
| 26.04.2024 | 2.62 | Fixed | 11MP with length of 80000: Identification improved |
| 22.09.2023 | 2.61 | Fixed | Bug fixed. |
| 21.09.2023 | 2.60 | New | More files for MP11. |
| 11.07.2022 | 2.59 | New | New file: 11 MP HW001 |
| 07.06.2022 | 2.58 | New file MM8GSF HW525. | |
| 26.05.2021 | 2.57 | New | Additional checksum for MM 8 DS. |
| 06.11.2019 | 2.56 | New | New file MM10GF HW005 |
| 05.08.2019 | 2.55 | New | New file MM9GC |
| 30.07.2019 | 2.54 | New | New file |
| 04.07.2019 | 2.53 | New | New file MM8GML |
| 31.05.2019 | 2.52 | New | New file |
| 10.05.2019 | 2.51 | New | MM10GF: Now also 40000h files |
| 29.03.2019 | 2.50 | New | New file MM8GFW HW640 |
| 20.03.2019 | 2.49 | Fixed | Possible crash fixed |
| 12.03.2019 | 2.48 | New | Test MM10 |
| 01.02.2019 | 2.47 | New | New file MM 8 GMF HW503 |
| 23.05.2018 | 2.46 | New | New IAW6KPI |
| 29.03.2018 | 2.45 | New | New file |
| 22.02.2018 | 2.44 | New | New MJD6F3 file |
| 21.02.2018 | 2.43 | New | New MJD6F3 file |
| 19.01.2018 | 2.42 | New | New MM7GV file |
| 17.01.2018 | 2.41 | Fixed | Files was not recognized |
| 05.01.2018 | 2.40 | New | Revised completely |
| 13.12.2016 | 2.39 | Fixed | Wrong block found |
| 04.11.2016 | 2.38 | New | Now also MJ9DF |
| 19.07.2016 | 2.37 | New | Now also MM8GMK HW 651 |
| 03.05.2016 | 2.36 | New | New files from MM8GSW: HW608 and HW612 |
| 14.01.2016 | 2.35 | New | MM/MJ8/9 revised completely |
| 11.04.2015 | 2.34 | New | New MM9GF file |
| 04.02.2015 | 2.33 | New | New Tata Vista file |
| 15.04.2014 | 2.32 | New | Now also MJD HW03 with length of F0000h |
| 19.03.2014 | 2.31 | New | New checksum found in MJ8 |
Part-No: OLS295
Description: Checksum correction for Bosch ME7-RSA Porsche, ME711 Porsche 997T
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 24.07.2020 | 2.37 | Fixed | Error correction. |
| 23.03.2018 | 2.36 | Fixed | Problem at already modified file fixed |
| 11.12.2017 | 2.35 | Fixed | Problem at certain file types fixed |
| 10.11.2017 | 2.34 | Fixed | Problem fixed |
| 13.02.2014 | 2.33 | New | Recognition of SPI-Wizard3 files improved |
| 12.09.2013 | 2.32 | New | RSA calculation now also possible at original files |
| 13.12.2011 | 2.31 | Fixed | At CMD file missing processor was displayed |
| 16.08.2011 | 2.30 | Fixed | Erroneous element assignment |
| 25.07.2011 | 2.28 | New | Recognition improved at 997 Dimsport files |
| 31.05.2011 | 2.27 | Fixed | CRC checksum was not found in some files |
| 28.05.2011 | 2.26 | Fixed | Problem fixed, if processor file length was E0000h |
| 17.05.2011 | 2.25 | New | Recognition modified on Boxster S |
| 29.09.2010 | 2.24 | New | New file |
| 05.05.2010 | 2.23 | New | Now also 2MB CMD files |
| 17.11.2009 | 2.22 | Fixed | Influence on other checksums fixed |
| 30.10.2009 | 2.21 | New | New file |
| 05.10.2009 | 2.20 | New | Element recognition improved |
| 30.04.2009 | 2.19 | Fixed | Now also ME7.8.1 |
| 29.09.2008 | 2.18 | New | CRC32 CS also calculate, if processor element is missing |
| 12.03.2008 | 2.17 | New | Checksum interface updated |
| 14.11.2007 | 2.15 | New | New file |
| 26.10.2007 | 2.14 | New | Recognition modified |
| 23.05.2007 | 2.13 | Fixed | RSA correction improved |
| 07.12.2006 | 2.12 | Fixed | 997T: Wrongly warning at complete projects |
| 28.11.2006 | 2.11 | New | 997T: Now also 'eprom only' at european cars |
| 12.10.2006 | 2.10 | Fixed | Problem at serial files fixed |
| 02.10.2006 | 2.09 | New | 997T: Now also processor size D0000h |
| 02.10.2006 | 2.09 | New | Recognition improved |
| 15.08.2006 | 2.08 | New | Now also 997 turbo. Processor and eprom must be read and programmed |
| 16.05.2006 | 2.05 | New | New file 379149 |
| 10.05.2006 | 2.04 | New | New file 379150 |
| 14.03.2006 | 2.03 | New | Identification modified |
| 09.02.2006 | 2.02 | New | New file |
| 03.01.2006 | 2.01 | New | New placement of the SPI identification |
| 08.12.2005 | 2.00 | New | New registration |
| 10.11.2005 | 1.1 | New | New file |
| 10.01.2005 | 1.0 | New | New |
Part-No: OLS296
Description: Checksum correction for Visteon MPC, ESU, EEC-V
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 11.07.2023 | 2.24 | Fixed | Visteon ESU: Bug with 2 wrong CS fixed. |
| 15.06.2022 | 2.23 | New | New: Visteon EEC-V. |
| 13.12.2021 | 2.22 | New | Test: New file Bosch MEDG9.8 !!! |
| 15.08.2019 | 2.21 | New | Reworked |
| 04.07.2019 | 2.20 | Fixed | False detection fixed |
| 30.01.2019 | 2.19 | New | Recognition modified |
| 12.12.2018 | 2.18 | New | Detection sharpend |
| 05.09.2017 | 2.17 | Fixed | Delphi Jaguar excluded |
| 04.06.2014 | 2.16 | New | Recognition improved |
| 16.03.2014 | 2.15 | New | New file |
| 12.04.2013 | 2.14 | New | New 3MB file |
| 10.04.2013 | 2.13 | New | Now also PCM122 with KESS files |
| 10.11.2012 | 2.12 | New | Patch at certain files |
| 19.10.2012 | 2.11 | Fixed | Recognition improved |
| 20.09.2012 | 2.10 | New | Now also Ford Mustang |
| 24.04.2012 | 2.09 | New | Exclusion of files, where this checksum doesnt work |
| 24.02.2012 | 2.08 | New | Now also PCM150 |
| 25.11.2009 | 2.07 | New | Now also black oak files with 60000h length |
| 20.11.2008 | 2.06 | New | Recognition improved |
| 19.11.2008 | 2.05 | New | Now also Black Oak with filelength 1B0000h |
| 18.11.2008 | 2.04 | New | Now also Ford Focus with Silver Oak ECU |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 23.05.2006 | 2.02 | New | BDM readout protection improved |
| 08.12.2005 | 2.00 | New | New registration |
| 24.06.2005 | 0 | Not yet ready |
Part-No: OLS297
Description: Checksum correction for Siemens MSS6x-Ignition/Injection
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 28.11.2017 | 2.14 | New | Now also processor file size of 81000h |
| 30.08.2017 | 2.13 | New | Now also Dimsport 5.4MB files |
| 05.11.2013 | 2.12 | New | Alternative layout at 5MB files respected |
| 09.11.2012 | 2.11 | New | Now also complete files of SPI-Wizard3 and CMD |
| 01.10.2012 | 2.10 | New | Now also NewGenius files |
| 10.12.2009 | 2.09 | New | Now also OptiCan files |
| 23.11.2009 | 2.08 | Fixed | Error fixed at 20000h files |
| 22.10.2009 | 2.07 | Fixed | Error at the insertion of the patch tag block fixed |
| 01.07.2008 | 2.06 | New | Now also OBD2 files |
| 12.03.2008 | 2.05 | New | Checksum interface updated |
| 23.09.2007 | 2.04 | New | Now also E92 M3 |
| 25.08.2006 | 2.03 | New | Modified to CAdrCnv |
| 23.05.2006 | 2.02 | New | BDM readout protection improved |
| 06.01.2006 | 2.01 | New | New placement of the BDM readout protection |
| 08.12.2005 | 2.00 | New | New registration |
| 24.10.2005 | 1.2 | New | New file |
| 18.10.2005 | 1.1 | New | New: M5 / M6 V10 |
Part-No: OLS298
Description: Checksum correction for Siemens Simos 6.x/15.10, SIM266, Theta Pi
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 02.08.2022 | 2.18 | New | SIMOS15.10 now also file length of 30000h |
| 20.08.2020 | 2.17 | New | New SIMOS15 file |
| 17.06.2020 | 2.16 | New | Now also SIMOS15.10 !!! |
| 04.10.2012 | 2.15 | New | Error message, if eprom was read as 2MB instead of 4MB at SIM266 |
| 15.05.2012 | 2.14 | New | New SIM2K file |
| 10.12.2010 | 2.13 | Fixed | Error at empty processor element fixed |
| 14.10.2010 | 2.12 | New | Now also SIM266 with 4MB eprom |
| 17.07.2009 | 2.11 | New | Now also Simos6.2 with length of 1D000h |
| 22.07.2008 | 2.10 | New | Now also Daewoo Tosca |
| 20.05.2008 | 2.09 | New | Now also Kia Lotze |
| 12.03.2008 | 2.08 | New | Checksum interface updated |
| 17.12.2007 | 2.07 | New | Now also Simos6.2 serial files |
| 25.08.2006 | 2.05 | New | Modified to CAdrCnv |
| 24.07.2006 | 2.04 | New | MB SIM266: Now also Byteshooter files |
| 23.05.2006 | 2.03 | New | BDM readout protection improved |
| 02.03.2006 | 2.02 | New | Now also Daewoo Tosca |
| 30.12.2005 | 2.01 | New | New placement of the BDM readout protection |
| 08.12.2005 | 2.00 | New | New registration |
| 06.12.2005 | 1.2 | New | Now also Audi 3.2L V6 FSI |
| 04.11.2005 | 1.1 | Fixed | Fixed: Error at SIM266 |
| 04.07.2005 | 1.0 | New | New |
Part-No: OLS299
Description: Checksum correction for Siemens PPD
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 16.02.2023 | 2.13 | New | Change of internal data. |
| 10.06.2013 | 2.12 | New | Calculation of security area per default off |
| 05.06.2013 | 2.11 | New | Calculation of the security area now optional |
| 27.05.2008 | 2.10 | New | If security area is ok in the original file, it will be inserted automatically |
| 12.03.2008 | 2.09 | New | Checksum interface updated |
| 10.08.2007 | 2.08 | Fixed | Error at webserver |
| 30.07.2007 | 2.07 | New | Now also serial files with length of 3D000h. |
| 16.02.2007 | 2.04 | New | Now also cars with DSG |
| 25.08.2006 | 2.03 | New | Modified to CAdrCnv |
| 23.05.2006 | 2.02 | New | BDM readout protection improved |
| 30.12.2005 | 2.01 | New | New placement of the BDM readout protection |
| 08.12.2005 | 2.00 | New | New registration |
| 24.06.2005 | 1.0 | New | New |
Part-No: OLS800
Description: Checksum correction for Siemens MSS70/MSD70, MS45 BMW
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 15.03.2023 | 3.01 | New | Siemens MSV70/MSD70: identification adjusted. |
| 23.04.2021 | 3.00 | New | Added OLS277 Siemens MS45 BMW. |
| 14.01.2010 | 2.06 | New | Now also Optican files |
| 12.03.2008 | 2.05 | New | Checksum interface updated |
| 25.08.2006 | 2.04 | New | Modified to CAdrCnv |
| 23.05.2006 | 2.03 | New | BDM readout protection improved |
| 04.05.2006 | 2.02 | New | Now also MSS70 |
| 08.12.2005 | 2.00 | New | New registration |
Part-No: OLS801
Description: Checksum correction for Bosch ME9 Opel, Suzuki
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 29.03.2021 | 2.30 | New | New file size for Opel ME9. |
| 10.10.2019 | 2.29 | New | New short file |
| 21.06.2018 | 2.28 | New | Automatical element detection in 28.0000h long files |
| 23.10.2017 | 2.27 | New | Recognition modified for software number 400135 |
| 24.04.2014 | 2.26 | New | Search function for additional checksums at OBD2 files improved |
| 13.03.2014 | 2.25 | Fixed | Recognition improved |
| 11.03.2014 | 2.23 | New | Now also BSR PPC format |
| 08.08.2013 | 2.22 | Fixed | Erroneous found checksum block fixed |
| 18.10.2011 | 2.21 | Fixed | Compiler error |
| 11.10.2011 | 2.20 | New | Recognition for additional checksums modified |
| 16.11.2010 | 2.19 | Fixed | Differenciation of different software version improved |
| 11.11.2010 | 2.18 | Fixed | At too small files no escape but messagebox |
| 10.11.2010 | 2.17 | Fixed | Additional CS found |
| 29.10.2010 | 2.16 | Fixed | Problem with end address fixed |
| 28.10.2010 | 2.15 | New | Error message, if file is too small + address for NOREAD moved |
| 18.03.2009 | 2.14 | New | Now also Suzuki Vitara 3.2L V6 |
| 07.11.2008 | 2.13 | New | Now also file length 3E000 |
| 26.09.2008 | 2.12 | New | Recognition modified |
| 23.07.2008 | 2.11 | New | New file |
| 11.07.2008 | 2.10 | Fixed | Checksum block lost |
| 24.06.2008 | 2.09 | New | Additional checksum found |
| 13.03.2008 | 2.08 | Fixed | Block was not found |
| 12.03.2008 | 2.07 | New | Checksum interface updated |
| 25.07.2007 | 2.06 | New | Now also vSpire file |
| 10.04.2007 | 2.05 | New | Now also Opel GT |
| 07.11.2006 | 2.04 | Fixed | Curious behaviour at changes |
| 24.08.2006 | 2.03 | New | Modified to CAdrCnv |
| 26.07.2006 | 2.02 | New | Now also file length 1E000h |
| 24.01.2006 | 2.00 | New | New |
Part-No: OLS803
Description: Checksum correction for Denso32; Transtron Isuzu
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 31.03.2025 | 4.35 | New | New size for Isuzu Transtron. |
| 19.03.2025 | 4.34 | New | Recognition of the new JCB/S imports OLS1021. |
| 25.02.2025 | 4.33 | New | Additional checksum algorithm implemented for newer Denso32 files. |
| 02.09.2024 | 4.32 | New | New identifier S320 |
| 12.07.2024 | 4.31 | New | New Denso32 |
| 26.06.2024 | 4.30 | New | Isuzu Transtron: Checksum ranges increased. |
| 11.06.2024 | 4.29 | New | New Filesize. |
| 11.06.2024 | 4.28 | New | New Denso file. |
| 13.04.2024 | 4.27 | New | New file |
| 23.01.2024 | 4.26 | New | .hex import identification. |
| 17.10.2023 | 4.25 | New | New Denso Mazda. |
| 17.08.2023 | 4.24 | Fixed | Fixed a bug that caused a recursion. |
| 16.08.2023 | 4.23 | New | New Denso. |
| 21.07.2023 | 4.22 | New | New file Denso32. |
| 20.07.2023 | 4.21 | New | New Denso and another checksum for DC1U. |
| 29.06.2023 | 4.20 | Fixed | Bug fix. |
| 22.05.2023 | 4.19 | New | New Isuzu Transtron. |
| 20.12.2022 | 4.18 | New | New Transtron. |
| 30.11.2022 | 4.17 | New | New Denso files. |
| 07.12.2021 | 4.16 | New | New special case in Denso table. |
| 28.06.2021 | 4.15 | New | New Denso file size 0x800000. |
| 23.06.2020 | 4.14 | Fixed | Fixed a bug which the plugin would crash with a certain file size. |
| 05.06.2020 | 4.13 | Fixed | Fixed a bug that caused the program to crash with certain files. |
| 14.11.2019 | 4.12 | New | New entry in the search table. |
| 21.10.2019 | 4.11 | Fixed | Additional test built in to catch errors. |
| 09.10.2019 | 4.10 | New | Revised search function |
| 26.09.2019 | 4.09 | New | New entrys in the search table |
| 26.09.2019 | 4.08 | New | New entry in the search table |
| 24.09.2019 | 4.07 | New | New entry in the search table |
| 20.09.2019 | 4.06 | New | New entry in the search table |
| 09.09.2019 | 4.05 | New | Incorrect address deleted. |
| 19.08.2019 | 4.04 | Fixed | Time for searching too long |
| 05.07.2019 | 4.03 | New | Reject at certain files faster |
| 13.06.2019 | 4.02 | Fixed | Error at calculation fixed |
| 13.06.2019 | 4.01 | Fixed | Transtron was not found |
| 11.06.2019 | 4.00 | New | Revised completely |
| 26.04.2019 | 3.22 | New | New file |
| 13.02.2019 | 3.21 | New | Test Hyundai Starex |
| 06.02.2019 | 3.20 | New | New ACU file |
| 16.11.2018 | 3.19 | New | New Hino file |
Part-No: OLS804
Description: Checksum correction for Tronic T8, 8-MD5 (Only for serial programming)
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 09.03.2018 | 2.12 | New | No more message, if patch tag block cannot be inserted |
| 09.06.2016 | 2.11 | Fixed | Crash at a certain file fixed |
| 11.01.2016 | 2.10 | New | Exception for 55569664 |
| 15.05.2009 | 2.09 | New | Now also Byteshooter files with length of E0000h |
| 12.12.2008 | 2.08 | New | New file |
| 27.11.2008 | 2.07 | New | New file |
| 12.03.2008 | 2.06 | New | Checksum interface updated |
| 16.06.2007 | 2.05 | New | Now also Ethanol cars |
| 15.06.2007 | 2.04 | Fixed | Crash at some files fixed |
| 07.09.2006 | 2.03 | Fixed | Error at the calculation fixed |
| 28.08.2006 | 2.02 | New | Modified to CAdrCnv |
| 17.08.2006 | 2.01 | New | Placement of patch tag block changed |
| 16.02.2006 | 2.00 | New | New |
Part-No: OLS805
Description: Checksum correction for TRW Volvo EMD2/2.2/2.3, ACM (EMS2.3 cannot be corrected because of RSA checksum
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 07.07.2025 | 2.41 | New | New EMS2.3 |
| 11.12.2024 | 2.40 | New | New EMS2.3. |
| 21.11.2024 | 2.39 | New | New file TRW Volvo Truck EMS2.4. |
| 02.12.2021 | 2.38 | Fixed | TRW Volvo Truck EMS2.3: Error correction to exclude wrong checksums. |
| 22.06.2021 | 2.37 | Fixed | Single checksums outside the map area are hidden. |
| 17.06.2021 | 2.36 | Fixed | Partially incorrect checksum removed, which is only calculated over a small area outside the map area. |
| 28.05.2021 | 2.35 | Fixed | Large EMS3.2 files 0x840000 + 0x844000 are now found regardless of the entered elements. |
| 22.03.2021 | 2.34 | Fixed | Fixed a bug that caused some files to crash. |
| 12.03.2021 | 2.33 | New | EMS2.3 revised and new size implemented 0x840000 + 0x844000 |
| 04.02.2021 | 2.32 | Fixed | Wrong identification removed. |
| 20.01.2021 | 2.31 | New | New ACM - EMS2.3 identification. |
| 29.08.2020 | 2.30 | Fixed | Checksum blocks were not found |
| 15.05.2020 | 2.29 | New | New ACM file |
| 03.04.2020 | 2.28 | Fixed | Wrong block start fixed |
| 10.03.2020 | 2.27 | Fixed | Crash at short files 10000h fixed |
| 24.01.2020 | 2.26 | New | Now also EMS2 from Mack MP7 |
| 04.12.2019 | 2.25 | New | Now RSA warning at EMS2.3 |
| 19.03.2019 | 2.24 | Fixed | Error in detection could cause a crash |
| 14.03.2019 | 2.23 | New | New ACM file |
| 10.12.2018 | 2.22 | New | Test TRW ACM |
| 30.07.2018 | 2.21 | New | Test EMS2.3 |
| 06.03.2018 | 2.20 | New | New file |
| 20.02.2017 | 2.19 | New | Recognition EMS2 improved |
| 27.01.2016 | 2.18 | New | Recognition of hex files improved |
| 13.01.2016 | 2.17 | New | Now also EMS2.2 hex file |
| 28.01.2014 | 2.16 | New | New file |
| 12.12.2013 | 2.15 | New | New file |
| 17.01.2013 | 2.14 | Fixed | Problem with compiler setting |
| 04.12.2012 | 2.13 | New | New EMS2.2 file |
| 12.07.2011 | 2.12 | New | Now also file length 201000h at EMS2.2 |
| 08.11.2010 | 2.11 | Fixed | Problem with new EMS2.2 file fixed |
| 27.09.2010 | 2.10 | New | New EMS2.2 file |
| 13.07.2010 | 2.09 | New | New EMS2 file |
| 18.05.2009 | 2.08 | Fixed | Block recognition modified |
| 17.03.2009 | 2.07 | Fixed | Problem at EMS2 with offset fixed |
| 16.03.2009 | 2.06 | New | Now also EMS2.2 P03 |
| 04.02.2009 | 2.05 | New | Alternative placement of the readout protection |
| 24.04.2008 | 2.04 | New | Now also serial files of new EMS2 ECUs |
| 12.03.2008 | 2.01 | New | Checksum interface updated |
| 24.10.2007 | 2.01 | New | Now also Byteshooter files |
Part-No: OLS807
Description: Checksum correction for Bosch MED17/EDC17, RSA, Comp Chk, MED17 Patch, EEPROM, EDC17Cxxx Patch, MED17 Variant
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 21.01.2025 | 3.32 | Fixed | Error message if the base table cannot be found in projects with variants |
| 20.01.2025 | 3.31 | New | Further EEPROM detection. |
| 18.11.2024 | 3.30 | New | New EEPROM. |
| 13.06.2024 | 3.29 | New | New dummy checksum for individual EDC17CV54 with a note that no correction is needed for this. |
| 07.05.2024 | 3.28 | New | Possible file size increased and small changes to the address processing of the hash checksum. |
| 28.03.2024 | 3.27 | Fixed | Query that sorts out incorrectly recognized CS EEPROM. |
| 25.03.2024 | 3.26 | New | New EDC17CV41. |
| 31.07.2023 | 3.25 | Fixed | EDC17CV4x patch bug fixed. |
| 04.04.2023 | 3.24 | Fixed | CVN-Fix now standard. Bug fixes. |
| 08.03.2023 | 3.23 | Fixed | MED17 CVN correction disabled because of recursion problems. EDC17 CVN correction still works. |
| 06.03.2023 | 3.22 | New | New EDC17CV41. |
| 04.03.2023 | 3.21 | New | Maximum project size increased to 10MB |
| 21.11.2022 | 3.20 | Fixed | Bug fixed which causes errors. |
| 10.11.2022 | 3.19 | Fixed | Correction at another address reverted due to recursion in update 3.17. |
| 07.11.2022 | 3.18 | Fixed | Buf fix. |
| 07.11.2022 | 3.17 | New | Fixed some bugs and correct a checksum on another address. |
| 20.08.2022 | 3.16 | Fixed | Incorrect text |
| 19.08.2022 | 3.15 | New | Now also EDC17CV82 |
| 16.08.2022 | 3.14 | Fixed | Correction EDC17CV41/42 and -C49. Inserted checkbox for disabling. |
| 09.08.2022 | 3.13 | New | Beta version for EDC17CV41, EDC17CV42 und EDC17C49. |
| 30.09.2021 | 3.12 | New | Project size increased. |
| 28.06.2021 | 3.11 | Fixed | Messagebox bug fixed. |
| 06.11.2020 | 3.10 | Fixed | Warning for tractor checksum was output too often |
| 13.10.2020 | 3.09 | Fixed | Detection improved at EDC17C49 |
| 08.10.2020 | 3.08 | Fixed | Detection of the tractor CS in EDC17CV41 improved which we cannot calculate |
| 23.09.2020 | 3.07 | Fixed | Bugfixes |
| 03.09.2020 | 3.06 | Fixed | Bug fixes |
| 03.08.2020 | 3.05 | Fixed | Fix registry problems. |
| 03.08.2020 | 3.04 | Bugfixes | |
| 14.07.2020 | 3.03 | New | EEprom detection completely revised. |
| 09.07.2020 | 3.02 | Fixed | Fixed registration error. |
| 09.07.2020 | 3.01 | New | Revised detection of EEprom. |
| 28.01.2020 | 3.00 | New | New Ford file |
| 14.10.2019 | 2.99 | Fixed | Error on checksumcorrection in EEprom fixed. |
| 18.09.2019 | 2.98 | New | Additional project sizes added for EEprom. |
| 16.09.2019 | 2.97 | New | New projectsize for Eeprom implemented |
| 07.08.2019 | 2.96 | New | EEprom checksum improved |
| 22.07.2019 | 2.94 | Fixed | Problem after VS update fixed |
| 21.07.2019 | 2.93 | Fixed | Error in Compiler settings |
| 19.07.2019 | 2.92 | New | New Ford file |
Part-No: OLS808
Description: Checksum correction for EFI Lotus Croft V1/V2
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 24.07.2019 | 2.18 | New | Now also file length of 101000h allowed |
| 12.11.2018 | 2.17 | New | Test |
| 05.11.2018 | 2.16 | New | New file |
| 26.11.2013 | 2.15 | New | Now also file size of 100400h |
| 14.05.2012 | 2.14 | New | Recognition modified at 1MB files |
| 03.05.2012 | 2.13 | New | New file |
| 16.12.2011 | 2.12 | New | New file |
| 28.10.2011 | 2.11 | New | New file |
| 16.07.2011 | 2.10 | New | Now also Caterham Superlight 300R |
| 20.04.2011 | 2.09 | New | Now also Evora read with Piasini Serial Suite |
| 24.08.2010 | 2.08 | New | New file |
| 09.04.2010 | 2.07 | New | New file Croft222 |
| 17.11.2009 | 2.06 | New | New file |
| 27.08.2009 | 2.05 | New | New Croft200 file |
| 18.06.2008 | 2.04 | New | Now also new files |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 17.10.2007 | 2.01 | New | Now also T4E070 and T4E062 |
| 16.02.2006 | 2.00 | New | New |
Part-No: OLS809
Description: Checksum correction for Delphi DCM3.2, DCM3.3, DCM3.4, DCM3.5 + PSA, DCM3.7, DCM MB
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 27.02.2025 | 3.03 | New | DCM3.3 EEPROM revised. |
| 25.10.2024 | 3.02 | New | New DCM3.7 |
| 24.10.2024 | 3.01 | New | Patch installed for some CRD3. |
| 07.10.2024 | 3.00 | New | New DCM3.7 |
| 20.09.2023 | 2.99 | Fixed | Missing CS in DCM3.3++ eeprom installed. |
| 13.09.2023 | 2.98 | New | DCM3.3+ EEPROM added and new DCM3.7 |
| 01.06.2023 | 2.97 | New | Detection area extended at DCM3.4 |
| 11.04.2023 | 2.96 | New | New DCM3.7. |
| 02.01.2023 | 2.95 | New | New size for Delphi DCM3.7. |
| 19.12.2022 | 2.94 | New | New DCM 3.7 file. |
| 06.10.2022 | 2.93 | Fixed | New DCM 3.7 file. |
| 04.10.2022 | 2.92 | New | New file DCM3.7. |
| 05.05.2021 | 2.91 | Fixed | Problem at certain file sizes fixed |
| 03.05.2021 | 2.90 | New | DCM3.4 - SH7058 - elements considered. |
| 03.05.2021 | 2.89 | New | DCM3.4 Renesas SH7058 |
| 14.01.2021 | 2.88 | New | Additional detection for file size 0x1F.0000. |
| 09.01.2021 | 2.87 | New | Now also Hex files with length of 1F.0000 at DCM3.3 |
| 10.02.2020 | 2.86 | New | New projectsize. |
| 14.11.2019 | 2.85 | New | New file DCM3.7 Bobcat |
| 18.09.2019 | 2.84 | New | New projectsize. |
| 24.07.2019 | 2.83 | New | At DCM3.2 binary files the Eprom element will be no longer activated but the All Elerments |
| 01.07.2019 | 2.82 | New | New Doosan file |
| 11.12.2018 | 2.81 | New | Test new CRD3 file |
| 22.10.2018 | 2.80 | New | New file MB CRD3 |
| 16.10.2018 | 2.79 | Fixed | Second address area was not respected |
| 09.08.2018 | 2.78 | New | New DCM3.7 file in Hyundai i20 |
| 21.06.2018 | 2.77 | New | DCM3.3: further file size 2A.0000h |
| 20.06.2018 | 2.76 | New | Test DCM3.3 |
| 14.05.2018 | 2.75 | New | New file |
| 24.10.2017 | 2.74 | New | DCM3.7: Fork lift |
| 28.09.2017 | 2.73 | Fixed | Crash at certain file sizes fixed |
| 29.06.2017 | 2.72 | Fixed | Crash on CS-Search |
| 22.06.2017 | 2.71 | New | New file DCM3.7 |
| 21.06.2017 | 2.70 | New | New file Infinity Q50 |
| 17.03.2017 | 2.69 | New | Additional file size at CRD3 |
| 14.02.2017 | 2.68 | New | New Tata Safari file |
| 26.01.2016 | 2.67 | New | Now also file size 300400h at DCM3.5 |
| 21.04.2015 | 2.66 | New | New DCM3.7 file |
| 17.09.2014 | 2.65 | New | Additional file lengths |
| 09.09.2014 | 2.64 | New | New DCM3.7 file |
Part-No: OLS810
Description: Checksum correction for Delphi Truck., Metatron MF3
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 22.01.2025 | 2.40 | New | New Delphi Truck |
| 02.05.2023 | 2.39 | New | New Delphi Truck |
| 02.05.2023 | 2.38 | New | New Delphi Truck |
| 06.03.2023 | 2.37 | New | New Delphi Truck size. |
| 06.02.2023 | 2.36 | New | New Delphi Truck |
| 02.02.2023 | 2.35 | New | New Delphi Truck files. |
| 19.10.2021 | 2.34 | New | New Metatron identification. |
| 04.05.2021 | 2.33 | New | New size for Delphii Truck. |
| 14.04.2021 | 2.32 | New | New file size added and checksum corrected, which note a different block size. Delphi Truck |
| 12.04.2021 | 2.31 | Fixed | Error at file size 20000h |
| 08.02.2021 | 2.30 | New | New UD Quon file |
| 29.05.2020 | 2.29 | New | New PACCAR file |
| 23.03.2020 | 2.28 | Fixed | Crash fixed |
| 27.02.2020 | 2.27 | New | New PACCAR file |
| 12.02.2020 | 2.26 | New | Paccar: new file size of 0xBF000 |
| 01.08.2019 | 2.25 | New | Paccar: new file size of 0xFF000 |
| 12.07.2018 | 2.24 | New | New file Nissan UD GW400 |
| 04.08.2017 | 2.23 | Fixed | Error at recognition fixed |
| 31.07.2017 | 2.22 | Fixed | Possible crash fixed |
| 12.07.2017 | 2.21 | New | New Hyundai HD500 file |
| 06.02.2017 | 2.20 | Fixed | Erroneous recognition |
| 17.01.2017 | 2.19 | New | New Hyundai file |
| 11.11.2015 | 2.18 | New | New file |
| 15.04.2015 | 2.17 | New | Other file formats for ETC3 |
| 20.02.2015 | 2.16 | Fixed | Possible crash at CMD files |
| 26.01.2015 | 2.15 | New | Now also 3MB files |
| 11.06.2014 | 2.14 | New | Now also Nissan 470 |
| 28.07.2011 | 2.13 | New | Metatron MF3: Now also BDM files |
| 26.05.2011 | 2.12 | New | Now also Metatron MF3 |
| 12.07.2010 | 2.11 | New | Recognition modified |
| 23.06.2010 | 2.10 | New | New file |
| 05.10.2009 | 2.09 | New | New file |
| 23.03.2009 | 2.08 | New | New file of Hyundai Trago |
| 04.03.2009 | 2.07 | New | Now also Hyundai Trago |
| 04.07.2008 | 2.06 | New | New file |
| 12.03.2008 | 2.05 | New | Checksum interface updated |
| 29.02.2008 | 2.04 | New | Recognition modified for new files |
| 28.02.2008 | 2.03 | New | Recognition modified for new files |
| 26.02.2008 | 2.02 | New | Recognition changed + now also Byteshooter files |
| 12.02.2007 | 2.01 | Fixed | Slows down the WinOLS startup |
Part-No: OLS811
Description: Checksum correction for
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 19.12.2022 | 2.25 | New | New Visteon file size for .bin import. |
| 10.02.2021 | 2.24 | New | Ford Visteon TCM moved to OLS817 |
| 08.02.2021 | 2.23 | New | New TCM file |
| 05.04.2019 | 2.22 | New | New file |
| 14.12.2018 | 2.21 | New | New Visteon TCU file |
| 13.08.2018 | 2.20 | New | New file |
| 24.07.2018 | 2.19 | New | Test: Visteon Tricore |
| 16.03.2016 | 2.18 | New | Now also FGtech files |
| 13.10.2011 | 2.17 | Fixed | File was not recognized |
| 22.08.2011 | 2.16 | New | Recognition revised |
| 04.02.2011 | 2.14 | New | New file in Genius format |
| 16.06.2010 | 2.13 | New | New file |
| 15.12.2009 | 2.12 | New | Now also Genius files |
| 16.11.2009 | 2.11 | New | New File |
| 10.06.2008 | 2.10 | New | Now also file length of Genius |
| 12.03.2008 | 2.09 | New | Checksum interface updated |
| 14.01.2008 | 2.08 | New | New file |
| 03.11.2007 | 2.07 | New | New file |
| 10.08.2007 | 2.06 | Fixed | In some Ford Transit files the patch-tag-block could not be placed |
| 27.07.2007 | 2.05 | New | Now also with linear memory layout |
| 20.07.2007 | 2.04 | New | Now also Ford Transit |
| 07.07.2007 | 2.03 | New | Now also files with more expansion codes |
| 06.07.2007 | 2.02 | New | Now also CMD files |
| 15.03.2007 | 2.01 | New | Ready |
| 05.03.2007 | 2.00 | New | Test |
Part-No: OLS812
Description: Checksum correction for Hitachi Nissan, Subaru, Renault
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 29.01.2024 | 2.51 | New | Hitachi Nissan new file size. |
| 22.11.2022 | 2.50 | New | New files Hitachi Nissan. |
| 05.07.2022 | 2.49 | New | Hitachi Nissan: New data status. |
| 13.09.2021 | 2.48 | New | Now also files with 40000h length |
| 05.05.2021 | 2.47 | New | Hitachi Nissan identification extended. |
| 18.03.2021 | 2.46 | New | New Hitachi Renault identification. |
| 18.05.2020 | 2.45 | New | Overwork Hitachi Nissan |
| 13.02.2020 | 2.44 | New | No more error message, if the Patch-Tag-Block cannot be placed in Subaru files |
| 17.05.2019 | 2.43 | New | Now also Renault Megane 4 RS Trophy |
| 06.03.2019 | 2.42 | New | New file Nissan Patrol |
| 10.08.2017 | 2.41 | New | Test Subaru WRX 2MB files |
| 09.01.2017 | 2.40 | New | Now also 2MB files, but only complete files - no maps only files |
| 18.05.2016 | 2.39 | New | Test Subaru Forester |
| 10.11.2015 | 2.38 | New | New file |
| 08.10.2015 | 2.37 | New | Now also files with empty boot area |
| 10.07.2015 | 2.36 | New | New files |
| 16.06.2015 | 2.35 | New | Recognition of block start at 8180h |
| 21.05.2015 | 2.34 | New | Recognition improved |
| 20.05.2015 | 2.33 | New | New NP300 file |
| 11.04.2015 | 2.32 | New | Now also files with length of 140000h |
| 12.01.2015 | 2.31 | New | Now also 2MB files |
| 18.08.2014 | 2.30 | New | New file Nissan Note |
| 22.07.2014 | 2.29 | New | Now also Nissan Wingroad with length 60000h |
| 15.07.2014 | 2.28 | New | Search algorithm improved |
| 26.03.2014 | 2.27 | New | New file |
| 18.03.2014 | 2.26 | New | New file |
| 18.03.2014 | 2.27 | Fixed | Problem searching checksum in modified file |
| 13.01.2014 | 2.25 | New | Search algorithm improved |
| 13.09.2013 | 2.24 | New | New file Nissan Patrol 5.6L |
| 10.09.2013 | 2.23 | New | New file Nissan Almera Classic |
| 05.08.2013 | 2.22 | New | Search of checksum blocks improved |
| 27.07.2013 | 2.21 | New | New file Nissan Teana |
| 12.07.2013 | 2.20 | New | New Infinity file |
| 10.06.2013 | 2.19 | New | New file |
| 06.06.2013 | 2.18 | New | New file |
| 15.05.2013 | 2.17 | New | New file |
| 08.05.2013 | 2.16 | New | New file |
| 07.02.2013 | 2.15 | New | New file |
| 15.01.2013 | 2.14 | New | Recognition updated |
| 18.09.2012 | 2.13 | New | New files of Qashqai and X-Trail |
Part-No: OLS813
Description: Checksum correction for Bosch Smart 2007
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 05.05.2014 | 2.06 | New | New file |
| 27.08.2012 | 2.05 | Fixed | Recognition improved |
| 07.10.2010 | 2.04 | New | New file |
| 12.03.2008 | 2.03 | New | Checksum interface updated |
| 16.08.2007 | 2.02 | New | Now also 1to1 file with 8000-17FFF = 0 |
| 02.08.2007 | 2.01 | New | test |
| 17.07.2007 | 0 | New | Not yet ready |
Part-No: OLS816
Description: Checksum correction for Bosch EGS, ETS50
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 08.09.2022 | 2.09 | New | Bosch EGS: new file identification for short files. |
| 08.09.2022 | 2.08 | Fixed | Bosch EGS revised. |
| 24.11.2020 | 2.07 | New | Re-worked EGS, some new checksums for EGS19. |
| 09.02.2018 | 2.06 | New | Recognition GS19 improved. Unfortunately not all files work fine. |
| 26.09.2017 | 2.05 | Fixed | Crash at TC14 files |
| 18.03.2016 | 2.04 | Fixed | Problem fixed |
| 21.08.2014 | 2.03 | New | Now also older Bosch EGS BT0102..... |
| 03.05.2010 | 2.02 | New | Test EST50 |
| 26.02.2009 | 2.01 | New | New file |
| 04.04.2008 | 2.00 | New | New |
Part-No: OLS817
Description:
Checksum correction for
- VL381/VGS4/DQ250 EEPROM
- AQ250/AL750
- AL450/CPC/DL382/DQ380/DQ400/DQ200 MQB/DQ250 MQB/X1
- Aisin DQ500
- Delphi CPC
- Ford UTCU3
- Getrag DCT
- Haldex
- Bosch TCU
- Siemens TCU, FGS2
- ZF 8HP
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 19.05.2025 | 3.13 | New | Additional checksum for Aisin M300. |
| 14.05.2025 | 3.12 | New | More Aisin M300 |
| 05.05.2025 | 3.11 | New | Publication Delphi CPEC and further Bosch ZF 8HP. |
| 06.01.2025 | 3.10 | New | New Aisin M300. |
| 09.12.2024 | 3.09 | New | New: CPC2 |
| 04.06.2024 | 3.08 | New | Siemens TCU revised. |
| 19.04.2024 | 3.07 | Fixed | Element offset correction for Siemens TCU. |
| 20.03.2024 | 3.06 | New | Element structure installed for some TCUs. |
| 15.02.2024 | 3.05 | Fixed | Changes to ZF 8HP that resulted in an incorrect offset. |
| 11.01.2024 | 3.04 | New | New Delphi CPC |
| 18.10.2023 | 3.03 | New | New Delphi CPC |
| 04.09.2023 | 3.02 | Fixed | Some ZF 8HP files were not found |
| 23.06.2023 | 3.01 | New | New Continental CPC. |
| 15.06.2023 | 3.00 | New | Name changed from: OLS817_DSGs to: OLS817_TCU1 |
| 31.05.2023 | 2.90 | New | New Bosch TCU. |
| 23.05.2023 | 2.89 | New | New 8HP file |
| 23.03.2023 | 2.88 | New | More Bosch TCU. |
| 20.03.2023 | 2.87 | New | More cs in Continental CPDs. |
| 20.03.2023 | 2.86 | New | New Continetal DCT size. |
| 17.03.2023 | 2.85 | New | New Getrag DCT. |
| 15.03.2023 | 2.84 | New | Another Continental CPC identification. |
| 10.03.2023 | 2.83 | Fixed | Delphi CPC: Bug fixed and insert patchBlock. |
| 09.03.2023 | 2.82 | New | Delphi CPC added. |
| 02.03.2023 | 2.81 | Fixed | Bugfix Continental CPC. |
| 01.03.2023 | 2.80 | New | New Continental CPC files. |
| 27.01.2023 | 2.79 | New | New DQ380 Files added. |
| 14.12.2022 | 2.78 | New | New Bosch TCU. |
| 10.10.2022 | 2.77 | New | Added ZF 8HP. |
| 07.07.2022 | 2.76 | New | New Siemens TCU. |
| 04.07.2022 | 2.75 | New | Revision Getrag DCT. |
| 24.06.2022 | 2.74 | New | New file size Siemens TCU. |
| 03.06.2022 | 2.73 | New | Ford UTCU3: New size |
| 05.05.2022 | 2.72 | New | New Getrag DCT and Siemens CPC files. |
| 22.04.2022 | 2.71 | New | New Ford UTCU3 size. |
| 10.02.2022 | 2.70 | New | New file size Bosch TCU. |
| 07.02.2022 | 2.69 | New | New file size Bosch TCU. |
| 02.02.2022 | 2.68 | New | New Bosch TCU file |
| 07.09.2021 | 2.67 | New | New Bosch TCU file |
| 12.08.2021 | 2.66 | New | At Hex CPC_NG files retain existing element |
| 10.08.2021 | 2.65 | New | New CPC file |
Part-No: OLS818
Description: Checksum correction for Tricore, Tricore Patch, CVN EMS2xxx, EMS3xxx, PCR2, SID208-807, SIM2K-xxx, SIMOS8-18
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 11.02.2025 | 3.29 | New | New Simos19. |
| 19.06.2024 | 3.28 | Fixed | Fixed bug with permanently activated RSA patch checkbox. |
| 06.05.2024 | 3.27 | Fixed | EMS2303: One CS block too much |
| 11.04.2024 | 3.26 | New | EMS27xx. |
| 03.01.2024 | 3.25 | New | New Siemens TCU |
| 21.09.2023 | 3.24 | New | PCR2.1 CVN Fix: Address brought forward |
| 08.08.2023 | 3.23 | New | New SID310 |
| 26.04.2023 | 3.22 | New | Now also EMS3180 |
| 18.04.2023 | 3.21 | New | Now also here SIM2K-341, Test SIM2K-510 |
| 15.04.2023 | 3.20 | New | Additional criterion for block search |
| 11.04.2023 | 3.19 | New | At SIM2K-240 now also the checksum at 20300 will be found and corrected |
| 14.02.2023 | 3.18 | New | Detection improved for SID212, SIMOS19.x, PatchTagBlock now in map area |
| 28.12.2022 | 3.17 | New | Checkbox for RSA patch. |
| 06.12.2022 | 3.16 | New | New EMS2208. |
| 18.11.2022 | 3.15 | New | New file EMS2219. |
| 28.09.2022 | 3.14 | New | New SID212 file. |
| 24.06.2022 | 3.13 | New | New SID10 file. |
| 14.06.2022 | 3.12 | Fixed | Fixed error due to Extra Ford checksum. |
| 02.05.2022 | 3.11 | New | CVN revised. |
| 04.04.2022 | 3.10 | New | New file SIM2K-305 incl. RSA patch. |
| 04.04.2022 | 3.09 | New | RSA patch for SIM2K250/SIM2K260 Beta version |
| 25.02.2022 | 3.08 | New | SIM2K250 with RSA warning now. |
| 04.02.2022 | 3.07 | New | New files SID212. |
| 22.12.2021 | 3.06 | New | New file SID310 |
| 11.11.2021 | 3.05 | New | New file |
| 24.09.2021 | 3.04 | New | New ID EMS2208 |
| 26.07.2021 | 3.03 | New | New SID209 file |
| 10.05.2021 | 3.02 | New | New file size for special handling for SIMOS8.6 and SIM2K-260. |
| 12.04.2021 | 3.01 | New | Special handling for SIMOS8.6 and SIM2K-260 |
| 02.03.2021 | 3.00 | New | New SID212 ID |
| 27.10.2020 | 2.99 | New | New SID209 ID added. |
| 19.10.2020 | 2.98 | New | SID603 IDs added. |
| 08.05.2020 | 2.97 | Fixed | SID212 recognition fixed |
| 07.04.2020 | 2.96 | New | More SID209 IDs added |
| 06.04.2020 | 2.95 | New | Customer specific handling of SID209 files |
| 23.03.2020 | 2.94 | New | Detection SIMOS16.21 implemented |
| 14.08.2019 | 2.93 | New | Recognition of add CS improved in MSD87 |
| 30.07.2019 | 2.92 | Fixed | Wrong block detection in PCR2.1 |
| 11.07.2019 | 2.91 | New | Test SID212 |
| 26.04.2019 | 2.90 | New | Now also SIM2K-253 |
Part-No: OLS819
Description: Checksum correction for F8T8, F8T8359; Honda-Keihin
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 24.07.2024 | 2.51 | Fixed | Bug that led to recursion removed. |
| 17.07.2024 | 2.50 | New | New: Honda-Shindengen checksum installed. |
| 15.08.2023 | 2.49 | New | Nee Mitsubishi files. |
| 14.02.2023 | 2.48 | New | New Mitsubishi files. |
| 28.12.2022 | 2.47 | New | Mitsubishi completely revised. |
| 10.02.2022 | 2.46 | New | New file size 0x400000 - Mitsubishi Eclipse. Entering incorrect checksums fixed. |
| 18.01.2022 | 2.45 | New | New file size for Mitsubishi 0x3E4000. |
| 07.01.2022 | 2.44 | New | New Honda-Keihin and Mitsubishi file. |
| 10.12.2021 | 2.43 | New | New Honda-Keihin. |
| 08.12.2021 | 2.42 | New | New Honda bike files. |
| 30.08.2020 | 2.41 | New | New Suzuki Vitara file |
| 22.05.2020 | 2.40 | New | New Honda bike files |
| 03.03.2020 | 2.39 | New | New Suzuki Vitara file |
| 07.11.2019 | 2.38 | Fixed | F8T8 problem with patch-tag-block: block removed |
| 23.11.2018 | 2.37 | Fixed | Problem at 31A527 fixed |
| 11.10.2018 | 2.36 | Fixed | Problem at file length 1F0000 fixed |
| 10.08.2018 | 2.34 | New | Test CX-5 |
| 08.08.2018 | 2.33 | New | Now also Mazda CX-5 files |
| 01.08.2018 | 2.32 | New | Suzuki 20000h files |
| 31.07.2018 | 2.31 | New | Test: Mitsubishi ECU in Suzuki car |
| 08.07.2018 | 2.30 | New | New file |
| 09.02.2018 | 2.29 | New | Recognition improved |
| 18.01.2018 | 2.28 | New | Mitsubishi ECUs: Switched to differential calculation ie. the original file must be correct |
| 07.03.2017 | 2.27 | New | New file |
| 01.09.2016 | 2.26 | New | New Yamaha FZ file |
| 15.07.2016 | 2.25 | New | New Keihin file |
| 19.05.2016 | 2.24 | New | Now also Yamaha R6 with Mitsubishi F8T359 |
| 11.04.2016 | 2.23 | New | New file Kawasaki ZX10 |
| 14.10.2015 | 2.22 | New | New file Yamaha XVS |
| 13.08.2015 | 2.21 | New | New Kawasaki Ultra file |
| 07.07.2015 | 2.20 | New | New file Honda FR-V |
| 20.03.2015 | 2.19 | New | New Mazda 3 file |
| 04.02.2015 | 2.18 | New | New file |
| 28.01.2015 | 2.17 | New | New Keihin file |
| 20.11.2014 | 2.16 | New | New Yamaha files in Mitsubishi F8T8 |
| 19.11.2014 | 2.15 | New | Now also 3MB files at Honda-Keihin |
| 17.10.2014 | 2.14 | New | Now also Yamaha Jetski with Mitsubishi Melco ECU |
| 01.10.2014 | 2.13 | New | New file |
| 21.07.2014 | 2.12 | New | New file |
| 11.03.2014 | 2.10 | New | New file |
Part-No: OLS820
Description: Checksum correction for MTxxx, MT2x/HV-240, DCM6
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 23.06.2025 | 2.73 | New | New Delphi MT2x/HV-240. |
| 20.05.2025 | 2.72 | New | New Delphi MT2x/HV-240. |
| 24.03.2025 | 2.71 | New | More Delphi MTxxx |
| 21.03.2025 | 2.70 | New | New Delphi MT2x/HV-240 |
| 20.03.2025 | 2.69 | New | New file sizes for MT2x/HV-240 and Delphi MT621. |
| 18.03.2025 | 2.68 | New | New Delphi MT2x/HV-240. |
| 03.03.2025 | 2.67 | New | New DCM7.xx. |
| 28.02.2025 | 2.66 | New | New MT22 |
| 21.02.2025 | 2.65 | New | New MT60. |
| 18.02.2025 | 2.64 | Fixed | Fixed a bug that led to an incorrect checksum address in some Delphi MT2x/HV-240. |
| 12.02.2025 | 2.63 | New | New MT60. |
| 29.01.2025 | 2.62 | New | New DCM6 file size. |
| 21.01.2025 | 2.61 | New | New DCM7.xx + extended function that finds additional CS blocks. |
| 17.01.2025 | 2.60 | New | New MT60. |
| 06.01.2025 | 2.59 | New | New Delphi MT2x/HV-240 |
| 19.12.2024 | 2.58 | New | New MT60 and MT90. |
| 16.12.2024 | 2.57 | New | New MTxxx |
| 12.12.2024 | 2.56 | New | New MT2x |
| 12.12.2024 | 2.55 | New | New MT2x |
| 12.12.2024 | 2.54 | New | New MT2x |
| 11.12.2024 | 2.53 | New | New MT2x. |
| 06.12.2024 | 2.52 | New | New MT2x and MTxx. |
| 29.11.2024 | 2.51 | New | New MT2x. |
| 20.08.2024 | 2.50 | New | New DCM 7.4. |
| 08.07.2024 | 2.49 | New | New Delphi MT92. |
| 17.06.2024 | 2.48 | New | New Delphi MT62.1 |
| 27.05.2024 | 2.47 | New | New Delphi MT62.1 |
| 29.04.2024 | 2.46 | New | New Delphi MTxx. |
| 02.02.2024 | 2.45 | New | BETA version Delphi DCM7.xx: This is not a checksum correction, but a patch! We cannot guarantee that it will work with every control device or tool. |
| 12.08.2022 | 2.44 | New | Checksums added in data area. |
| 24.05.2022 | 2.43 | New | New MT62.1 file |
| 11.08.2021 | 2.42 | New | MT92 improved, MT22 new file |
| 21.07.2021 | 2.41 | New | Further checksum blocks found in MT62.1 |
| 18.07.2021 | 2.40 | Fixed | HiLo Notation at Delphi MT62.1 |
| 15.07.2021 | 2.39 | Fixed | Fixed a bug for DCM that caused the crash. |
| 31.05.2021 | 2.38 | New | New MT22.1 size. |
| 20.04.2021 | 2.37 | Fixed | Fixed a bug that caused the crash. |
| 30.03.2021 | 2.36 | Fixed | Possible error fixed |
| 10.03.2021 | 2.35 | New | New file size for Delphi MTxx |
| 08.03.2021 | 2.34 | New | Delphi MTxx: new identification |
Part-No: OLS821
Description: Checksum correction for Deco 5, Delco OS
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 22.04.2025 | 2.64 | New | Automatic detection of the start of Block0 |
| 08.04.2025 | 2.63 | New | Adaptation of the information about the missing map area due to new files. |
| 26.11.2024 | 2.62 | Fixed | Offset correction for individual checksums. |
| 07.10.2024 | 2.61 | New | Another checksum block found. |
| 03.09.2024 | 2.60 | New | Now the checksums of bootloader AND operating system are found |
| 16.04.2024 | 2.59 | New | Checksum over operating system can be enabled separately |
| 05.12.2023 | 2.58 | Fixed | Bugfix which causes an error. |
| 17.11.2023 | 2.57 | New | New E88 file |
| 10.11.2023 | 2.56 | New | Checksum over code area is now calculated |
| 04.05.2023 | 2.55 | New | New file |
| 29.07.2022 | 2.54 | Fixed | Erroneous block detection removed |
| 04.02.2022 | 2.53 | New | New file |
| 01.02.2022 | 2.52 | Fixed | At some files wrong checksum address was used |
| 31.01.2022 | 2.51 | New | CVN fix switchable |
| 24.01.2022 | 2.50 | New | Reworked completely |
| 21.01.2022 | 2.49 | New | Delco E41 TCU |
| 07.12.2021 | 2.48 | New | New file |
| 20.04.2021 | 2.47 | Fixed | Possible registration error fixed |
| 16.03.2021 | 2.46 | New | Additional bytes at the end of the file allowed |
| 15.01.2021 | 2.45 | New | New file |
| 11.05.2020 | 2.44 | New | New file Colorado. |
| 29.01.2020 | 2.43 | New | New E92 file |
| 14.02.2019 | 2.42 | New | New file |
| 08.01.2019 | 2.41 | New | New Chevrolet file |
| 19.02.2018 | 2.40 | New | New Opel Mokka file |
| 29.09.2017 | 2.39 | Fixed | Error fixed at calculation of files, which were already calculated by other software |
| 19.04.2017 | 2.38 | New | New file |
| 21.02.2017 | 2.37 | New | New file |
| 05.12.2016 | 2.36 | New | New Buick file |
| 11.10.2016 | 2.35 | New | Now also file size of 600000 |
| 13.08.2016 | 2.34 | Fixed | New file: Block was not found |
| 09.08.2016 | 2.33 | New | End of file recognition improved |
| 18.05.2016 | 2.32 | New | Now also 4MB files |
| 19.11.2015 | 2.31 | Fixed | In some files the patch tag block was located on a checksum result |
| 17.11.2015 | 2.30 | New | New file |
| 11.11.2015 | 2.29 | New | New file |
| 10.09.2015 | 2.28 | New | New file |
| 23.03.2015 | 2.27 | New | New file |
| 21.03.2014 | 2.26 | New | New file |
| 11.03.2014 | 2.25 | New | Now also recognition of 921... |
Part-No: OLS822
Description: Checksum correction for Mikas 11; ME7 China; Siemens China; NPP ITELMA, M75/86
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 29.12.2023 | 2.11 | New | New M240 file |
| 11.07.2023 | 2.10 | New | New checksum beta version!: ITELMA/Mikas MD22/MT22/M240. |
| 20.04.2021 | 2.09 | New | Further Itelma M86 files implemented, Error at registration fixed |
| 24.07.2018 | 2.08 | New | New: GAZ with Mikas12 |
| 10.02.2015 | 2.07 | New | New file of Itelma M75 in Lada Priora |
| 12.06.2013 | 2.06 | New | Now also Itelma M75 |
| 22.04.2013 | 2.05 | New | Now also Itelma M73 |
| 20.03.2013 | 2.04 | New | Recognition modified |
| 20.02.2013 | 2.03 | Fixed | Possible crash for non-matching files |
| 18.02.2013 | 2.02 | New | Now also NPP Itelma |
| 18.10.2011 | 2.01 | New | Now also Proton with Siemens ECU |
| 12.07.2011 | 2.00 | New | New: Mikas 11 in UAZ Patriot |
Part-No: OLS823
Description: Checksum correction for Denso Bikes; Siemens M3C/M3D/MD/M4C; Bosch: MSE3, MSE6; Marelli IAW1; Delphi MT05.2, MT05; Keihin Bikes;
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 01.07.2025 | 2.55 | New M4C. | |
| 17.04.2025 | 2.54 | New | New Siemens M4C bikes. |
| 02.09.2024 | 2.53 | New | Now also KTM with Dimsport file size of 12.0000h |
| 24.07.2024 | 2.52 | New | New Keihin-Bikes. |
| 31.05.2024 | 2.51 | New | New Delphi MT05.2. |
| 30.01.2024 | 2.50 | New | Added checksum for MT05.2. |
| 19.09.2023 | 2.49 | New | New Keihin Bikes Triumph. |
| 05.05.2023 | 2.48 | New | New file |
| 04.05.2023 | 2.47 | New | At M3D, M4C, M4D now a data element is inserted |
| 11.04.2023 | 2.46 | Fixed | Changed patchblock address for M3D. |
| 28.11.2022 | 2.45 | New | Added KTM M4C. |
| 04.11.2022 | 2.44 | New | Keihin Bikes: Honda 450 and KTM 450. |
| 23.06.2022 | 2.43 | New | Siemens M3D/M4D/M4C: New File. |
| 03.06.2022 | 2.42 | New | Siemens M3D/M4D/M4C: new size. |
| 30.05.2022 | 2.41 | Fixed | Siemens M3D/M4D/M4C: Fixed an error on CVN correction. |
| 25.05.2022 | 2.40 | New | Patch for M3D/M4D installed and new Denso Bikes added. |
| 20.05.2022 | 2.39 | New | Denso Bikes: Yamaha Tmax. |
| 19.05.2022 | 2.38 | New | M4C installed. |
| 18.05.2022 | 2.37 | New | Siemens M3D/M4D: New checksum installed. |
| 11.05.2022 | 2.36 | New | Siemens M3D/M4D: Changes in correction. |
| 04.05.2022 | 2.35 | New | Siemens M3D/M4D: Changes in the checksum correction. |
| 30.03.2022 | 2.34 | New | New: Bosch MSE6 Bikes. |
| 13.12.2021 | 2.33 | New | New Siemens MD3/MD4 |
| 14.08.2021 | 2.32 | New | New MT05 file |
| 29.03.2021 | 2.31 | Fixed | Bugfix. |
| 25.11.2020 | 2.30 | New | New Suzuki GSX file |
| 23.11.2020 | 2.29 | New | Checksums for Siemens M3C about complete file. |
| 18.08.2020 | 2.28 | New | New Keihin Triumph file |
| 07.05.2020 | 2.27 | New | Further Harley Davidson files supported |
| 29.04.2020 | 2.26 | New | New Denso file |
| 18.02.2020 | 2.25 | New | Additional file length at M3C |
| 02.02.2020 | 2.24 | Fixed | Wrong identification fixed |
| 22.11.2019 | 2.23 | New | Now also Triumph files with length of 140000h |
| 20.10.2019 | 2.22 | New | Additional file size of 48200h at Siemens/VDO M3C |
| 29.04.2019 | 2.21 | New | New Yamaha file |
| 16.04.2019 | 2.20 | New | New KTM file |
| 01.04.2019 | 2.19 | New | Now also file size of 40040h at M3C files |
| 26.02.2019 | 2.18 | New | Test M4D |
| 23.08.2018 | 2.17 | New | New file Kawasaki Z1000 |
| 09.03.2018 | 2.16 | New | New Suzuki file |
Part-No: OLS824
Description: Checksum correction for TEMIC/Conti MCM/ACM, XC2287, ACM3
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 15.07.2025 | 2.48 | New | Renewed EEPROM revision. |
| 22.08.2024 | 2.47 | New | EEPROM revised. |
| 12.07.2024 | 2.46 | New | Improvement of the EEPROM CS + additional sizes. |
| 12.04.2024 | 2.45 | New | New Temic XC2287 |
| 12.12.2023 | 2.44 | New | New TEMIC/Conti MCM/ACM. |
| 18.07.2023 | 2.43 | New | New Temic/Conti MCM/ACM. |
| 09.05.2023 | 2.42 | New | Test file 30C |
| 23.03.2023 | 2.41 | New | New ACM3 and MCM files. |
| 21.03.2023 | 2.40 | New | New: ACM3. |
| 09.02.2023 | 2.39 | New | New size for TEMIC Truck XC2287. Note: Patch is a test version! Not on old files. A note will appear in the checksum window if the file affected! |
| 30.08.2022 | 2.38 | Fixed | Error, if EEprom was second element |
| 09.06.2022 | 2.37 | New | New Temic/Conti file. |
| 09.05.2022 | 2.36 | New | New file size for TEMIC/Conti MCM/ACM. |
| 29.03.2021 | 2.35 | Fixed | Bugfix. |
| 10.03.2021 | 2.34 | New | New TEMIC Truck XC2287 identification |
| 29.06.2020 | 2.33 | New | Add new identification for TEMIC/Conti MCM/ACM. |
| 04.02.2020 | 2.32 | New | Identification of EEprom file modified |
| 06.11.2019 | 2.31 | New | New file |
| 06.11.2019 | 2.30 | New | New file |
| 18.12.2018 | 2.29 | Fixed | One ACM files was not recognized anymore |
| 27.11.2018 | 2.28 | New | Temic/Conti ACM/MCM ECUs: Recognition modified |
| 13.08.2018 | 2.27 | New | New file |
| 02.06.2018 | 2.26 | Fixed | Crash fixed |
| 01.06.2018 | 2.25 | Fixed | Sum address modified |
| 30.04.2018 | 2.24 | New | Recognition improved |
| 20.11.2017 | 2.23 | Fixed | Euro6 files were not recognized |
| 07.11.2017 | 2.22 | New | Recognition improved, name changed |
| 27.04.2017 | 2.21 | New | New file |
| 08.02.2017 | 2.20 | Fixed | Recognition ACM units modified |
| 19.01.2017 | 2.19 | New | Now also Siemens/Conti ACM control units |
| 18.01.2016 | 2.18 | New | New file |
| 15.01.2016 | 2.17 | New | New file |
| 16.12.2015 | 2.16 | New | New OM936 file |
| 14.12.2015 | 2.15 | New | Now also OM936 |
| 25.08.2015 | 2.14 | Fixed | Checksum was not corrected if it was on address 0 |
| 17.06.2015 | 2.13 | Fixed | Already modified files were not recognized |
| 11.02.2015 | 2.12 | New | Now also 4MB files |
| 22.01.2015 | 2.11 | New | New file |
| 30.10.2014 | 2.10 | New | Element handling improved |
| 25.04.2014 | 2.09 | New | New file 21D |
Part-No: OLS825
Description: Checksum correction for Campi
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 03.10.2023 | 2.08 | New | Test: Aventador |
| 23.05.2023 | 2.07 | Fixed | Long files removed, because checksum over map area has not worked |
| 12.04.2023 | 2.06 | New | Now also file length 204000 |
| 14.12.2021 | 2.05 | New | Now also GFA files |
| 13.12.2021 | 2.04 | New | Revised. |
| 27.03.2019 | 2.03 | New | New file |
| 26.11.2015 | 2.02 | New | New file |
| 26.05.2014 | 2.01 | New | New file |
| 05.02.2014 | 2.00 | New | First test |
Part-No: OLS826
Description: Checksum correction for Bosch DCU-15/EAS/SC, Wabco VCM, Cummins CM3230B/EDC17CV51, Cummins CM2xxx
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 15.07.2025 | 2.56 | Fixed | Troubleshooting. |
| 25.06.2025 | 2.55 | Fixed | Troubleshooting. |
| 06.06.2025 | 2.54 | New | CM2xxx revised. |
| 04.04.2025 | 2.53 | New | New CM2xx |
| 03.04.2025 | 2.52 | Fixed | Further troubleshooting. |
| 25.03.2025 | 2.51 | Fixed | Fixed bugs that could lead to a crash. |
| 21.03.2025 | 2.50 | New | More CM2xxx. |
| 07.03.2025 | 2.49 | Fixed | Troubleshooting. |
| 04.03.2025 | 2.48 | Fixed | Error fixed. |
| 04.02.2025 | 2.47 | Fixed | Error correction that led to recursion. |
| 10.01.2025 | 2.46 | New | New CM2xxx |
| 26.11.2024 | 2.45 | Fixed | Fixed a bug where a checksum was not entered for some files. |
| 05.08.2024 | 2.44 | New | CM2xx: new checksum blocks, changes of duplicate checksums in sync blocks, bug fixes. |
| 28.05.2024 | 2.43 | Checksum entry improved. | |
| 26.03.2024 | 2.42 | New | Improve checksum search. |
| 19.03.2024 | 2.41 | New | New CM2xxx |
| 29.01.2024 | 2.40 | New | New CM2xxx files. |
| 27.06.2023 | 2.39 | New | CM2xx: Changes in creating elements for .bin files. |
| 13.06.2023 | 2.38 | New | More CM2xxx and new checksums added on some Wabco VCM3. |
| 05.06.2023 | 2.37 | New | CM2xxx identification improved. |
| 23.05.2023 | 2.36 | New | Cummins CM3230B/EDC17CV51 revised, FLS import considered. |
| 27.04.2023 | 2.35 | New | Complete revision to recognize old files and new XCAL imports. |
| 17.03.2023 | 2.34 | New | New DCU-15 and merged EAS/SCR. |
| 14.03.2023 | 2.33 | Fixed | Version mismatches. |
| 03.03.2023 | 2.32 | New | New CM2xxx. |
| 24.02.2023 | 2.31 | New | New CM2xxx file size. |
| 09.02.2023 | 2.30 | New | Better CM2xxx identification. |
| 20.12.2022 | 2.29 | New | New Cummins CM2xxx identification. |
| 18.11.2022 | 2.28 | New | New files CM2xxx. |
| 25.10.2022 | 2.27 | New | New file for large Cummins. |
| 29.06.2022 | 2.26 | New | New file Cummins CM2xx. |
| 06.05.2022 | 2.25 | New | New file size for Bosch DCU-15/SRC. |
| 23.03.2022 | 2.24 | New | Cummins CM2xxx - new file size: 0x200000 |
| 14.01.2022 | 2.23 | New | Cumins CM2xxx new file size: 0x800000. |
| 05.01.2022 | 2.22 | New | New file. |
| 30.11.2021 | 2.21 | New | Small adjustment. |
| 26.11.2021 | 2.20 | New | Checksum revised |
| 24.11.2021 | 2.19 | New | Earlier Cumins checksums outside of the map area reinstalled. |
| 13.10.2021 | 2.18 | New | new Wabco VCM data status. |
| 28.09.2021 | 2.17 | New | Further checksum addresses localized. |
Part-No: OLS827
Description: Checksum correction for Liebherr ECU2/3, Temic TAD801, Haldex Gen4, Aisin AF40
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 31.07.2025 | 2.10 | New | FLS file recognition for Continental VDO ACU GEN3 |
| 17.07.2025 | 2.09 | New | New file size for Temic TAD801 |
| 19.05.2025 | 2.08 | New | Further Liebherr recognition. |
| 14.04.2025 | 2.07 | Fixed | Troubleshooting that led to incorrect recognition of files. |
| 26.03.2025 | 2.06 | New | NEW: Continental VDO ACU GEN3 |
| 17.03.2025 | 2.05 | New | Liebherr 0x400000 File size implemented. |
| 13.03.2025 | 2.04 | New | Bosch ZF 2 beta implemented.Changes to the Liebherr checksum. |
| 10.11.2024 | 2.03 | New | Detection of AF40 improved for Saab |
| 27.09.2024 | 2.02 | New | CPC4 beta version. |
| 24.05.2024 | 2.01 | New | New checksum: MB CPC3 |
| 27.02.2024 | 2.00 | Fixed | Only update of the version number to 2.00 due to database conflict. |
| 26.02.2024 | 1.02 | New | New: Aisin AF40 |
| 21.06.2023 | 1.01 | New | Haldex Gen4. |
| 16.06.2023 | 1.00 | New | New. |
Part-No: OLS830
Description: Checksum correction for MDG1, CVN, EEPROM, MD1CE101/MD1CS069 Patch - Attention: The RSA checksum in this file cannot be calculated. So the resulting file can only be used in a tool, which switches off this checksum.
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 18.07.2025 | 2.55 | Fixed | Elements improved so that for some vbf imports the elements are not only entered correctly on the second search. |
| 03.07.2025 | 2.54 | New | Missing CS block for MD1CP062 installed. |
| 03.03.2025 | 2.53 | Fixed | A version of the EEPROM checksums has been revised. |
| 31.01.2025 | 2.52 | New | New EEPROMS. |
| 19.11.2024 | 2.51 | Fixed | Fixed: RSA warning was not displayed immediately during the first checksum search. |
| 05.11.2024 | 2.50 | Fixed | Fixed bugs in elements. |
| 23.10.2024 | 2.49 | Fixed | Bug fix. |
| 22.05.2024 | 2.48 | Fixed | Expanding false detection. |
| 21.05.2024 | 2.47 | Fixed | Changes in elements for bug fix. |
| 07.05.2024 | 2.46 | New | Detection of truck double blocks installed. |
| 16.04.2024 | 2.45 | New | Address processing revised. |
| 18.03.2024 | 2.44 | Fixed | Bug fix in EEPROM checksum. |
| 27.02.2024 | 2.43 | New | Internal optimizations, new element installation, new version of the hash patch. |
| 30.01.2024 | 2.42 | Fixed | Adjustments for hash checksum for hex imports. |
| 26.01.2024 | 2.41 | New | Corrected incorrect end address in patch and added an RSA warning. |
| 15.01.2024 | 2.40 | Fixed | Bug in EEPROM fixed which crashed the PlugIn. |
| 29.11.2023 | 2.39 | Fixed | Bug fix for MD1CE101/MD1CS069 patch. |
| 22.11.2023 | 2.38 | New | More EEPROM version. |
| 11.09.2023 | 2.37 | Fixed | Patch correction address changed. |
| 18.08.2023 | 2.36 | New | Larger files added to the identification. |
| 24.01.2023 | 2.35 | Fixed | Block detection improved |
| 19.01.2023 | 2.34 | New | Extended block search, so that blocks are also found which contain several hardware elements, incorrect checksums are not inserted for variant blocks ID 70 |
| 04.11.2022 | 2.33 | New | Implement MD1CE101 and MD1CS069 checksum. |
| 21.10.2022 | 2.32 | Fixed | Problems on some computers |
| 14.10.2022 | 2.31 | Fixed | Fixed the bug of WinOLS4 version. |
| 07.10.2022 | 2.30 | New | Added EEPROM for MD1CS001. Beta |
| 01.08.2022 | 2.29 | New | CVN fix with checkbox to switch on and off. |
| 19.07.2022 | 2.28 | Fixed | EEprom checksum bug corrected. |
| 13.04.2022 | 2.27 | New | Changes on Ford checksum and in the EEPROM area. |
| 24.02.2022 | 2.26 | New | New MG1CSxxx Ford checksum. |
| 09.09.2021 | 2.25 | New | New Ford file |
| 08.06.2021 | 2.24 | Fixed | Removed wrong checksums and made some improvements. |
| 17.11.2020 | 2.23 | New | Maximum file size now 16MB, Ford checksum updated |
| 02.06.2020 | 2.22 | Fixed | Problem with empty processor element fixed |
| 04.02.2020 | 2.21 | Fixed | Notification with reference to checksum postponed outside the map area. |
| 28.01.2020 | 2.20 | New | Improvement of the checksum search. |
| 20.01.2020 | 2.19 | New | Improved detection and calculation of the EEPROM checksum. |
| 09.01.2020 | 2.18 | Fixed | Bugfix |
| 06.12.2019 | 2.17 | New | Test EEprom checksum |
| 29.08.2019 | 2.14 | Fixed | Error fixed |
Import - Export (21)
Part-No: OLS1001
Description: Allows the import, modification and export of Vadis/VBF file
More information
Original Tester Import / Export
The car manufacturer are using systems to apply later update to the already delivered cars. The new data for the ECUs are stored in company specific files with own data formats.
With the new import/export plug-ins these files can now be analyzed and imported into WinOLS. Only the processor or eprom area will be shown in WinOLS as if it would be an eprom file. Modifications can be done as usual and the checksum can be corrected by the corresponding plug-in.
The finished file can be exported back into the original tester data format.
A possible checksum over the tester file will be corrected automatically.
Provided functions: Allows the import, modification and export of Vadis/VBF file
- Import VBF-Files
- Export VBF-Files
Attention: Even though all known checksums are corrected, we cannot guarantee that the exported tuning file can be programmed with VBF programming tools into the ECUs.
Version details
| Date | Version | * | Change |
| 08.07.2025 | 1.039 | Fixed | Crash with a specific file |
| 02.09.2024 | 1.038 | New | Memory layout improved in some cases |
| 28.11.2022 | 1.037 | New | Import improved for some Denso files |
| 14.02.2022 | 1.036 | Fixed | Address of empty area in special case corrected |
| 11.02.2022 | 1.035 | Fixed | Fillbyte default value could be wrong |
| 05.05.2021 | 1.034 | Fixed | File format checksum wasnt calculated correctly for some files |
| 02.03.2021 | 1.033 | New | Element-detection improved for large projects |
| 17.11.2020 | 1.032 | New | Improved element layout for 16MB files |
| 06.04.2020 | 1.031 | Fixed | Error in the element layout for some files |
| 09.12.2019 | 1.030 | Fixed | Some files could not be imported |
| 18.06.2019 | 1.029 | New | Another file variation supported |
| 04.06.2019 | 1.028 | Fixed | Element assignment improved |
| 27.12.2018 | 1.027 | Fixed | Possible error in element order could lead to overlapping elements |
| 14.12.2018 | 1.026 | New | Addresses for Tricore improved and elements reduced |
| 15.08.2018 | 1.025 | New | Address/Element corrections for more file variations |
| 07.08.2018 | 1.024 | New | Another format variation supported |
| 19.03.2018 | 1.023 | Fixed | Wrong element name when more that 50 elements |
| 06.12.2017 | 1.022 | Fixed | Checksum was sometimes wrong |
| 09.11.2017 | 1.021 | New | Support for MD1/MG1 files |
| 29.09.2017 | 1.020 | New | Improved compatibility: Compressed files are now recompressed on export. If they were imported with this version. |
| 12.09.2017 | 1.019 | Fixed | Uses the old memory layout for some Denso files |
| 08.09.2017 | 1.018 | New | Memory-Layout improved for Denso files |
| 07.09.2017 | 1.017 | New | Another format variation can be imported |
| 07.07.2017 | 1.016 | New | New internal file version supported |
| 16.06.2017 | 1.015 | Fixed | Error during element detection |
| 27.02.2017 | 1.014 | New | New internal filetype supported |
| 25.08.2016 | 1.013 | New | Calculation of additional checksum which is present in some files |
| 12.01.2016 | 1.012 | Fixed | Possible crash when exporting |
| 06.01.2016 | 1.011 | New | Internal improvements |
| 03.07.2014 | 1.010 | Fixed | Improved Simens file import regarding checksums |
| 14.05.2014 | 1.009 | Fixed | Problems with files with overlapping elements. |
| 02.04.2013 | 1.008 | Fixed | Possible crash for VBF files with overlapping elements. |
| 21.09.2012 | 1.007 | New | Import improved |
| 08.03.2012 | 1.006 | Fixed | Fixed crash on import |
| 01.09.2011 | 1.005 | Fixed | Improved element assignment at SID803 |
| 20.06.2011 | 1.003 | New | Filling of gaps with 00 at SID807 |
| 10.12.2008 | 1.002 | New | Element conversion improved |
| 04.12.2008 | 1.001 | Fixed | Problem at SID803 |
| 06.11.2008 | 1.000 | New |
Caterpillar FLS/FL2 Import/Export (FL2-Export: see details)
Part-No: OLS1002
Description: Import and export Caterpillar FLS/FL2 files. FL2-Exports cannot be used in the original tool.
More information
This DLL allows the import and export of FLS files. An export is only possible for project which were imported with this plugin.
FL2-Files can be imported.
Unfortunately, we cannot correct the cryptographic FL2 checksum. The exported FL2 file can therefore NOT be programmed with the original tool. In addition, there are some FL2 files that currently cannot be exported at all.
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
Provided functions:
- Import FLS-Files
- Import FL2-Files
- Export FLS-Files
- Export FL2-files (limited)
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 30.01.2025 | 1.043 | New | Another file variant is now supported |
| 24.10.2024 | 1.042 | Fixed | Checksum compatibility improved |
| 23.10.2024 | 1.041 | New | Import+Export fundamentally revised due to some special files |
| 07.09.2023 | 1.040 | Fixed | Internal improvements regarding paths |
| 17.08.2023 | 1.039 | New | Export of projects with non-unique addresses improved |
| 09.06.2023 | 1.038 | New | Improved import of elements for some files |
| 17.04.2023 | 1.037 | Fixed | Better behavior in case of special export errors |
| 25.11.2022 | 1.036 | New | Improved Decryption |
| 05.10.2022 | 1.035 | Fixed | FL2 import didnt work from CD |
| 22.06.2022 | 1.034 | Fixed | Import didnt work for some files |
| 02.06.2022 | 1.033 | New | Another format format variation supported |
| 24.05.2022 | 1.032 | New | Another variant can be imported now |
| 15.11.2021 | 1.031 | New | Warning if file format checksum cant be corrected |
| 22.07.2021 | 1.030 | Fixed | Import faster and another variation |
| 22.03.2021 | 1.028 | New | Export imitates the import-file in some cases better requires re-importing the source file |
| 01.03.2021 | 1.027 | Fixed | PartNumber could be too short when exporting |
| 26.02.2021 | 1.026 | Fixed | Import as version didnt always work |
| 25.02.2021 | 1.025 | New | LUA compatibility improved |
| 24.02.2021 | 1.024 | New | LUA compatibility improved |
| 28.10.2020 | 1.023 | Fixed | Import of new file variant. Requires WinOLS 4.47.04 or manual selection of the file format in the file dialog. |
| 26.08.2020 | 1.022 | Fixed | Export problems for non-unique element addresses |
| 18.05.2020 | 1.021 | New | PartNumber can be changed during export |
| 22.04.2020 | 1.020 | New | Another variant can be imported |
| 02.04.2020 | 1.019 | Fixed | Import of some files didnt work / took forever |
| 25.06.2019 | 1.018 | Fixed | Export didnt work properly for some projects |
| 06.06.2019 | 1.017 | New | Import of an additional FL2 variant is now supported |
| 04.03.2019 | 1.016 | New | Another file format variation can be imported |
| 12.02.2019 | 1.015 | Fixed | Some files could not be imported |
| 05.02.2019 | 1.014 | Fixed | Addresses were sometimes interpreted wrong |
| 02.10.2018 | 1.013 | Fixed | Wrong import for some projects |
| 19.07.2018 | 1.012 | New | Experimental FL2-Export now with warning note available again |
| 02.07.2018 | 1.011 | Fixed | Experimental FL2-Export deactivated. |
| 29.06.2018 | 1.010 | Fixed | Sometimes blocks were stored at the wrong address. |
| 27.06.2018 | 1.009 | Fixed | Missing error message when required third-party tool was missing |
| 07.06.2018 | 1.008 | Fixed | Import as version could deliver incorrect values |
| 09.03.2018 | 1.007 | New | FL2-Re-Export Experimental; Careful with the Suffix, WinOLS 4.02 will suggest it correctly |
| 09.03.2018 | 1.007 | New | FL2-Import Beta |
| 22.02.2018 | 1.006 | Fixed | Export was bad for some file types |
| 22.12.2017 | 1.005 | Fixed | Possible storage error |
| 23.11.2017 | 1.004 | Fixed | For some files the created elements were too big |
Part-No: OLS1003
Description: With this plugin the DimSport NewGenius can be controlled directly from WinOLS
More information
In cooperation with Dimsport we developed a WinOLS plugin that allows you to use all NewGenius system function directly in WinOLS. This allows you to directly store files in the NewGenius or load from the NewGenius into WinOLS.
The import and export of NewGenius slave files is not available in this first version and will be provided shortly as update. (Requires separate dongle.)
This connector can only be used by NewGenius Master users!
The installation is (like all WinOLS plugins) very easy: This plugin is automatically installed while using the WinOLS update function and then automatically uses the local Dimsport drivers (separate download, Link see below).
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 14.05.2025 | 1.010 | New | Driver link updated |
| 21.03.2025 | 1.009 | New | Link to Dimsport drivers updated. |
| 29.08.2024 | 1.008 | Fixed | Fixed the driver download link |
| 23.10.2023 | 1.007 | New | Link to Dimsport drivers updated |
| 03.05.2022 | 1.006 | New | Elements are supported during export only the active element is used |
| 09.02.2022 | 1.005 | New | 64-Bit compatibility improved |
| 17.12.2021 | 1.004 | New | Updated link to the Dimsport drivers, if theyre not installed yet |
| 08.09.2021 | 1.003 | Fixed | Now also works with WinOLS5 / 64Bit |
| 14.01.2014 | 1.002 | Fixed | Element wasnt created properly |
| 22.06.2011 | 1.001 | New | Improved error handling if driver is missing. |
| 17.06.2011 | 1.000 | New | First version |
Part-No: OLS1004
Description: Import / Export CMD Slave Files, requires a working CMDFlash with connected Master to the computer
More information
In cooperation with CMD Flashtec SA we developed a WinOLS plugin that allows you to import and export CMDFlash slave files.
It needs a working CMDFlash installed on the computer and the master interface connected. Furthermore this option must be enabled in the CMDFlash system.
The Cmdflash.exe application must be running in the background.
The installation is (like all WinOLS plugins) very easy: This plugin is automatically installed while using the WinOLS update function and then automatically uses the local installed CMDFlash system.
Provided functions:
- Import CMD Slave Files
- Export CMD Slave Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 25.11.2021 | 1.011 | New | Error messages improved |
| 25.03.2021 | 1.010 | Fixed | Problem with 64-Bit-Version fixed this requires the upcoming version 3.2.0.211 of the CMDFlash software |
| 29.04.2020 | 1.009 | New | Warning if length of path+filename might cause problems. |
| 10.09.2019 | 1.008 | New | Project properties are now also imported |
| 29.02.2016 | 1.007 | Fixed | Several small bug corrections |
| 15.11.2012 | 1.000 | New | First Version |
| 03.01.2012 | 0 | New | Not yet ready |
Part-No: OLS1005
Description: Exports in EK1 format. For exclusive use with EK1 device
Provided functions:
- Export .ek1, .eke Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 08.11.2022 | 1.011 | New | New format: EKE |
| 08.01.2015 | 1.010 | Fixed | Improved error message |
| 25.06.2013 | 1.009 | Fixed | Problem XP compatibilty |
| 11.06.2013 | 1.000 | New | First Version |
Part-No: OLS1006
Description: Imports odx, odx-f, frf, sgo, sgm, pdx, .sox files
More information
This DLL allows the import of ODX/ODX-F/FRF/SGO/SGM/PDX/SOX-files. An export of these file formats is not supported.
Note: We cannot guarantee 100% format coverage. While many files can be imported, there are also quite a few (e.g. DL501) where this does not work. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
You can Try online if a file can be imported.
Provided functions:
- Import ODX-Files
- Import ODX-F-Files
- Import FRF-Files
- Import SGO-Files
- Import SGM-Files
- Import PDX-Files
- Import SOX-Files
- Import XML file with ODX content (OLS1006 is not a general XML importer and can only import some very specific XML files. The importer automatically recognizes whether it is responsible for a specific XML file).
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 23.05.2025 | 1.080 | New | Another file format variant odx-xml can be imported |
| 09.01.2025 | 1.079 | Fixed | Possible crash with defective file |
| 30.07.2024 | 1.078 | New | Several format variants improved during import |
| 17.04.2024 | 1.077 | New | Import improved |
| 04.04.2024 | 1.076 | Fixed | ODX-F import improved |
| 14.11.2022 | 1.075 | New | Improved element addresses for Simos 23.41 SF6 and Simos 23.42 SF8 |
| 06.10.2022 | 1.074 | New | Better element support for Siemens PDK |
| 22.08.2022 | 1.073 | New | Extended import for some Simos |
| 11.07.2022 | 1.072 | New | Another file variant can now be imported |
| 15.02.2022 | 1.071 | New | Better addresses for AL552 / AL952 |
| 11.02.2022 | 1.070 | Fixed | Problems with pdx-import |
| 11.02.2022 | 1.070 | New | Support for AL552 / AL952 |
| 26.01.2022 | 1.069 | New | Support for Simos15 SF7 |
| 17.11.2021 | 1.068 | Fixed | Stability improved |
| 12.11.2021 | 1.067 | New | Support for ASG1 files |
| 26.08.2021 | 1.066 | Fixed | Wrong element addresses for some files |
| 05.08.2021 | 1.065 | New | Several detail improvements |
| 18.02.2021 | 1.064 | Fixed | Internal fix |
| 15.02.2021 | 1.063 | Fixed | Possible crash when importing some files |
| 25.01.2021 | 1.062 | New | Import improved |
| 02.12.2020 | 1.061 | New | SDIx import improved |
| 24.07.2020 | 1.060 | Fixed | Wrong project size for a special kind of files |
| 11.05.2020 | 1.059 | Fixed | Hardware element sizes could be too large in special case |
| 15.04.2020 | 1.058 | New | Now import of .sox files is supported |
| 02.04.2020 | 1.057 | Fixed | Import improved |
| 25.03.2020 | 1.056 | New | Improved SGO import function |
| 09.03.2020 | 1.055 | New | More files supported and many detail improvements |
| 19.02.2020 | 1.054 | New | Import improved |
| 19.12.2019 | 1.053 | New | Import improved |
| 17.12.2019 | 1.052 | Fixed | Address correction |
| 18.09.2019 | 1.051 | New | Support for Simos 12.9 files |
| 13.11.2018 | 1.050 | New | MDG1 map area only |
| 06.11.2018 | 1.049 | New | Support for Siemens PDK |
| 04.10.2018 | 1.048 | Fixed | For MED17 a section was missing |
| 01.10.2018 | 1.047 | Fixed | Text error corrected |
| 01.10.2018 | 1.046 | New | Element import is now more maps-targeted. |
| 01.10.2018 | 1.046 | New | New ECUs: Simos18, Simos20.20, Simos16.1, Simos16.21 |
| 24.09.2018 | 1.045 | New | Support for MED 17.1.10 and more Simos types |
| 22.08.2018 | 1.044 | New | Element-Handling improved |
| 15.08.2018 | 1.043 | New | More DQ/AL variations can now be imported |
Part-No: OLS1007
Description: Required functions for OLS16/OLS300/External Simulators
More information
This DLL contains the central functions for the support of simulators in WinOLS. It is required for the use of OLS16, OLS300 and external simulators.
External simulators: Here WinOLS automatically exports the project after each change as binary file(s) or Motorola Hex. This can then be further processed by programs from other manufacturers.
Both the simulator and the real-time export are started via the menu area:
Project > Hardware > Simulator
Note: Customers who already purchased OLS16 or OLS300, get this Plugin for free.
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 17.08.2016 | 1.00 | New | First Release |
Part-No: OLS1008
Description: Import/Export for unencrypted CFF files
More information
This DLL allows the import and export of unencrypted (binary) CFF files. CFF files with XML content are not supported. An export is only possible for files imported with this plugin.
Currently known ECUs:
| ECU | Import | Mod + CS | Binary export | Export CFF/ Prog |
| Conti/Temic ACM / MCM | Yes | OLS824 | Yes, with Offset 0x20000 | Yes |
| Bosch MED17 | Yes | OLS807 | Yes, map area | Yes, but not for programming |
| Siemens VGS NAG2 | Yes | OLS817 | Yes, with offset 0x40000 | Not tested yet |
| Siemens VGS NAG4 | Yes | OLS817 | Yes, with offset 0x50000 | Not tested yet |
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
Provided functions:
- Import CFF-Files
- Export CFF-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 05.08.2022 | 1.09 | New | Another format variation supported |
| 03.05.2022 | 1.08 | Fixed | File format checksum wasnt calculated correctly in some cases |
| 20.03.2020 | 1.07 | New | New format variation |
| 13.02.2020 | 1.06 | Fixed | Import didnt work for some files |
| 10.12.2018 | 1.05 | Fixed | Import was cancelled for some files |
| 22.11.2018 | 1.04 | New | Address management improved |
| 19.11.2018 | 1.03 | New | Empty blocks are inserted for better binary export |
| 19.11.2018 | 1.03 | New | Another file format checksum Variation corrected |
| 14.11.2018 | 1.02 | New | Another checksum in the file format corrected |
| 11.05.2018 | 1.01 | New | Improved: Element names |
| 07.05.2018 | 1.00 | New | First release |
| 26.04.2018 | 0 | New | Not yet ready |
Part-No: OLS1009
Description: Imports XML/BIN pairs
More information
This DLL allows the import of BMW original files. For the import always 2 files (binary and XML) are necessary. Usually the bin/xml suffix is followed in the filename by another suffix consisting of numbers. Apart from bin/xml, the two filenames must be identical. To start the import, simply drag both files into WinOLS or select both files in the Import-Wizard.
Since version 1.02 1 BSW file can be imported instead of the two mentioned files.
Since version 1.07 delta files (recognizable by the file name) can also be imported. Delta files always refer internally to another file. This file does not have to be imported, it just has to be in the same folder, Winols will find it automatically.
An export in these formats is not supported.
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
Provided functions:
- Import BMW BIN+XML-Files
- Import BSW-Files
- Import 0PA-Files
- Import 0DA-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 24.04.2024 | 1.13 | Fixed | Error at end of block for certain files |
| 26.11.2021 | 1.12 | New | Error handling again improved |
| 26.11.2021 | 1.11 | New | Error handling improved |
| 27.04.2020 | 1.10 | New | Improved Address-Handling |
| 22.05.2019 | 1.09 | New | Improved strategy for element creation |
| 19.03.2019 | 1.08 | Fixed | Endian was wrong for short areas in some cases |
| 07.03.2019 | 1.07 | New | Import of delta files now supported. |
| 11.02.2019 | 1.06 | New | Wizard helps you now in case of overlapping source files |
| 06.02.2019 | 1.05 | New | Better error information for overlapping source data |
| 08.01.2019 | 1.04 | Fixed | Correction for the fill area and improved error message |
| 07.01.2019 | 1.03 | New | ECU-dependent sorting of areas and filling of gaps between areas |
| 06.12.2018 | 1.02 | New | Import of BSW-Files is not supported |
| 08.11.2018 | 1.01 | New | Format variation supported |
| 06.11.2018 | 1.00 | New | First version |
Part-No: OLS1010
Description: Imports / Exports CRE files
More information
This DLL allows the import and export of CRE files. An export is only possible for files imported with this plugin.
For the correct export of the CRE file you need a plugin to calculate the checksum EDC17, EDC7, EDC16.
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
Provided functions:
- Import CRE-Files
- Export CRE-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 12.04.2023 | 1.01 | New | Improvements regarding the compatibility of the export |
| 22.05.2019 | 1.00 | New | First release |
Part-No: OLS1011
Description: Requires WinOLS5 + an internet connection and bFlash API key
.sbdc; Requires WinOLS5 + bFlash API key
More information
Note: The feature to connect the WinOLS visualizer with bTrace is no longer supported by B&C.
This DLL allows WinOLS to import and export B&C bFlash slave files (*.sbdc).
Requires:
- WinOLS 5
- bFlash API key
Please enter the API key in WinOLS under "F12 > Third party".
Provided functions:
- Import bFlash slave files
- Export bFlash slave files
Tip: This plugin can also export projects that were not imported with OLS1011. To do this, change the project type to "bFlash slave":
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 05.05.2023 | 1.08 | Fixed | Export problem for some files |
| 01.02.2023 | 1.07 | New | Plugin renamed. Please contact EVC in case of problems. |
| 31.01.2023 | 1.06 | New | Internal changes |
| 11.07.2022 | 1.04 | Fixed | Error during export |
| 04.05.2022 | 1.03 | Fixed | Internal fix |
| 14.04.2022 | 1.02 | Fixed | Internal fix |
| 27.10.2021 | 1.01 | Fixed | Internal fix |
| 27.08.2019 | 1.00 | New | First release |
| 29.05.2019 | 0 | New | Not yet ready |
Part-No: OLS1012
Description: Imports/Exports map changes in DCM files
More information
This DLL allows the import and export of map values in DCM files.
The import requires that the maps already exist with the correct ID in the project. An export is only possible for files imported with this plugin.
New/Beta: From now on an export is also possible without previous import. This requires at least WinOLS 5.19 and a filled Id field.
Because this plugin effectively does not import/export maps but hexdump values, import/export are called via the normal WinOLS import/export functions. (So not like the A2L import).
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
Provided functions:
- Import DCM-Files
- Export DCM-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 08.09.2023 | 1.06 | New | Error message improved |
| 23.06.2023 | 1.05 | New | Improved safety in the assignment of the maps |
| 26.05.2023 | 1.04 | New | Support for GRUPPEN objects |
| 25.05.2022 | 1.03 | New | Export: Info text und function a bit improved |
| 09.03.2022 | 1.02 | New | Now also export maps without ID |
| 09.03.2022 | 1.02 | New | Export selected maps if 1 selected |
| 09.03.2022 | 1.02 | New | Import/Export: .lab-Dateien als Selektion verarbeiten können einfache Text Files mit einer Liste der IDs |
| 12.01.2022 | 1.01 | New | Export without previous import (Beta; Only WinOLS5) |
| 25.06.2019 | 1.00 | New | First release |
Part-No: OLS1013
Description: .hex, vds both encrypted
More information
This DLL allows the import and export of VDS files and files with the suffix HEX, which are encrypted like VDS files. An export is only possible for files imported with this plugin.
Note: This DLL is not a general "protection" for HEX files. It simply imports/exports the file format of a manufacturer. Encrypted HEX files can only be processed by tools that are designed for VDS files.
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
Provided functions:
- Import VDS-Files
- Import Encrypted-HEX-Files
- Export VDS-Files
- Export Encrypted-HEX-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 17.02.2025 | 1.007 | Fixed | Crash during export if previously imported with OLS1008 a CFF file |
| 13.01.2025 | 1.006 | New | Elements improved during export |
| 05.11.2024 | 1.005 | New | Fehlermeldung, wenn Datei überlappende Elemente enthält |
| 09.10.2024 | 1.004 | Fixed | Details of the source file format are better imitated during export |
| 27.09.2024 | 1.003 | Fixed | Fixed export problems with elements |
| 29.07.2024 | 1.002 | New | Non-standard file footer is tolerated during import |
| 19.01.2023 | 1.001 | New | Improved: Element size for some files |
| 02.12.2019 | 1.00 | New | First release |
| 25.11.2019 | 0 | New | Not yet ready |
Part-No: OLS1014
Description: Import SMR-F / SMR-FB files
.smr-f
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 29.02.2024 | 1.07 | New | Project property is now saved to ECUStg instead of ECUProd |
| 10.05.2023 | 1.06 | Fixed | Possible crash when importing multiple files at the same time |
| 29.03.2023 | 1.05 | New | Internal improvement |
| 14.12.2022 | 1.04 | New | Major internal changes |
| 14.12.2022 | 1.04 | New | Import SMR-F MD1CS016 |
| 27.01.2022 | 1.03 | New | Element representation improved |
| 07.06.2021 | 1.02 | Fixed | Wrong address management for some files |
| 05.03.2021 | 1.01 | New | File type variation can now be imported,too |
| 24.01.2020 | 1.00 | New | Version 1.00 |
| 30.12.2019 | 0 | New | Not yet ready |
Part-No: OLS1015
Description: Imports / exports .nav.dec, .nav.zenc, .nav Dateien
.nav.dec, .nav.zenc, .nav
More information
This DLL allows the import and export of .nav.zenc and .nav.dec files. Export is only possible for files imported with this plugin.
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. Also that exported file can be used in all third party programs, we can not guarantee at this time. If you have such a problematic file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
Provided functions:
- Import NAV-Files
- Import NAV.DEC-Files
- Import NAV.ZENC-Files
- Export NAV-Files
- Export NAV.DEC-Files
- Export NAV.ZENC-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 12.01.2024 | 1.07 | New | Better element layout for one file type |
| 30.03.2023 | 1.06 | New | Virtual elements are not created anymore |
| 21.12.2022 | 1.05 | New | Import of SID9xx files improved |
| 25.08.2022 | 1.04 | New | Better element sizes in one case |
| 16.08.2022 | 1.03 | New | Now with import/export of .nav files |
| 01.06.2022 | 1.02 | Fixed | Import problem for .dec files wasnt this plugins job |
| 02.05.2022 | 1.01 | Fixed | Crash for one special file |
| 25.02.2022 | 1.00 | New | First release |
| 30.08.2021 | 0 | New | Not yet ready |
Part-No: OLS1016
Description: Autotuner Slave Files Import/Export
Requires WinOLS5 + an internet connection and Master tool ID and Autotuner API key
More information
In cooperation with Autotuner we developed a WinOLS plugin that allows you to automatically decrypt and encrypt your Autotuner slave files. An export is only possible for project which were imported with this plugin.
This service requires additional fees (per month and/or file) to be paid to Autotuner which are not included in the purchase price of this plugin. Please contact Autotuner for the exact costs.
A valid Autotuner master API key is required to use this plugin. Please contact Autotuner to request your master API key before buying this plugin, fees may apply.
Requires:
- WinOLS 5
- Autotuner-Master-API key
Please enter the API key in WinOLS under "F12 > Third party".
Provided functions:
- Import Autotuner-Slave-Files
- Export Autotuner-Slave-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 08.05.2025 | 1.04 | New | Error message improved |
| 18.09.2023 | 1.03 | Fixed | Default element was not created by plugin, which caused detail problems during import |
| 29.11.2021 | 1.02 | New | Improved import of project properties |
| 11.11.2021 | 1.01 | New | Improved error information |
| 28.10.2021 | 1.00 | New | First Release |
Part-No: OLS1017
Description: Autoflasher Slave Files Import/Export
Requires WinOLS5 + an internet connection and Aufoflasher API key
More information
In cooperation with Autoflasher we developed a WinOLS plugin that allows you to automatically decrypt and encrypt your Autoflasher slave files. An export is only possible for project which were imported with this plugin.
A valid Autoflasher master API key is required to use this plugin. Please contact Autoflasher to request your master API key before buying this plugin, fees may apply.
Requires:
- WinOLS 5
- Autoflasher-Master-API key
Please enter the API key in WinOLS under "F12 > Third party".
Provided functions:
- Import Autoflasher-Slave-Files
- Export Autoflasher-Slave-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 08.05.2025 | 1.003 | New | Error message improved |
| 12.01.2023 | 1.002 | Fixed | Second export problem fixed |
| 12.01.2023 | 1.001 | Fixed | Export didnt work |
| 30.11.2022 | 1.000 | New | First release |
| 22.11.2022 | 0 | New | Not yet ready |
Part-No: OLS1018
Description: Visualizer live connector
More information
This DLL allows to connect the WinOLS Visualizer with third party programs (which must be prepared for this). Also CSV files can be dragged into the WinOLS Visualizer.
EVC provides the necessary API (docu+example code) to other companies free of charge:
- C#
- C++
The following programs already work with the WinOLS Visualizer:
- VehiCAL
- ismFlash
Note: This requires at least WinOLS 5.29.
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 01.02.2023 | 1.007 | New | Plugin renamed. Please contact EVC in case of problems. |
| 31.01.2023 | 1.000 | New | First release |
| 30.01.2023 | 0 | New | Not yet ready |
Part-No: OLS1019
Description: Imports/exports Cummins xcal files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 13.01.2025 | 1.007 | New | Improved export compatibility |
| 08.05.2024 | 1.006 | New | Suffix during export improved |
| 24.04.2024 | 1.005 | Fixed | Error at end of block for certain files |
| 19.04.2024 | 1.004 | New | Export improved |
| 23.10.2023 | 1.003 | New | Improved: Element layout during import |
| 27.04.2023 | 1.002 | Fixed | Export didnt always work |
| 22.04.2023 | 1.001 | New | Compatibilty improved |
Part-No: OLS1020
Description: Magicmotorsport Slave Import/Export
Requires WinOLS5 + an internet connection and Magicmotorsport registration / API key
.mmf; Requires one-time, paid registration with Magicmotorsport
More information
In cooperation with Magicmotorsport, we have developed a WinOLS plugin that allows you to automatically decrypt and encrypt your Magicmotorsport slave files.
This service requires additional fees (one-time paid registration) which are to be paid to Magicmotorsport and are not included in the purchase price of this plugin. Please contact Magicmotorsport for the exact costs.
A valid Magicmotorsport X-API-key / X-SN / SN is required to use this plugin. Please contact Magicmotorsport to request this data before purchasing this plugin.
Requires:
- WinOLS 5
- Paid registration with Magicmotorsport
- Magicmotorsport X-API-key / X-SN / SN
Please enter this in WinOLS under "F12 > Third-party provider".
Provided functions:
- Import Magicmotorsport slave files
- Export Magicmotorsport slave files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 08.05.2025 | 1.005 | Error message improved | |
| 21.03.2025 | 1.004 | New | Single export of elements requires WinOLS 5.76.11 |
| 06.03.2025 | 1.003 | New | Simplified configuration |
| 28.02.2025 | 1.002 | New | Simplified SlaveSN handling |
| 21.02.2025 | 1.001 | Fixed | Import suffix detection didnt always work |
| 20.02.2025 | 1.000 | New | First version |
| 05.02.2025 | 0 | New | Not yet ready |
Part-No: OLS1021
Description: Imports/exports JCB files. Imports JCBS files.
.jcb; .jcbs
More information
This DLL allows the import and export of .JCB and .JCBS files. An export is only possible for files that have been imported with this plugin and only in .JCB format. Projects created from .JCBS files can be exported as .JCB files.
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. Also that exported file can be used in all third party programs, we can not guarantee at this time. If you have such a problematic file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
Provided functions:
- Import JCB files
- Export JCB files
- Import JCBS files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 21.03.2025 | 1.001 | New | First release |
| 13.03.2025 | 0 | New | Not yet ready |
Maps (6)
Part-No: OLS521
Description: DAMOS and ASAP2 Import
More information
The vehicle manufacturers are using development systems to match ECUs to the according engines. These systems are displaying the maps including scaling, sampling points and labels for the developers while only the data contents themselves are being stored in the EPROM and built in to the ECU.
All other information is being stored into files which contain the addresses and names of the maps.
The DAMOS and ASAP2 file formats have qualified the best for this purpose and are being used by almost all German vehicle manufacturers.
Few tuners have the proper contacts to the manufacturers or racing departments who can get their hands on the data file for a certain ECU. For these "advanced tuners" the DAMOS/ASAP2 import option has been implemented in order for them to be able to use the map information and properties from such a file directly in a WinOLS project.
For this task filters and choices are available to sort out only the required map information from the 2000 - 10000 maps contained in such a file.
Provided functions:
- Import A2L-Files
- Import ASAP2-Files
- Import DAM-Files
- Import DAMOS-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 09.07.2025 | 5.036 | Fixed | RAM areas that were split by elements were calculated incorrectly |
| 21.03.2025 | 5.035 | New | Offset detection improved |
| 21.03.2025 | 5.035 | New | Accelerated: A2L files with many MATRIX_DIM tokens |
| 21.03.2025 | 5.035 | New | Dark color mode is now supported |
| 03.03.2025 | 5.034 | Fixed | Possible error with offset suggestion if import from an A2L file was run 2x |
| 03.03.2025 | 5.034 | Fixed | Problems with quotation marks in strings |
| 25.02.2025 | 5.033 | New | Improved: Offset suggestion is now for offset 2 |
| 25.02.2025 | 5.033 | New | Improved: Offset detection |
| 28.01.2025 | 5.032 | New | Support for importing MATRIX_DIM |
| 17.01.2025 | 5.031 | New | Support for import of ARRAY_SIZE |
| 10.06.2024 | 5.030 | Fixed | A2L-Import didnt work for some paths |
| 29.05.2024 | 5.029 | New | Improved Import of RAM-Bit-Maps |
| 29.02.2024 | 5.028 | New | Improved handling of defective A2L files |
| 30.01.2024 | 5.027 | Fixed | Offset was sometimes recognized incorrectly |
| 15.01.2024 | 5.026 | New | Import speed improved |
| 22.11.2023 | 5.025 | New | A2L files with massive defects are now recognized a defective |
| 23.10.2023 | 5.024 | Fixed | Problem with manual offset |
| 08.09.2023 | 5.023 | Fixed | Axis lengths correction didnt work for BYTE bitwidth |
| 08.09.2023 | 5.023 | Fixed | Problems with offset an RAM areas |
| 23.08.2023 | 5.022 | New | Flash elements are now imported as RAM areas |
| 23.08.2023 | 5.022 | New | Value ranges are imported and activated as limitation starting with WinOLS 5.48 |
| 31.05.2023 | 5.021 | Fixed | Possible error with address assignment by elements for projects with exactly 1 element |
| 16.05.2023 | 5.020 | Fixed | Map size was sometimes wrong |
| 13.04.2023 | 5.019 | Fixed | Error message during offset search for some projects |
| 28.02.2023 | 5.018 | Fixed | Some RAM maps were not imported correctly |
| 14.02.2023 | 5.017 | Fixed | Correction for a bug in the previous release |
| 09.02.2023 | 5.016 | Fixed | Maps with changed sizes were not always imported |
| 11.01.2023 | 5.014 | Fixed | Crash in special case |
| 29.12.2022 | 5.013 | Fixed | Problems with some special files |
| 15.12.2022 | 5.012 | Fixed | 2 problems with cuboid 3d maps |
| 12.12.2022 | 5.010 | Fixed | Problems with Chinese codepage |
| 02.11.2022 | 5.009 | New | Import accelerated in some cases |
| 05.10.2022 | 5.008 | Fixed | Problem when axis was in a different element than the map |
| 19.09.2022 | 5.007 | Fixed | Problems with Chinese codepage |
| 06.09.2022 | 5.006 | Fixed | Import problem for some Damos maps |
| 15.07.2022 | 5.005 | New | Faulty recursive subfolders are now ignored |
| 23.06.2022 | 5.004 | New | Offset-detection improved |
| 07.06.2022 | 5.003 | New | Offset detection improved |
| 02.06.2022 | 5.002 | Fixed | Problem with displaying the selected maps when using the search function |
| 18.05.2022 | 5.001 | New | Import of subfolder structure now optional |
Part-No: OLS523
Description: Import maps. Requires ecfg file + address mapping file
More information
Option: Cummins ecfg Importer
The import filter OLS523 (Cummins ecfg Importer) imported maps from Cummins files.
For technical reasons, 1-2 files are required:
- The ecfg file
- Optional: A txt file with information about which map ID can be assigned to which address.
If OLS523 is installed, it is sufficient to select the ecfg file and drag them into the WinOLS project together. It then automatically starts an import process, which is very similar to OLS521 (DAMOS / A2L - import filter).
The format of the optional txt files is simple. Each line contains the id and the address, in each case as a hex. All common separators like ;, - spaces or tabs are accepted. Additional texts per line are allowed and ignored.
Few tuners have the proper contacts to the manufacturers or racing departments who can get their hands on the data file for a certain ECU. For these "advanced tuners" the ecfg/txt import option has been implemented in order for them to be able to use the map information and properties from such a file directly in a WinOLS project.
For this task filters and choices are available to sort out only the required map information from the 2000 - 10000 maps contained in such a file.
Provided functions:
- Import ECFG-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 19.02.2025 | 1.032 | New | Error message improved |
| 14.02.2024 | 1.031 | Fixed | Import could take an extremely long time for some files |
| 06.09.2023 | 1.030 | New | More uniform progress indicator |
| 12.04.2023 | 1.028 | Fixed | Y axis could be imported incorrectly |
| 22.03.2022 | 1.027 | New | Small preview images for the map selection |
| 17.02.2022 | 1.026 | New | Automatic detection of data improved. |
| 11.01.2022 | 1.025 | New | Automatic detection of data improved. Import may be slightly slower than before. |
| 03.01.2022 | 1.024 | Fixed | Data was sometimes not found |
| 29.12.2021 | 1.023 | Fixed | Import errors for some files |
| 26.10.2021 | 1.022 | Fixed | Some ecfg file were import wrong |
| 15.10.2019 | 1.021 | New | Drag+Drop of text file into last wizard page searches for all lines of the file |
| 15.10.2019 | 1.021 | New | Search-line accepts OR conditions: AB,XY |
| 27.09.2019 | 1.020 | New | Motorola-Endian Support and now 2 Offsets possible |
| 13.08.2018 | 1.019 | Fixed | Start address for 1d maps sometimes slightly wrong |
| 09.08.2018 | 1.018 | Fixed | Sometimes too many maps were imported |
| 09.08.2018 | 1.018 | Fixed | Y-Axis could sometimes be wrong |
| 30.05.2018 | 1.017 | New | Improved import |
| 19.03.2018 | 1.016 | New | Improved automatic id detection |
| 06.11.2017 | 1.015 | New | Folders in ecfg-files are now supported |
| 24.10.2017 | 1.014 | Fixed | Files with uppercase suffix couldnt be imported |
| 09.08.2017 | 1.013 | Fixed | File dialog didnt support .e2m |
| 28.07.2017 | 1.012 | Fixed | Invalid maps were not ignored but inserted at the beginning of the project |
| 26.07.2017 | 1.011 | New | E2M: Precision is imported |
| 26.07.2017 | 1.011 | Fixed | Groups were additionally imported as maps |
| 26.07.2017 | 1.010 | Fixed | E2M: Some maps were ignored during import |
| 26.07.2017 | 1.010 | New | E2M: Folders are imported |
| 24.07.2017 | 1.009 | Fixed | Axis unit wasnt imported for e2m files. |
| 24.07.2017 | 1.008 | Fixed | Axis factor wasnt imported for e2m files. |
| 10.07.2017 | 1.007 | New | Offset can be entered |
| 12.06.2017 | 1.006 | New | Support for .e2m files Beta |
| 12.06.2017 | 1.005 | Fixed | Registration problems on some systems |
| 29.05.2017 | 1.004 | Fixed | Error message on import problems improved |
| 24.04.2017 | 1.003 | New | Support for Block-elements |
| 24.04.2017 | 1.003 | Fixed | Invalid Tables werent skipped |
| 24.04.2017 | 1.002 | New | Support für table and string blocks |
| 20.04.2017 | 1.001 | New | Now supports elements |
| 20.04.2017 | 1.001 | New | Txt files are not required any more |
| 21.03.2017 | 1.000 | New | Now officially 1.000 |
| 20.03.2017 | 0.904 | Fixed | Header-bytes were not skipped for axes |
| 20.03.2017 | 0.904 | Fixed | 1d-maps were not supported |
Part-No: OLS524
Description: Imports maps from Mitsubishi XML files
More information
The import filter OLS524 (Mitsubishi Xml Importer) imported maps from Mitsubishi Xml files.
The required information is sometimes spread over 2 Xml files. In this case both files must be imported AT THE SAME TIME. For this you have 2 options:
- Use the WinOLS menu command to start the import module. Choose both files.
- In the Windows Explorer mark both files (Ctrl+Click) and drag them together into the project window.
It then automatically starts an import process, which is very similar to OLS521 (DAMOS / A2L - import filter).
Filters and selection options are available to take over only the required map data of the partly 2000 - 10000 maps.
We neither have such XML files nor do we have information about how or where to get them.
Provided functions:
- Import Mitsubishi XML-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 23.03.2022 | 1.015 | New | Small preview images for the map selection |
| 22.10.2019 | 1.014 | New | Search-line accepts OR conditions: AB,XY |
| 22.10.2019 | 1.014 | New | Drag+Drop of text file into last wizard page searches for all lines of the file |
| 21.08.2019 | 1.013 | Fixed | Unit/precision/Formular were not imported for some files |
| 05.12.2017 | 1.012 | New | float axes are now automatically recognized, when necessary |
| 28.11.2017 | 1.011 | New | Offset can be entered now start it with the menu item, not with drag+drop |
| 17.11.2017 | 1.010 | Fixed | Text axis wrong on mirrored maps |
| 17.11.2017 | 1.010 | New | Optional logfile on the desktop. To activate, start plugin via the project-menu |
| 14.11.2017 | 1.009 | New | Support for bit fields and text axes |
| 23.06.2017 | 1.008 | Fixed | Factor/Offset werent always correctly imported. |
| 16.06.2017 | 1.007 | Fixed | Choosing 2 XML files manually didnt work |
| 14.06.2017 | 1.006 | Folders, Factor+Offset and improved import quality | |
| 13.06.2017 | 1.005 | Fixed | Several import errors fixed |
| 12.06.2017 | 1.004 | Fixed | Registration problems on some systems |
| 15.05.2017 | 1.003 | Fixed | Import of fractionend map data didnt work. |
| 15.05.2017 | 1.002 | Fixed | Problems with multiple rom tags in one file |
| 12.05.2017 | 1.001 | Fixed | Problems with the registration |
| 05.04.2017 | 1.000 | New | First official release |
| 05.04.2017 | 0.901 | Fixed | Smaller text corrections |
| 04.04.2017 | 0.900 | New | first release |
| 03.04.2017 | 0 | New | Not yet ready |
Part-No: OLS525
Description: Imports map details from PRM files; The maps need exist before the import.
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
More information
The import filter OLS525 (PRM Importer) imported maps from PRM files.
Note: We cannot guarantee 100% format coverage. Many files can be imported, but there are also some where this is not possible. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
If OLS525 is installed, it is sufficient to select the PRM file and drag them into the WinOLS project together. It then automatically starts an import process, which is very similar to OLS521 (DAMOS / A2L - import filter).
IMPORTANT: For PRM files the maps must already exist in most cases. (No matter if as normal or potential map.) The importer only adds the available detailed information like name or unit. Only in some special cases can the plugin create the map.
We neither have such PRM files nor do we have information about how or where to get them.
Provided functions:
- Import PRM-Files
Version details
| Date | Version | * | Change |
| 23.03.2022 | 1.001 | New | Small preview images for the map selection |
| 26.11.2019 | 1.000 | New | First Version Beta |
| 03.04.2017 | 0 | New | Not yet ready |
Part-No: OLS526
Description: Imports map from TunerPro Xdf files
More information
The import filter OLS526 (TunerPro XDF Importer) imported maps from TunerPro XDF files.
Note: We cannot guarantee 100% format coverage. While many files can be imported, there are also quite a few (e.g. non-XML files) where this will not work. If you have such a file, please send it to EVC. Furthermore, we cannot guarantee that all files of this type can be imported in the future.
New / Beta: XDF-Export. In WinOLS start it via Projekt Export & Import.
If OLS526 is installed, it is sufficient to select the XDF file and drag them into the WinOLS project together. It then automatically starts an import process, which is very similar to OLS521 (DAMOS / A2L - import filter).
We neither have such XDF files or do we have information about how or where to get them.
Provided functions:
- Import XDF-Files
- Export XDF-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 17.01.2025 | 1.037 | New | Improved import of maps with index axes |
| 16.12.2024 | 1.036 | New | XDFFUNCTION import improvements |
| 11.12.2024 | 1.035 | New | XDFFUNCTION is now imported |
| 25.11.2024 | 1.034 | New | Error message improved |
| 11.11.2024 | 1.033 | Fixed | Problems with some XDFPATCHs |
| 08.11.2024 | 1.032 | New | XDFPATCH-Import |
| 25.08.2022 | 1.031 | Fixed | Export: SkipBytes in the map itself were not handled correctly |
| 23.08.2022 | 1.030 | Fixed | Individual values were in the wrong format after export |
| 23.08.2022 | 1.030 | Fixed | Endian could be wrong in certain cases |
| 23.08.2022 | 1.030 | New | Radix import/export WinOLS5 only |
| 03.05.2022 | 1.029 | New | Numerous improvements during import and export |
| 23.03.2022 | 1.028 | New | Small preview images for the map selection |
| 26.10.2021 | 1.027 | Fixed | Offset-problem for some files |
| 09.09.2021 | 1.026 | Fixed | Axes were swapped incorrectly for some maps |
| 26.08.2021 | 1.025 | New | Import of special-case-axis supported |
| 28.06.2021 | 1.024 | New | Axes with user-defined texts |
| 18.05.2021 | 1.023 | Fixed | Several import errors fixed |
| 11.05.2021 | 1.022 | Fixed | Fixed another variation of wrong axes |
| 11.05.2021 | 1.021 | Fixed | Some axes could be imported wrong |
| 24.09.2020 | 1.020 | Fixed | Possible crash during import since previous update |
| 16.09.2020 | 1.019 | Fixed | Incorrect userdef-axis for some files |
| 16.09.2020 | 1.019 | Fixed | Wrong addresses for some files |
| 10.06.2020 | 1.018 | Fixed | Unused dialog elements removed, which were visible when starting without drag+drop |
| 24.04.2020 | 1.017 | Fixed | Export didnt use element offsets |
| 02.04.2020 | 1.016 | Fixed | Export of very small factors didnt work properly |
| 27.01.2020 | 1.015 | Fixed | Better error message when file cant be imported |
| 22.01.2020 | 1.014 | Fixed | Problem with quotation mark in folder name |
| 07.01.2020 | 1.013 | Fixed | Detail error |
| 19.12.2019 | 1.012 | Fixed | Wrong precision if nothing was entered in WinOLS |
| 13.12.2019 | 1.011 | Fixed | Several corrections in the export process |
| 27.11.2019 | 1.010 | New | Now with XDF export Beta! In WinOLS start it via Projekt Export & Import. |
| 12.11.2019 | 1.009 | Fixed | Crash for some files |
| 29.10.2019 | 1.008 | New | Sign-detection improved |
| 29.10.2019 | 1.008 | New | Skip-bytes are now supported |
| 22.10.2019 | 1.007 | New | Search-line accepts OR conditions: AB,XY |
| 22.10.2019 | 1.007 | New | Drag+Drop of text file into last wizard page searches for all lines of the file |
| 11.09.2019 | 1.006 | New | Import with offset or elements now supported |
| 01.04.2019 | 1.005 | New | Endian detection improved |
| 14.02.2019 | 1.004 | Fixed | Some fields were not imported |
| 13.02.2019 | 1.003 | Fixed | For file format variations axis data was not imported |
Part-No: OLS527
Description: Imports map from Mitsubishi mm3 files
More information
The import filter OLS527 (Mitsubishi MM3 Importer) imports maps from Mitsubishi MM3 files.
Note: This plugin is in experimental stage. It can import a lot of files, but there are also a lot where it does not work or only partially. If you have such a file, please send it to EVC. Furthermore we cannot guarantee that all files of this kind can be imported in the future.
If OLS527 is installed, it is sufficient to select the MM3 file and drag it into the WinOLS project. An import process will then start automatically, which is clearly oriented towards OLS521 (DAMOS/A2L - Import Filter).
We do not have such MM3 files available, nor can we provide sources of supply.
Provided functions:
- Import MM3-Files
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 19.07.2022 | 1.000 | New | First release beta |
| 10.06.2022 | 0 | New | Not yet ready |
Special Stuff (3)
Part-No: OLS530
Description: External control by script languge LUA
More information
With this plugin you can remote-control many WinOLS functions with lua-scripts.
- Scripts can be:
- ...be apploed on-demand on the current project.
- ...run permanently and process in coming files.
- Application samples:
- Read/Write individual bytes in a project.
- Apply changes in each incoming file, depending on the Bosch number an send the result by mail.
- The WinOLS-Online-Checksum-Search is written in lua.
- Important:
OLS530 is a scripting language - not a ready-made solution. This plugin requires programming knowledge and work on your part. We are happy to provide support for errors in the LUA plugin, but cannot provide support for your programming work. - Download:
- Debugger:
As of WinOLS 5.70 / OLS530 3.005 there is a separate LUA debugger:
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 08.11.2024 | 3.006 | New | Internal change for requirex |
| 07.10.2024 | 3.005 | New | Preparations for the new LUA debugger |
| 24.08.2021 | 3.004 | Fixed | Registration problems on some systems |
| 14.12.2020 | 3.003 | New | Prepares for an important change. WinOLS-functions will soon return a real bool instead of 1/0. |
| 16.03.2015 | 3.002 | Fixed | Registration problems |
| 13.03.2015 | 3.001 | Fixed | Some functions didnt work |
| 08.12.2005 | 2.000 | New | New registration |
| 14.03.2005 | 1.000 | New | New |
Part-No: OLS540
Description: Automatically translates map names from German to English (Beta)
More information
WinOLS projects can contain many maps. However, these are often labeled in German, which not everyone understands. This WinOLS plugin allows es to translate the maps from German to English automatically.
To start it use this menu item:
Project > Ex- & Import > Translate map texts
Note: This is a machine translation. It is neither 100% complete nor 100% correct. We can therefore not guarantee the result.
Tip: Technically savvy and dedicated users can add translations for other languages themselves. The required translation tables are not not provided by EVC, but must come from the user. Instructions
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 29.11.2023 | 1.18 | New | Now also translate EN-DE |
| 18.02.2022 | 1.17 | New | Translation improved and accelerated |
| 17.08.2021 | 1.16 | Fixed | Possible crash |
| 17.12.2020 | 1.15 | New | Translation expanded+corrected |
| 27.01.2020 | 1.14 | New | Translation expanded+corrected |
| 24.10.2019 | 1.13 | New | Translation improved |
| 25.09.2019 | 1.12 | Fixed | Texts could contain unnecessary spaces |
| 17.09.2019 | 1.11 | New | Translation improved |
| 15.05.2019 | 1.10 | New | Translation improved |
| 01.03.2018 | 1.09 | New | Translation improved |
| 02.06.2017 | 1.08 | New | Translation improved |
| 08.06.2015 | 1.07 | New | Expanded dictionary by 5000 words |
| 03.02.2015 | 1.06 | New | Improved translation engine |
| 29.01.2015 | 1.05 | Fixed | Translation improved |
| 27.01.2015 | 1.04 | Fixed | Translation improved |
| 14.01.2014 | 1.03 | New | Improved translation. Missing texts are logged in the temp folder. |
| 19.04.2013 | 1.02 | Fixed | Windows XP compatibilty fixed |
| 16.04.2013 | 1.01 | Fixed | Translation improved, possible crashes fixed |
| 29.01.2013 | 1.00 | New | First version (beta) |
Part-No: OLS550
Description: Free helper plugin to recognize data areas. Important for the search of similar projects.
Attention: All data for WinOLS5. Checksums for WinOLS4 will no longer be updated after 31.12.2022
Version details
| Date | Version | * | Change |
| 25.04.2025 | 1.30 | New | Missing Denso32 and correction of incorrectly recognized vbf imports. |
| 07.04.2025 | 1.29 | New | CM2xxx, Update MTxxx |
| 07.06.2024 | 1.28 | New | MEMS3 detection adjusted |
| 02.02.2024 | 1.27 | New | Some updates and DCM7.xx |
| 24.11.2023 | 1.26 | New | Bosch M2.x/M5.x; Delphi MTxx |
| 19.10.2023 | 1.25 | New | TEMIC/Conti MCM/ACM, TEMIC Truck XC2287, TRW Volvo Truck EMS + some adjustments |
| 21.08.2023 | 1.24 | New | Update MDG1, TCU1 and Siemens M3D/M4D/M4C. |
| 11.07.2023 | 1.23 | New | Data areas for ITELMA/Mikas MD22/MT22/M240. |
| 27.06.2023 | 1.22 | New | Added identification of missing Delphi DCM3.7. |
| 05.06.2023 | 1.21 | New | CM2xxx adjusted. |
| 30.05.2023 | 1.20 | New | CM850 |
| 10.05.2023 | 1.19 | New | Cummins CM3230/EDC17CP51 improved |
| 28.04.2023 | 1.18 | New | CM2xxx DataAreas.Please update all CM2xxx projects! |
| 20.12.2022 | 1.17 | New | Fillbyte detection at SID9xx as ZENC import |
| 22.08.2022 | 1.16 | New | Phoenix VP44/CR |
| 20.08.2022 | 1.15 | New | Phoenix L14/L21/L33 |
| 05.08.2022 | 1.14 | Fixed | Fixed bug that could lead to crash. |
| 14.12.2021 | 1.13 | New | Siemens MD3/MD4 |
| 10.12.2021 | 1.12 | Added:- Metatron- Cumins CM2xxx- Cumins CM3230B / EDC17CV51- Campi- Bosch DCU-15/SRC- Wabco VCM- TEMIC Truck V1-5 | |
| 28.10.2021 | 1.11 | New | New:Bosch M3.x/M5.92 OLS244Siemens Volvo/Renault/Kia OLS248Bosch BMS46 + BMS OLS251Siemens ECM OLS253Bosch MAN/Scania/JD OLS255Delphi Truck OLS810 |
| 20.08.2021 | 1.10 | Fixed | Error at WinOLS startup fixed |
| 31.03.2021 | 1.09 | New | Added more data areas |
| 01.04.2019 | 1.08 | New | DQ250 |
| 16.03.2019 | 1.07 | New | MED17 / EDC17: Block ID 80 is now also stored as data block |
| 29.01.2019 | 1.06 | Fixed | Error at TDI V4.1 fixed |
| 10.12.2018 | 1.05 | Fixed | SIMOS18 detection improved |
| 18.10.2018 | 1.04 | New | Now also Bosch MDG1 |
| 25.01.2018 | 1.03 | New | Now also Motorola MEMS |
| 06.12.2017 | 1.02 | New | Improved: Denso32New: Delco E39, E78, E80, E83, E87, E98 |
| 26.11.2017 | 1.01 | New | Error in Siemens Tricore fixed, new: Denso32 |
| 08.11.2017 | 1.00 | New | New, free plugin to support the similar projects search |
Checksum Point (6)
| Part-No. | CS points |
| OLS-CKS1 | 1 |
Understanding the Checksum Point System in WinOLS 5
- What is a Checksum Point?
In WinOLS 5, EVC electronic (Germany) introduced a new mechanism called the Checksum Point System.
This is a flexible payment model that allows users to purchase and activate checksum modules, plugins, or projects as needed.
Checksum Points act as a digital currency within the WinOLS ecosystem.
You can buy points in advance and then use them to pay for specific features or services whenever required.
- How Does the Checksum Point System Work?
Each checksum plugin or project in WinOLS has its own point value.
Users can purchase points individually or as part of packages to receive discounted rates.
When you use or activate a checksum module, WinOLS automatically deducts the corresponding number of Checksum Points from your account.
Checksum Points can be used to:
- Purchase Checksum Modules (Import/Export, Maps, Special Items, Checksum Correction)
- Purchase Projects from the EVC Reseller / Online Project Database
- Why Does WinOLS Use a Point System?
EVC chose the Point System because it offers several key benefits:
- Flexible license management – buy points once and use them gradually over time.
- Cost optimization – save significantly by purchasing Checksum Points in larger packages.
- Unified system – the same points can be used across both WinOLS and the reseller project network.
This system is especially useful for tuners, workshops, and professional users who frequently need access to different checksum modules or plugins for various ECU projects.
- Real-World Example
Suppose you are editing an ECU file and WinOLS notifies you that the checksum module for that ECU has not yet been activated.
You can simply use your Checksum Points to unlock it instantly — without additional payment or waiting for a new license.
Once the points are deducted, the checksum module is permanently activated for your use.
- Summary
The Checksum Point System in WinOLS 5 provides a smart and flexible way to purchase checksum modules, plugins, and projects.
It gives users greater control, convenience, and cost efficiency in managing their tuning and calibration workflows.
| Part-No. | CS points |
| OLS-CKS2 | 2 |
Understanding the Checksum Point System in WinOLS 5
- What is a Checksum Point?
In WinOLS 5, EVC electronic (Germany) introduced a new mechanism called the Checksum Point System.
This is a flexible payment model that allows users to purchase and activate checksum modules, plugins, or projects as needed.
Checksum Points act as a digital currency within the WinOLS ecosystem.
You can buy points in advance and then use them to pay for specific features or services whenever required.
- How Does the Checksum Point System Work?
Each checksum plugin or project in WinOLS has its own point value.
Users can purchase points individually or as part of packages to receive discounted rates.
When you use or activate a checksum module, WinOLS automatically deducts the corresponding number of Checksum Points from your account.
Checksum Points can be used to:
- Purchase Checksum Modules (Import/Export, Maps, Special Items, Checksum Correction)
- Purchase Projects from the EVC Reseller / Online Project Database
- Why Does WinOLS Use a Point System?
EVC chose the Point System because it offers several key benefits:
- Flexible license management – buy points once and use them gradually over time.
- Cost optimization – save significantly by purchasing Checksum Points in larger packages.
- Unified system – the same points can be used across both WinOLS and the reseller project network.
This system is especially useful for tuners, workshops, and professional users who frequently need access to different checksum modules or plugins for various ECU projects.
- Real-World Example
Suppose you are editing an ECU file and WinOLS notifies you that the checksum module for that ECU has not yet been activated.
You can simply use your Checksum Points to unlock it instantly — without additional payment or waiting for a new license.
Once the points are deducted, the checksum module is permanently activated for your use.
- Summary
The Checksum Point System in WinOLS 5 provides a smart and flexible way to purchase checksum modules, plugins, and projects.
It gives users greater control, convenience, and cost efficiency in managing their tuning and calibration workflows.
| Part-No. | CS points |
| OLS-CKS3 | 3 |
Understanding the Checksum Point System in WinOLS 5
- What is a Checksum Point?
In WinOLS 5, EVC electronic (Germany) introduced a new mechanism called the Checksum Point System.
This is a flexible payment model that allows users to purchase and activate checksum modules, plugins, or projects as needed.
Checksum Points act as a digital currency within the WinOLS ecosystem.
You can buy points in advance and then use them to pay for specific features or services whenever required.
- How Does the Checksum Point System Work?
Each checksum plugin or project in WinOLS has its own point value.
Users can purchase points individually or as part of packages to receive discounted rates.
When you use or activate a checksum module, WinOLS automatically deducts the corresponding number of Checksum Points from your account.
Checksum Points can be used to:
- Purchase Checksum Modules (Import/Export, Maps, Special Items, Checksum Correction)
- Purchase Projects from the EVC Reseller / Online Project Database
- Why Does WinOLS Use a Point System?
EVC chose the Point System because it offers several key benefits:
- Flexible license management – buy points once and use them gradually over time.
- Cost optimization – save significantly by purchasing Checksum Points in larger packages.
- Unified system – the same points can be used across both WinOLS and the reseller project network.
This system is especially useful for tuners, workshops, and professional users who frequently need access to different checksum modules or plugins for various ECU projects.
- Real-World Example
Suppose you are editing an ECU file and WinOLS notifies you that the checksum module for that ECU has not yet been activated.
You can simply use your Checksum Points to unlock it instantly — without additional payment or waiting for a new license.
Once the points are deducted, the checksum module is permanently activated for your use.
- Summary
The Checksum Point System in WinOLS 5 provides a smart and flexible way to purchase checksum modules, plugins, and projects.
It gives users greater control, convenience, and cost efficiency in managing their tuning and calibration workflows.
| Part-No. | CS points |
| OLS-CKS4 | 4 |
Understanding the Checksum Point System in WinOLS 5
- What is a Checksum Point?
In WinOLS 5, EVC electronic (Germany) introduced a new mechanism called the Checksum Point System.
This is a flexible payment model that allows users to purchase and activate checksum modules, plugins, or projects as needed.
Checksum Points act as a digital currency within the WinOLS ecosystem.
You can buy points in advance and then use them to pay for specific features or services whenever required.
- How Does the Checksum Point System Work?
Each checksum plugin or project in WinOLS has its own point value.
Users can purchase points individually or as part of packages to receive discounted rates.
When you use or activate a checksum module, WinOLS automatically deducts the corresponding number of Checksum Points from your account.
Checksum Points can be used to:
- Purchase Checksum Modules (Import/Export, Maps, Special Items, Checksum Correction)
- Purchase Projects from the EVC Reseller / Online Project Database
- Why Does WinOLS Use a Point System?
EVC chose the Point System because it offers several key benefits:
- Flexible license management – buy points once and use them gradually over time.
- Cost optimization – save significantly by purchasing Checksum Points in larger packages.
- Unified system – the same points can be used across both WinOLS and the reseller project network.
This system is especially useful for tuners, workshops, and professional users who frequently need access to different checksum modules or plugins for various ECU projects.
- Real-World Example
Suppose you are editing an ECU file and WinOLS notifies you that the checksum module for that ECU has not yet been activated.
You can simply use your Checksum Points to unlock it instantly — without additional payment or waiting for a new license.
Once the points are deducted, the checksum module is permanently activated for your use.
- Summary
The Checksum Point System in WinOLS 5 provides a smart and flexible way to purchase checksum modules, plugins, and projects.
It gives users greater control, convenience, and cost efficiency in managing their tuning and calibration workflows.
| Part-No. | CS points |
| OLS-CKS20 | 20 |
Understanding the Checksum Point System in WinOLS 5
- What is a Checksum Point?
In WinOLS 5, EVC electronic (Germany) introduced a new mechanism called the Checksum Point System.
This is a flexible payment model that allows users to purchase and activate checksum modules, plugins, or projects as needed.
Checksum Points act as a digital currency within the WinOLS ecosystem.
You can buy points in advance and then use them to pay for specific features or services whenever required.
- How Does the Checksum Point System Work?
Each checksum plugin or project in WinOLS has its own point value.
Users can purchase points individually or as part of packages to receive discounted rates.
When you use or activate a checksum module, WinOLS automatically deducts the corresponding number of Checksum Points from your account.
Checksum Points can be used to:
- Purchase Checksum Modules (Import/Export, Maps, Special Items, Checksum Correction)
- Purchase Projects from the EVC Reseller / Online Project Database
- Why Does WinOLS Use a Point System?
EVC chose the Point System because it offers several key benefits:
- Flexible license management – buy points once and use them gradually over time.
- Cost optimization – save significantly by purchasing Checksum Points in larger packages.
- Unified system – the same points can be used across both WinOLS and the reseller project network.
This system is especially useful for tuners, workshops, and professional users who frequently need access to different checksum modules or plugins for various ECU projects.
- Real-World Example
Suppose you are editing an ECU file and WinOLS notifies you that the checksum module for that ECU has not yet been activated.
You can simply use your Checksum Points to unlock it instantly — without additional payment or waiting for a new license.
Once the points are deducted, the checksum module is permanently activated for your use.
- Summary
The Checksum Point System in WinOLS 5 provides a smart and flexible way to purchase checksum modules, plugins, and projects.
It gives users greater control, convenience, and cost efficiency in managing their tuning and calibration workflows.
| Part-No. | CS points |
| OLS-CKS50 | 50 |
Understanding the Checksum Point System in WinOLS 5
- What is a Checksum Point?
In WinOLS 5, EVC electronic (Germany) introduced a new mechanism called the Checksum Point System.
This is a flexible payment model that allows users to purchase and activate checksum modules, plugins, or projects as needed.
Checksum Points act as a digital currency within the WinOLS ecosystem.
You can buy points in advance and then use them to pay for specific features or services whenever required.
- How Does the Checksum Point System Work?
Each checksum plugin or project in WinOLS has its own point value.
Users can purchase points individually or as part of packages to receive discounted rates.
When you use or activate a checksum module, WinOLS automatically deducts the corresponding number of Checksum Points from your account.
Checksum Points can be used to:
- Purchase Checksum Modules (Import/Export, Maps, Special Items, Checksum Correction)
- Purchase Projects from the EVC Reseller / Online Project Database
- Why Does WinOLS Use a Point System?
EVC chose the Point System because it offers several key benefits:
- Flexible license management – buy points once and use them gradually over time.
- Cost optimization – save significantly by purchasing Checksum Points in larger packages.
- Unified system – the same points can be used across both WinOLS and the reseller project network.
This system is especially useful for tuners, workshops, and professional users who frequently need access to different checksum modules or plugins for various ECU projects.
- Real-World Example
Suppose you are editing an ECU file and WinOLS notifies you that the checksum module for that ECU has not yet been activated.
You can simply use your Checksum Points to unlock it instantly — without additional payment or waiting for a new license.
Once the points are deducted, the checksum module is permanently activated for your use.
- Summary
The Checksum Point System in WinOLS 5 provides a smart and flexible way to purchase checksum modules, plugins, and projects.
It gives users greater control, convenience, and cost efficiency in managing their tuning and calibration workflows.
Cart
(0 Product)
Related products
Reviews
There are no reviews yet.
